WHISPERFLO
HIGH PERFORMANCE PUMP
Rainbow Pool Products
PO Box 2388, Mansfield Qld 4122
Telephone STD 61-7-3849 5385
Facsimile STD 61-7-3849 5384
Email: info@rainbowpoolproducts.com.au
Web: www.rainbowpoolproducts.com.au
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
P/N L300203 B1012
XF
SAVE THESE INSTRUCTIONS
™
INSTALLATION AND
USER'S GUIDE
XF
™
WHISPERFLO
High Performance Pump Installation and User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WHISPERFLOXF and is the answer not in the manual?

Questions and answers

Related Manuals for Pentair WHISPERFLOXF

Summary of Contents for Pentair WHISPERFLOXF

  • Page 1 ™ WHISPERFLO HIGH PERFORMANCE PUMP Rainbow Pool Products INSTALLATION AND PO Box 2388, Mansfield Qld 4122 Telephone STD 61-7-3849 5385 USER’S GUIDE Facsimile STD 61-7-3849 5384 Email: info@rainbowpoolproducts.com.au Web: www.rainbowpoolproducts.com.au IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS SAVE THESE INSTRUCTIONS P/N L300203 B1012 ™...

  • Page 2: Table Of Contents

    ™ registered trademarks of Pentair Water Pool and Spa, Inc. and/or its affiliated companies in the United States and/ or other countries. Unless expressly noted, names and brands of third parties that may be used in this document are not used to indicate an affiliation or endorsement between the owners of these names and brands and Pentair Water Pool and Spa, Inc.

  • Page 3: Important Pump Warning And Safety Instructions

    IMPORTANT PUMP WARNING AND SAFETY INSTRUCTIONS General Warnings IMPORTANT NOTICE capacitor bank that holds a 230 VAC charge even when there is no This guide provides installation and operation instructions for the power to the unit. ™ questions regarding this equipment. Attention Installer: This guide contains important information about the and programming to limit pumps performance potential with old or installation, operation and safe use of this product.
  • Page 4 (D) Disabled submerged outlets, or Warnings and safety instructions for Pentair Aquatic Systems For Installation of Electrical Controls at Equipment Pad (ON/OFF pumps and other related products are available at: Switches, Timers and Automation Load Center) http://www.pentairpool.com/pool-owner/safety-warnings/ or call...

  • Page 5: Pump Overview

    PUMP OVERVIEW The WhisperFloXF High Performance Pump is ™ specifically designed to be the best choice for a variety of inground pools. A heavy duty 56 square flange motor, and highly engineered hydraulics make this rugged and tested design perfect for any pool, spa, water feature, or fountain.

  • Page 6: Electrical Wiring Installation

    ELECTRICAL WIRING INSTALLATION RISK OF ELECTRICAL SHOCK OR ELECTROCUTION. This pump must be installed by a licensed or certified electrician or a qualified service professional in accordance with the National Electrical Code and all applicable local codes and ordinances. Improper installation will create an electrical hazard which could result in death or serious injury to users, installers, or others due to electrical shock, and may also cause damage to property.

  • Page 7: Operating The Pump

    OPERATING THE PUMP DO NOT run the pump dry. If the pump is run dry, the mechanical seal will be damaged and the pump will start leaking. If this occurs, the damaged seal must be replaced. ALWAYS maintain proper water level in your pool (half way up skimmer opening).

  • Page 8: Maintenance

    MAINTENANCE DO NOT open the strainer pot if pump fails to prime or if pump has been operating without water in the strainer pot. Pumps operated in these circumstances may experience a build up of vapor pressure and may contain scalding hot water. Opening the pump may cause serious personal injury.

  • Page 9: Servicing

    SERVICING Always disconnect power to the pump at the circuit breaker and disconnect the communication cable before servicing the pump. Failure to do so could result in death or serious injury to service people, users or others due to electric shock. Read all servicing instructions before working on the pump.

  • Page 10: Pump Reassembly

    Pump Reassembly spring end of the mechanical seal 8. Assemble the motor subassembly to the housing. black/carbon face is facing outward. wrench, install and tighten the four nuts to a overtighten the nuts. 9. Fill the pump with water. the seal into the seal plate with your thumbs and lubricate seal faces.

  • Page 11: Troubleshooting

    TROUBLESHOOTING RISK OF ELECTRICAL SHOCK OR ELECTROCUTION. Improperly installation will create an electrical hazard which could result in death or serious injury to pool users, installers, or others due to electrical shock, and may also cause damage to property. 1. If you are not familiar with your pool filtering system and/or heater: a.

  • Page 12: Replacement Parts

    REPLACEMENT PARTS WhisperFloXF High Performance Pump Parts List ™ Item # Description QTY. Item # Description QTY. IMPELLER PUMP CASING ASSEMBLY 401000 See Impeller BARREL UNION KIT 410020 IMPELLER KIT LID/LOCKING RING 401006 801293 (Includes items 11, 12 & 14)

  • Page 13: Pump Dimensions

    Pump Dimensions ™ WHISPERFLO High Performance Pump Installation and User’s Guide...

  • Page 14: Pump Performance Curves

    Pump Performance Curves Head Liters per Minute Note: This chart is valid for 50Hz, 2 pole speed and positive suction pressure. Note: speed and positive pressure. Q [l/min] PWA CONFIDENTIAL Printe Rainbow Pool Products PO Box 2388, Mansfield Qld 4122 Telephone STD 61-7-3849 5385 Facsimile STD 61-7-3849 5384 Email: info@rainbowpoolproducts.com.au...
