WFCO WF-68100 Operator's Manual

Operator Manual
For use with WFCO Deckmount
WF-68100
Converter
CAUTION
! !
CAUTION and care must be taken when servicing this equipment.
To prevent severe shock or electrocution consult your servicing dealer.
No serviceable parts.
General Consumer Information
Power Factor Correction
This feature causes the unit to consume
cost or allows more AC devices to be used.
Reverse Battery Protection
This feature prevents permanent damage to the converter from an incorrect
battery connection. Replace only with "ATC-style" fuses.
Automatic Cooling Fan
The fan is variable speed and current controlled.
Electronic Current Limiting
Automatically shuts down power during overload or short-circuit conditions.
Automatically returns to normal operation after conditions are corrected.
If the unit shuts off from an overload condition, the user needs to reduce the
load below 50% in order for the unit to come back on.
Over-Temperature Protection
Unit will shut down if temperature is too high.
Battery Type Selection Switch
For increased battery life span, you can select battery type between
AGM/Lead-Acid and Gel-Cell type of batteries. Gel-Cell type of batteries
requires lower output voltage and there is no need for bulk mode. Default
setting is (up) AGM/Lead-Acid type of batteries.
Manual Bulk Charging Switch
For AGM/Lead-Acid type of batteries, with a push of a button on the front
cover you can manually bring the converter to bulk charge mode.
2
LED Indicators
Lights show operating status of the converter:
- Green LED: converter powered up
- Amber LED: On when unit is turned off and the connected battery is full,
flickering occurs when battery is approaching low voltage.
- Red LED: converter is overloaded
less power, which reduces electric
