g) Preparation of wall outlet
Before connecting the amplifier to your mains supply using a licensed electrician, check
that the supply is correctly wired, and is adequate for power consumption up to
1200 VA. Make certain that the grounding lead is connected properly and that it has a
cross section not less than the cross section of the phase conductor in the wall outlet for
the amplifier.
It is preferable that you use the wall outlet closest to the source. The installation leads should be at least
1.0 mm² (AWG 17 or SWG 18) at operating 200-240VAC and 1.5 mm² (AWG 15 or SWG 17) at 100-120VAC
(recommended values if there are no stricter requirements by your local standard).
Check that the panel fuse has a free capacity for the additional load from the amplifier as specified in
Sections
5.3 Fuse Replacement
mains outlet, be sure that you check it, too.
Make sure the main Power switch (marked "ON", see
front panel is in OFF position (see
mains plug into the wall outlet prepared for it. The amplifier remains switched off (with the "ON" indicator
dark).
Page 18 of 40 | S e c t i o n INSTALLATION
WARNING
and
6.1.i) Mains Power Consumption

Figure 2-2 Power rocker switch in OFF or ON position

Figure 2-2 Power rocker switch in OFF or ON position
Figure 2-2 Power rocker switch in OFF or ON position
User's Manual | ACOM 1010 | HF Linear Amplifier
. If you connect the amplifier to a different

Figure 3-1 Front panel - Display and Controls

OFF position
) on the
) and insert amplifier's
ON position
