  • Page 1 EZN850 User’s Manual Copyright © EverFocus Electronics Corp, Release: Dec. 2009 Rev.C...
  • Page 2 - Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications made to this equipment, not expressly approved by EverFocus or parties authorized by EverFocus could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the...
  • Page 3 Do not use the appliance in an extreme environment where high temperature or high humidity exists. Use the appliance at temperature within -40℃ ~ 50℃ / -40 ~ 122 and a humidity below 90%. The input power source for EZN850...
  • Page 4 Java™ and all Java-related logos and trademarks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries. Support If the unit ever needs repair service, the customer should contact the nearest EverFocus Electronics Corp. Service Center for return authorization and shipping instruction. EZN850...

  • Page 5: Table Of Contents

    4.4.2.9 EXIT ...38 4.5 USER...39 4.6 EVENT...40 4.6.1 Event ...41 4.6.2 Motion...43 4.6.3 Alarm...44 4.6.4 Time Mask ...46 4.7 SYSTEM ...47 4.7.1 Date/Time...47 4.7.2 Daylight Saving ...49 4.7.3 SD Card...50 4.7.4 Serial Communication ...53 4.7.5 Maintenance ...54 5. SPECIFICATIONS...56 EZN850...

  • Page 6: Introduction

    EZN850 network camera utilizes H.264, MPEG-4 and MJPEG compression for multiple streaming outputs. Engineered with the advanced new generation 16-bit DSP, the EZN850 has powerful processing capability to perform 560 TVL of horizontal resolution. With built-in DNR (Dynamic Noise Reduction), EZN850 provides crystal clear images in low light condition and substantial disk-saving.

  • Page 7: Accessing The Camera Menu

    Step 1. Start an Internet Explorer browser. Step 2. Enter the IP address or host name of the camera in the Location/Address field of your browser. (Please refer to EZN850 Installation Guide for how to find the IP address). Step 3. Input “Username” and “Password”. Default Username is “user1” and default password is “11111111”.
  • Page 8 User Config” for further information. Note: Record segment is limited to 5 min. If you need to do long time recording, please set schedule recording. For more details about schedule recording, please see “4.6 EVENT”. button to close EZN850 network page. EZN850...

  • Page 9: Setting

    Motion menu. Please refer to “4.6.2 Motion” for detailed information about Motion setup. 4. Setting Click this button to display the setup menu. EZN850...
  • Page 10 EZN850...

  • Page 11: System Info

    EZN850 4.1 System Info System information and system log check of the setup menu can be performed on this page. The “System Info” page has 2 tabs: [Information] tab and the [Log] tab. 4.1.1 Information System Information: Firmware version, MAC address, Video Type, Model number.

  • Page 12: Log

    System will keep the latest 256 records. Press button to export system log into “.txt” file and select the location where the exported log file will be saved to. EZN850...

  • Page 13: User Config

    Position: Select the position where the text will be displaying from Upper Left / Lower Right / Lower Left. Press Apply to apply the setting changes or Reset to reset without saving the change. Date/Time Format Used in Text Select Date/Time Format from the following options: EZN850...
  • Page 14 Browse button to locate the new language file (.evb) and then click the Load button. Note: 1. Maximum five languages can be in the language list. 2. Upload a new language file will reboot system automatically. Please reconnect IP camera after reboot. button, then direct to the EZN850...

  • Page 15: Network

    The following information is required to configure the network settings. Contact the network administrator or your Internet service provider. • IP Type • IP address • Subnet mask • Gateway (when using the gateway server/router) • Primary DNS, Secondary DNS (when using DNS) • HTTP Port EZN850...
  • Page 16 Primary DNS An IP address of DNS server that is provided by ISP. Secondary DNS If your ISP provides you an IP address secondary DNS, please set it here. Username Enter User name of the account (used only for PPPoE). EZN850...

  • Page 17: Ddns

    When accessing the camera via the Internet from the network environment of which the global IP address is obtained using DHCP, the DDNS function is necessary. To use the DDNS function, it is necessary to connect to the dedicated DDNS EZN850...

