Item# 67380-D
Lowe's# 466652
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Read the owner's manual thoroughly before installing or servicing this
equipment. If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury or loss of life.
Save these instructions for future use. If you are
assembling this unit for someone else, give this
manual to him or her and read and save for the
future.
Portable Gas Fire Pit
Owner's Manual
SERIES
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
WARNING
For outdoor use only.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BOND MANUFACTURING Signature Series
Summary of Contents for BOND MANUFACTURING Signature Series
- Page 1 SERIES Portable Gas Fire Pit Item# 67380-D Lowe’s# 466652 DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire department. WARNING Do not store or use gasoline or other flammable vapors and liquids in the...
-
Page 2: Safety Information
• Do not sit or rest hands or feet on this heating unit. • Never place hands or fingers on upper portion of this unit while in use. • Keep all electrical cords and fuel supply hose away from heated surfaces. Bond Manufacturing Company | Page 2... - Page 3 • Combustible material should not be within 72 inches of the top of the unit, or within 48 inches around the entire unit. • Keep the appliance area clear and free from combustible material, gasoline and other flammable vapors and liquids. •...
- Page 4 Combustible materials should not be within 72 Min. Clearance Min. Clearance 48 in (121.9 cm) 48 in (121.9 cm) inches of the top of the unit, or within 48 inches around the entire unit. Min. Clearance 48 in (121.9 cm) Bond Manufacturing Company | Page 4...
- Page 5 HARDWARE Item Description Cushion Spring Washer Flat Washer M6 Nut 1-866-771-2663 | Page 5...
- Page 6 CONTENTS Item Description Body Pumice Stones 1 box Handle Wrench Tank Holder Control Knob (preassembled) Bond Manufacturing Company | Page 6...
- Page 7 ASSEMBLY INSTRUCTIONS 1. Place 2 cushions (AA) onto threaded part of handle (D). Insert handle (D) into holes on top of the lid (A). 2. From the underside of the lid (A), place 2 spring washers (BB) and then 2 flat washers (CC) onto threaded part of the handle (D).
- Page 8 VALVE tighten connections by hand only. turn clockwise REGULATOR to reseal 6. Cover body (B) with lid (A). To lock lid (A) in place, turn clockwise. To unlock, turn counterclockwise. LOCK UNLOCK Bond Manufacturing Company | Page 8...
-
Page 9: Operation
OPERATION Before performing a leak test, be sure that no sparks can occur and you are in a spacious outdoor area. Connect the propane gas tank to the regulator and turn the valve on the unit to the “off” position. Brush a soap and water mixture on all connections. Turn the gas supply on; if bubbles occur on any connection there may be a leak. -
Page 10: Maintenance
• Not using manufacturer approved or supplied parts/accessories may result in a defective condition and void the warranty of this heating unit. • Always place lid (if applicable) or protective cover on heating item when not in use. Bond Manufacturing Company | Page 10... -
Page 11: Troubleshooting
Electrode wire is loose or disconnected Reconnect wire to the igniter box located inside the table behind the igniter box Electrode wire is shorting between valve Contact Bond Manufacturing for a re- and igniter pin placement part No gas flow Check that the gas tank isn’t empty... -
Page 12: Warranty
• Use and installation other than what is listed in this manual. Please contact the manufacturer for replacement parts. CONTACT If you have any questions or concerns, please contact Bond Manufacturing Company at the below resources: Toll Free Phone 1-866-771-BOND (2663) | Monday - Friday, 8am - 4:30pm PST Email customer.service@bondmfg.com...
