HEAT GLO SUPREME-I30-IFT Owner's Manual
Hide thumbs Also See for SUPREME-I30-IFT:

Advertisement

INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
NOTICE: DO NOT discard this manual!
Models:
SUPREME-I25-IFT
SUPREME-I30-IFT
SUPRM-I30LP-IFT
SUPREME-I35-IFT
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner's Manual • 2532-981 Rev. J • 7/20
Owner's Manual
Care and Operation
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fitter.
See appliance installation manual for additional
Commonwealth of Massachusetts requirements.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPREME-I30-IFT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HEAT GLO SUPREME-I30-IFT

  • Page 1 See appliance installation manual for additional gases, unless a certified kit is used. Commonwealth of Massachusetts requirements. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 2: Welcome

    MIN. MIN. INPUT INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 Serial Serial XXXXXXXX XXXXXXXX ORIFICE ORIFICE SIZE: SIZE: #XXXXX #XXXXX #XXXXX #XXXXX (Serie): (Serie): Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 3: Table Of Contents

    C. Contact Information ......31  = Contains updated information. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 4: Limited Lifetime Warranty

    None 1 Year All replacement parts beyond warranty period See conditions, exclusions and limitations on the next page Page 1 of 2 4021-645K 1/20 Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 5 OTHER THAN THE WARRANTY SPECIFICED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645K 1/20 Page 2 of 2 Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 6: Product Specific Information

    This appliance is equipped with 5 mm ceramic glass. Re- place glass only with 5 mm ceramic glass. Please contact your dealer for replacement glass. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 7: Important Safety And Operating Information

    • Keep remote controls out of reach of children. Figure 3.1 Clear Space Requirement - All Models • Never leave children alone near a hot fireplace, whether operating or cooling down. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 8: General Operating Parts

    For APPLIANCE SURROUND additional finishing guidelines, see Section 8 Installation Manual. Figure 3.3 Good Faith Wall Surface Temperatures Above Appliance Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 9 Increase “A” dimension. Increase “C” dimension, however, increasing “B” dimension beyond maximum recommended typically results in higher temperatures. Figure 3.4 Good Faith TV Guidelines Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 10: Before Lighting Appliance

    • Verify collar slide plate screw is attached see Figure 3.5. BE SURE SLIDE PLATE SCREW IS FULLY TIGHTENED. Figure 3.5 Collar slide Plate Screw Detail Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 11: Lighting Instructions (Ipi)

    Propane Installation code, CSA B149.1. P65Warnings.ca.gov. For additional information on operating your Keep burner and control compartment clean. See installation and operating instructions accompanying appliance. refer to www.hearthnhome.com. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 12: Appliance Break-In

    See Section G. This break-in will ensure optimum speed control of the fan during subsequent use. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 13: Operation During A Power Outage

    See Figure 3.9. Check to make sure the ignition module switch is NOT in the “ON” position. • Resume normal operation with the RC400. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 14: Detailed Component Operating Instructions - Intellifire

    IFT-RC400, IFT-RC150 or wired wall switch. 2. If multiple control options are installed, the IFT-ECM will respond to the last command from the wired wall switch, IFT-RC400 or IFT-RC150. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 15 If the IFT-ECM re-enters the lock-out condition after these steps, call your dealer for service. SURROUND RESET SWITCH Figure 3.10 Surround Reset Switch Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 16: Maintenance And Service

    CAUTION! Risk of Burns! The fireplace should be turned off and cooled before servicing. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 17 Verify top latches are fully engaged and then fasten the two bottom latches using the supplied multi-purpose tool. • Reinstall door or decorative front. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 18 CAUTION: Be sure to reinstall the component heat shield before firing the appliance. Components will overheat without the heatshield in place. CAUTION: Be sure to reinstall wires into the retaining clips. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 19: Maintenance Tasks - Qualified Service Technician

    • Verify that the collar slide plate screw is installed. See Figure 3.5. • Remove all foreign objects. • Verify unobstructed air circulation. • Ensure no wire connections become disengaged. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 20 • Verify that there is not a short in flame sense circuit by checking continuity between pilot hood and flame sensing rod. Replace pilot as necessary. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 21: Frequently Asked Questions And Troubleshooting

    (4 AA cell batteries required). Refer to Section 3.I for more details. Contact your dealer for additional information regarding operation and troubleshooting. Visit www.heatnglo.com to locate a dealer. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 22: Frequently Asked Questions - Intellifire Touch Controls (Ift-Rc400)

    90 seconds. If this failure appliance did not start. Try again period of appliance inactivity. persists, contact dealer for service. by pressing Flame On. Gas control system failure. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 23: Troubleshooting

    6-pin harness. Pilot won’t light, there is no noise Spark coil failure. Replace ECM. or spark, 2 Red/2 Green Lockout. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 24 Damaged pilot assembly. tance between tip of sense rod and IFT-ECM connector, should be less than 1 ohm. Replace pilot assembly if damage is de- tected. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 25: Reference Materials

    For more information refer to the instructions supplied with your decorative front. Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 26: Service Parts

    (Not for use with BRICK-MI25-TR/BRICK-MI25-HB) Seal, Glass Frame 2531-122 GLA-2531 Glass Door Assembly Power Cord 2201-024 GFK-160A Additional service part numbers appear on following page. 7/20 Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 27 (Not for use with BRICK-MI30-TR/BRICK-MI30-HB) Seal, Glass Frame 2532-122 GLA-2532 Glass Door Assembly Power Cord 2201-024 GFK-160A Additional service part numbers appear on following page. 7/20 Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 28 (Not for use with BRICK-MI35-TR/BRICK-MI35-HB) Seal, Glass Frame 2533-122 GLA-2533 Glass Door Assembly 2201-024 Power Cord GFK-160A Additional service part numbers appear on following page. 7/20 Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 29 Jumper Wire, 36” Male/Female 19.8 2532-170 Tray, Component 19.9 2532-171 Wire Tray 19.10 SRV2179-300 Wall Switch Jumper Wire 19.11 SRV2326-152 Cable, B Type AC Module Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 30 Regulator NG NGK-DXV-50 Regulator Propane SRVLPK-DXV-50 **Fuse for battery pack can be sourced locally, not a warranty item. Specs are 250v, 3A fuse, 3/4” long Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
  • Page 31: Contact Information

    6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7074035, 7098269, 7258116, 7322819, 7470729, 7726300, 8147240, 9625149 or other U.S. and foreign patents pending. 2000-945D Printed in U.S.A. - Copyright 2020 Heat & Glo • SUPREME-I25-IFT, SUPREME-I30-IFT, SUPRM-I30LP-IFT, SUPREME-I35-IFT Owner’s Manual • 2532-981 Rev. J • 7/20...