  • Page 18: Bandwidth

    ○ www.dyndns.com ○ www.no-ip.com Enable: Check the box to enable DDNS setting. Service ISP: If you choose EverFocus DDNS server, you can obtain a free account name from EverFocus ”www.everfocusddns.com”. Enter an IP Cam Account Name: Press button to register or update DDNS account.

  • Page 19: Smtp/Ftp

    The settings relating to the mail server used to send the e-mail notification from the camera to predefined addresses via SMTP can be configured. SMTP Server: Enter the IP address or the host name of the SMTP server used to EZN850...
  • Page 20 Test FTP Server: Press FTP server. Press Apply to apply the setting changes or Reset to reset without saving the change. button to send a testing mail to the assigned button to send a testing file to the assigned EZN850...

  • Page 21: Network Alarm (Reserved For Powercon)

    This function is reserved for PowerCon software, for the detail setting please refer to PowerCon network alarm protocol. 4.4 Video The settings relating video such as streaming, camera OSD can be configured on this page. The "Video" page has 2 tabs: the [Multi-streaming] tab and the [Camera] tab. EZN850...

  • Page 22: Multi Streaming

    Frame Rate: select from NTSC: 1 / 3 / 5 / 15 / 30 fps, PAL: 1/ 2.5/5/12.5/25 fps. Note: 1. Total frame rate cannot exceed 60 fps. 2. System performance may be influenced if user enables 4 video streams simultaneously. EZN850...

  • Page 23: Camera

    EZN850 Press Apply to apply the setting changes or Reset to reset without saving the change. Video Recording Setting User can set video recording by selecting one of the enabled video streams. This will allow user to view live images as well as to record video of the other video streaming.

  • Page 24: Lens

    “LENS” by clicking the UP ( ) or DOWN ( ) key. Click Left ( ) or Right ( ) key to adjust IRIS level (the higher is brighter). In most cases, you don’t need to adjust this, since Lens is Auto Iris supported. EZN850...

  • Page 25: Shutter

    SPECIAL <┘ EXIT Note: Since DC lens is a built-in lens for EZN850 camera, it does not support Manual lens, please do not select lens as Manual mode, it disables sens-up and may cause malfunction of lens. Please click SET key for saving setting and return to the previous menu.

  • Page 26: White Balance Control

    AWC (Auto White Balance Control): Click the SET key while the camera is directed at a piece of white paper to get the optimum state under the present illumination. If the environment and the light source are changed, you need to BRIGHTNESS BRIGHTNESS SHUTTER > MANUAL EZN850 |+++++++++| 25 1/50...

  • Page 27: Backlight

    2. Select the mode you would like to operate by clicking LEFT ( ) or RIGHT ( ) key. SETUP DC <┘ LENS SHUTTER WHITE BAL. > BACKLIGHT MIDDLE AUTO <┘ SENS-UP SPECIAL <┘ EXIT WHITE BAL. BLUE EZN850 |+++++++++| 32 |+++++++++| 39...

  • Page 28: Agc (Auto Gain Control)

    1. Please direct the arrow to point to “DNR” on the SETUP menu by clicking UP ( ) or DOWN ( ) key. 2. Select the mode you would like to operate by clicking LEFT ( ) or RIGHT ( ) key. EZN850...

  • Page 29: Sens-Up

    AUTO: Low light level auto mode. Default value is AUTO (Up to X 10). SETUP DC <┘ LENS SHUTTER WHITE BAL. BACKLIGHT MIDDLE AUTO <┘ > SENS-UP SPECIAL <┘ EXIT OFF: The function is disabled. LIMIT > AUTO EZN850 X 10...

