READ BEFORE USE!
WARNING
WARNING
USE LIQUID PROPANE GAS ONLY!
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
Service must be performed by a qualified installer,
service agency or the gas supplier.
DANGER
WHAT TO DO IF YOU SMELL GAS:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and
immediately call your gas supplier or fire department.
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which
has no odor.
Using it in an enclosed space can kill you
Never use this appliance in an enclosed space such as a
camper. Tent, car or home.
OWNERS MANUAL
1
HYFP50085-1
Model No.:
WARNING
For Outdoor Use Only!
Use Liquid Propane Gas (LP-Gas) Only !
Propane cylinders sold separately .
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Read the
owners manual thoroughly before installing or servicing this
equipment. If the information in this manual is not followed
exactly, a fire or explosion may result causing property damage,
personal injury or loss of life. Save these instructions for future
use. If you are assembling this unit for someone else, give this
manual to him or her to read and save for the future.
WARNING
Turn off gas supply when the appliance is not in use.
An LP cylinder not connected for us should not be stored in the
vicinity of this or any other appliance.
WARNING
WARNING
If the appliance is stored indoors, detach and leave
LP-Gas cylinder outdoors.
WARNING
This appliance must be attended at all times!
WARNING
Battery may contain mercury. Do not deposit in fire or put in trash.
Recycle the battery as hazardous waste.
Design certified under ANS Z21.97 • CSA 2.41-(2012)
Requirements for Outdoor Gas Fireplaces
66637
Style No.:

Advertisement

loading
Need help?

Need help?

Do you have a question about the HYFP50085-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BOND MANUFACTURING HYFP50085-1

  • Page 1 OWNERS MANUAL HYFP50085-1 66637 Model No.: Style No.: READ BEFORE USE! WARNING For Outdoor Use Only! Use Liquid Propane Gas (LP-Gas) Only ! Propane cylinders sold separately . WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the owners manual thoroughly before installing or servicing this equipment.
  • Page 2 DANGER Failure to follow the Dangers, Warnings and Cautions contained in this Owner’s Manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property. During ignition procedure, one should NEVER get his/her face close to and/or above the burner in a case an unnoticed flame were to suddenly light up and cause injury.
  • Page 3 • The use of alcohol, prescription or non-prescription drugs may impair an individual’s ability to properly assemble or safely operate this outdoor appliance • Do not use in an explosive atmosphere. Keep gas appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids.
  • Page 4 • The LP gas tank should not be dropped or handled roughly. • Tanks must be stored outdoors out of the reach of children. Do NOT store in a building, garage, or any other enclosed area. • Never store your LP gas tank where temperatures can reach over 125°F. •...
  • Page 5 Fix or replace the hose as required before using the appliance. For assistance with repair or replacement of the hose, call Bond Manufacturing at 1-866-771-2663. Use only replacement parts from the manufacturer. b) Inspect the seal inside the CGA No 791 service valve on the LP gas cylinder when replacing the cylinder or at least once per year.
  • Page 6 Accessories ITEM DESCRIPTION FIREPIT TABLE FRONT ENCLOSURE LEFT ENCLOSURE RIGHT ENCLOSURE LAVA ROCKS 6.0KG TANK SEAT PVC COVER HARDWARE 1 PACK AGE TTERY AA 2 BOX 4 PC 1 PC 1 PC 1 PC 1 PC 1 PC 1 PACKAGE...
  • Page 7 ASSEMBLY INSTRUCTIONS * Please keep this owner's manual for future reference. *If you have opened the carton and removed all packages, please disregard the STEP 1 and 2. See the STEP 3 directly. STEP 1 STEP 1 STEP 2 (1) Open the carton and turn it upside down, making sure the carton is opened (1) Open the carton and turn it upside down, making sure the carton is opened up as below.
  • Page 8: Selecting A Location

    WARNING WARNING ** DO NOT COVER THE IGNITION SCREEN when placing the lava rocks into the fire bowl. Always keep Ignition Screen visible. This screen must be clear and free of obstructions at all times to insure proper operation. The burner of the fireplace must be covered by lava rocks completely.
  • Page 9 LEAK TEST Perform a leak test in a well ventilated area outside. Make sure any open flames or cigarettes are extinguished. Remove the battery. Ensure the burner control knob is in the "OFF" position. In a bowl, create a soap solution using 1 part water and 1 part liquid detergent. Apply the soapy water solution to all connections.
  • Page 10: Routine Care

    Wearing heat resistant gloves position a long lit match or lit long neck lighter close to the burner ports. DO NOT lean over the burner while lighting. Push and turn burner control knob to the "LOW" position. The burner should lit within 5 seconds. If ignition does occur within 5 seconds, turn the burner control knob to "OFF", wait 5 minutes for gas to clear and repeat the lighting procedure.
  • Page 11 IF YOU HAVE QUESTIONS OR CONCERNS PLEASE CALL BOND TOLL FREE # 1-866-771-BOND (2663) OR TO BETTER EXPEDITE YOUR REQUEST FEEL FREE TO EMAIL US customerservice@bondmfg.com OR LOG IN TO OUR WEBSITE UNDER CUSTOMER SERVICE SUPPORT www.bondmfg.com BOND MANUFACTURING CO. 1700 West 4th Street, Antioch CA 94509...
