MKIV UNDERDECK JIB REEFING & FURLING
Installation Manual - Intended for specialized personnel or expert users
Please read these instructions carefully before installing, servicing, or operating the equipment.
This manual may be modified without notice. See: www.harken.com/manuals for updated versions.
Unit 1, 2, 3
Hub Assembly
Troubleshooting/Warranty
PLEASE SAVE THESE INSTRUCTIONS