  • Page 30: Special

    Input the camera ID, and it will be appeared on the monitor. 1) Please direct the arrow to point to “CAMERA” by clicking UP ( ) or DOWN ( ) key. 2) Select “ON” by clicking LEFT ( ) or RIGHT ( ) key. EZN850...
  • Page 31 ─ · ← → 0 1 2 3 4 5 6 7 8 9 C L R P O S E N D EZN850...
  • Page 32 RETURN <┘ 4.4.2.8.4 MOTION DETECTION EZN850 enables you to observe movements of objects in 4 different places on the screen, the message “MOTION DETECTED” appears on the screen when movement is detected; therefore this helps to improve supervision efficiency. The camera detects an object’s movement by sensing discrepancy of outline.
  • Page 33 1. The original position of AREA1 was TOP: 10, DOWN: 25, LEFT: 20 and RIGHT: AREA1 > AEREA SEL AREA STATE DOWN LEFT RIGHT AREA2 AREA4 EZN850 MOTION DETECTION AREA1 |+++++++++| 10 |+++++++++| 25 |+++++++++| 20 |+++++++++| 40 Press SET to return...
  • Page 34 5. Increase LEFT scale value by 20. AREA1 position after change is: TOP: 30, DOWN: 45, LEFT: 40 and RIGHT: 60. AREA1 In order to save the changes and complete the setting, click the SET key. This allows you to return to the previous menu. EZN850...
  • Page 35 Additionally, it is possible to change the position of the area to be covered. Please refer to the following example for detailed steps on moving AREA1 to center. PRIVACY > AEREA SEL AREA STATE. AREA TONE DOWN LEFT RIGHT EZN850 AREA1 |+++++++++| 80 |++++++++| 10 |+++++++++| 25 |+++++++++| 20 |+++++++++| 40...
  • Page 36 3. Increase TOP scale value by 20. AREA1 position after change is: TOP: 30, DOWN: 45, LEFT: 20 and RIGHT: 40. AREA1 4. Increase RIGHT scale value by 20. AREA1 position after change is: TOP: 30, DOWN: 45, LEFT: 20 and RIGHT: 60. AREA1 EZN850...
  • Page 37 -OFF: Disable the SHARPNESS mode. Please click the SET key. The available range of level is 0~31. SPECIAL CAMERA ID COLOR ADJ. <┘ SYNC. MOTIION DET PRIVACY MIRROR ON <┘ > SHARPNESS RESET RETURN <┘ SHARPNESS > LEVEL EZN850 |+++++++++| 8...

  • Page 38: Exit

    > RETURN <┘ 4.4.2.9 EXIT Click SET key on “EXIT” after you finish all the settings. It will return to live image. Note: If you quit the Menu without clicking EXIT, all the settings you previously did will NOT be saved. EZN850...

  • Page 39: User

    • Guest- the lowest level of access, which only allows the user access to the Live View page. Note: Please select Active in Status section to activate user account. Press Apply to apply the setting changes or Reset to reset without saving the change. EZN850...

  • Page 40: Event

    2. **Either Upload to FTP or Record to Network Storage can be selected to record event video to remote site. 3. Up to 10 event types can be configured in the camera, and up to 3 of these can be configured to upload images Manual Motion Schedule Trigger Detection Recording EZN850 Pre/Post-Alarm...

  • Page 41: Event

    EZN850 4.6.1 Event The settings relating to event occurrences such as settings for the event occurrence, motion, alarm and time mask can be configured on this page. The "Event" page has 4 tabs: the [Event] tab, the [Motion] tab, the [Alarm] tab and the [Time Mask] tab.
  • Page 42 EZN850 To change the priority of events, click on the event and it will be highlighted. Press button to move between events. The event that has highest priority will be activated first. Press Apply to apply the setting changes or Reset to reset without saving the change.

  • Page 43: Motion

    To remove the selection, simply right click the mouse, the selected polygon will be deleted. Steps for setting motion detection areas: 1. Motion Detection video is not a moving video. For getting the most update picture, press to update the current image. EZN850...

