- Page 1 Operator’s Manual WF-8900-REP Series WF-9900 Series Converter Replacement Kit Distributed in the U.S.A. and Canada by ARTERRA DISTRIBUTION (877) 294-8997 Warranty: warranty@wfcoelectronics.com Fax (574) 294-8698 Power PROs Technical Support www.wfcoelectronics.com (877) 294-8997...
-
Page 2: Table Of Contents
TA B L E O F C O N T E N T S SAFETY INFORMATION ......................3 KIT FEATURES ..........................3 PERFORMANCE FEATURES ...................... 4 INSTALLATION INSTRUCTIONS Tools Needed ..........................4 Step-by-Step Instructions ......................4 DC Fuse Board ..........................5 TROUBLESHOOTING INSTRUCTIONS ................ -
Page 3: Safety Information
GENERAL INFORMATION WF-8900-REP Kit Features The WF-8900-REP Converter Replacement Kit allows easy upgrade of existing power centers. Technicians can easily remove the lower section of certain power center brands and slide in the WF-8900-REP unit. This exchange upgrades the old single stage charger to a high performance three-stage charging powerhouse. -
Page 4: Performance Features
OPERATIONAL FEATURES WF-8900-REP Performance Features The WF-8900-REP Converter Replacement Kit provides all of WFCO’s performance standards: • Quiet Operation • Filtered Power • Overload Protection • Short Circuit Protection • FCC Class B Approval INSTALLATION INSTRUCTIONS Installing the WF-8900-REP Kit Tools Needed for Assembly: •... -
Page 5: Dc Fuse Board
Removing the AC (110 volt) side of the converter: 1. Drop the front door down and turn off 30amp main breaker. 2. Remove all screws holding the front door assembly on. 3. Remove (2) screws holding the metal plate that covers the AC breakers. 4. -
Page 6: Troubleshooting Instructions
16. Turn all breaker on and apply 110volt power to the RV. Test for operation. TROUBLESHOOTING INSTRUCTIONS Troubleshooting the WF-8900-REP Series Refer to the WF-9800 Series Troubleshooting Guide for the WF-9800 Series Deck Mount found on page 11 of this manual. -
Page 7: Automatic Cooling Fan
Automatic Cooling Fan The cooling fan in the WF-9800 Series Converter-Chargers is incremental and is controlled by the current drawn out of the converter to the applied load. The on-board microprocessor increases fan speed as the total load increases and decreases fan speed as the load decreases. Figure 2 Unlike traditional temperature-controlled fans, the load-controlled fan provides better component cooling by avoiding temperature spikes which can lead to premature... -
Page 8: Operational Features
Absorption, Bulk, and Float. 3-Stage Charging WFCO converters of every style have become the favored brand for power conversion and electric distribution in the RV industry. They provide RV owners wth an efficient and cost- effective method to use an AC power source and provide power to DC components inside the RV, while charging accessory batteries at the same time. -
Page 9: Absorption Mode
RV will rarely require anything other than Absorption Mode. When a WFCO converter is connected to a battery in Absorption Mode, power is available for charging that battery whenever the converter output is greater than the voltage level of the battery. -
Page 10: Converter Output Voltage
Converter Output Voltage Before checking the WF-9800 Series Converter-Charger output voltage, disconnect the battery cables at the battery. Make sure the converter is plugged into an AC source (105- 130 Volts). Check the converter output voltage at the battery with a voltmeter. Place the meter probes on the discon-nected battery cables;... -
Page 11: Troubleshooting Flow Chart
If the above checks have been made but the converter output still reads 0.0 VDC, the converter is not functioning properly. Figure 5 GENERAL COMPLIANCE INFORMATION Agency Listings The WF-9800 Series Converter-Chargers are UL-Listed, and cUL-Listed (Canadian). FCC Compliance Class B NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 12 Figure 6...
-
Page 13: Specifications
United States, Alaska, Hawaii and the Provinces of Canada. WFCO warrants, to the owner, that its products are free from defects in material and workmanship under normal use and service based on its intended use and function. - Page 14 WF-8900-REP DIMENSIONAL DRAWING Figure 7...
- Page 16 W F C O E L E C T R O N I C S . C O M...
