WFCO WF-68100 Installation Manual

WF-6800 Series Specifications
WF-6800 Facts Summary
AC Input DC Output
Model
Voltage Current AGM/L.A. Gel-Cell
No.
Volts (V)
(V) (A) Volts (V)
13.2 13.2
105
WF-68100
to 14 13.7 13.6
132
14.4
Wiring Diagram
POS+
CHASSIS
(EARTH)
GROUND
Ground bar can also be found
GROUND BAR
inside of the WF-8930/50
distribution panel.
Dimensions
Weight PFC
Amps
Height Width Length
(lbs)
(A) (in) (in) (in)
Yes
100 3.89 9.92 13.36 10.25
AGM
Lead-Acid
BATTERY TYPE SELECTION
Gel-cell DIP SWITCH
NEG-
REVERSE BATTERY
PROTECTION FUSES
ATC Style
"Littelfuse " Type 257 fuses ®
Distribution Panel
WF-8930/50
Possible Inline fuse
12 V
BATTERY
CD-M-00009-7
For use with WFCO Deckmount Converter
4