  • Page 44: Alarm

    2, 3, 4, 5, 6, 7, 8, 9 to 10 (high). 7. For each of them, you can set the event action to be activated. Event action can be set in “Event” section. 4.6.3 Alarm and click on the polygon, to EZN850...
  • Page 45 EZN850 Alarm Output Setting Contact Type: Normal Close, Normal Open Duration Time: Select duration time of alarm output from 5 sec, 10 sec, 20 sec, 30 sec, 60 sec, 2 min, 3 min and 5 min. Press Apply to apply the setting changes or Reset to reset without saving the change.

  • Page 46: Time Mask

    2. Enter Mask name, e.g. Weekend. 3. Check “Sun” & “Sat” boxes. 4. Select “Start time” and “End time” or “Full day”. Press Apply to apply the setting changes or Reset to reset without saving the change. for a full day of event action. EZN850...

  • Page 47: System

    Press Apply to apply the setting changes or Reset to reset without saving the change. Set Date/Time Manually Date: Click the calendar and pick the date. Press << to go previous year, < to go previous month, > to go next month and >> to go next year. EZN850...
  • Page 48 Sync. Internal: Select an interval (1 - 24 hours: in 1 hour intervals) of synchronization with the NTP server. Time Zone: Select a time zone according to the location where the camera is in use. Press Apply to apply the setting changes or Reset to reset without saving the change. EZN850...

  • Page 49: Daylight Saving

    EZN850 4.7.2 Daylight Saving Set Daylight Saving Check Enable Daylight Saving checkbox to enable daylight saving. Set the start time to daylight saving time. Set the start week of daylight saving time: 1 / Last Set the start date of daylight saving time: Sunday / Monday / Tuesday / Wednesday...

  • Page 50: Sd Card

    2. E-mail notification may not always be made at a very moment when the remaining space of the SD memory card reached the selected value Event Recording: -FTP backup only: Event video will record to SD card when network is disconnected. EZN850...
  • Page 51 3. Do not turn the power of the camera off in the process of formatting. Obtain images on the SD memory card 1. Go to IE Browser or Windows Command. 2. Enter ftp://Camera IP address ----- The windows pops up for user name and password. button will be shown for user to EZN850 button.
  • Page 52 EZN850 3. Enter administrator user name and password. (user1, 11111111) 4. Then you can download video or image file from SD card. The file name will show the time of video.

  • Page 53: Serial Communication

    RS485 port on the camera. There are six different speeds, 2400/4800/9600/19200/38400/57600. The default setting from the factory is 9600. Protocol: Select protocol from EverFocus and Pelco-D. The default setting from the factory is Pelco-D. Data Bit: This field is the data bit at which you will be transferring. There are two settings for this option: 8 or 7.

  • Page 54: Maintenance

    • DDNS setting Default: The Default button should be used with caution. Pressing this button will return all of the camera's settings, including the IP address, to the factory default values. The camera will then have to be re-installed. EZN850...
  • Page 55 Press the Browse button to locate the saved config. file (see above) and then click the Load button. The settings will be restored to the previous configuration. Upgrade Firmware Upgrade the EZN850 with the latest firmware. Press Browse button to search firmware file. Press Upgrade button to upgrade the firmware.

  • Page 56: Specifications

    Supports SDHC Host Specification POWER Power Supply 24VAC ; 100VAC~240VAC 24VAC: 28W max. (Heater/ON & IR LED/ON) ; Power Consumption 100VAC~240VAC: 8W max. (Heater/ON & IR LED/ON) PHYSICAL Dimensions 295 mm (W) x 115 mm (H) ; 11.8” (W) x 4.5” (H) EZN850...
  • Page 57 Weight 2.5kg ; 5.5lbs (3.0kg ; 6.6LBS with bracket) ENVIRONMENTAL Operating Temp. -40°C ~ 50°C ; -40°F ~ 122°F Humidity 20~80% Heater Weatherproof Ratings IP66 Vandal Proof EZN850...
  • Page 58 Hauppauge, NY 11788 TEL: +1-631-436-5070 FAX: +1-631-436-5027 www.everfocus.com Your EverFocus product is designed and manufactured with high quality materials and components which can be recycled and reused. This symbol means that electrical and electronic equipment, at their end-of-life, should be disposed of separately from your household waste.
