For technical assistance or replacement parts, please contact Sunjoy Industries
at 1(866) 578-6569 any time 24 hours/7 days a week or Email bj@sunjoygroup.com
or visit www.sunjoyonline.com to place your order.
Our clear, easy-to-follow, step-by-step instructions will guide you through the project from start to
finish. The final product will be a quality piece that will assemble easily and give years of enjoyment.
IMPORTANT:
Please read instructions thoroughly before assembly. Familiarize yourself with the inventory of parts and
the accompanying illustrations to assure safe and proper
Repeated assembly can weaken the locking ability of the washers. Periodically check all bolted
connections on your set to make sure they are tight and secure. Please keep the instructions for future
reference.
WARNINGS AND CAUTIONS:
Read and follow all Warnings & Assembly Instructions before attempting to assemble.
Keep children away from assembly area.
Assemble on level ground.
Do not over tighten any of the bolts or nuts; tighten only until firm.
7 PIECE
CORA
DINING SET
ARTICLE #113109
assembly.
Advertisement
Table of Contents
Related Manuals for Berkley Jensen 113109
Summary of Contents for Berkley Jensen 113109
- Page 1 7 PIECE CORA DINING SET ARTICLE #113109 For technical assistance or replacement parts, please contact Sunjoy Industries at 1(866) 578-6569 any time 24 hours/7 days a week or Email bj@sunjoygroup.com or visit www.sunjoyonline.com to place your order. Our clear, easy-to-follow, step-by-step instructions will guide you through the project from start to finish.
- Page 2 PARTS LIST: Quantity Part Part No. Description Umbrella hole P30308A06163 P31324A06163 Table top P31431A01163 P11457A01163 Bottom support P11458A01163 Side support H06020C11 Bolt M6*20 Spring washer H13001C11 H12001C11 Flat washer M6 H00002C12 M6 Hex wrench Step 1 Use Hex wrench (DD) to attach the Legs (C) to Table top (B) using Bolt (AA), Spring washer (BB) and Flat washer (CC) as Fig.1, don’t tighten them here.
- Page 3 Step 3: Use Hex wrench (DD) to attach the Side supports (E) to Table top (B) using Bolt(AA), Spring washer(BB) and Flat washer(CC) as Fig.3, don’t tighten them here. Then use Hex wrench (DD) to attach the Side supports (E) to the Bottom support (D) using Bolt (AA), Spring washer (BB) and Flat washer (CC) as Fig.4, and tighten all of them finally.
- Page 4 Step 4: Put the Umbrella hole cap (A) into the Table top (B), adjust the foot pad then complete the installation.
- Page 5 CARE AND MAINTENANCE: To keep your patio furniture looking like new, fabric and frames should be cleaned often with a sponge and water. A protective base coat of mild wax should be applied periodically to the frame. Stubborn stains may require warm soapy water applied with a soft brush. Do not use harsh or abrasive solvents.
- Page 6 CORA DINING CHAIR ARTICLE #113109 Quantity Part Part No. Description P31107A01163 Chair body P31209A01163 Chair leg P00409A01118 Cushion P00604B10301 Lumbar pillow H06060C11 Bolt M6*60 H13001C11 Spring washer M6 H12001C11 Washer M6 H00002C12 M6 Wrench...
- Page 7 Step 1: Connect the Chair body (A) with the Leg (B) using Bolt ( AA), Spring washer (BB) and Washer (CC) as Fig 1, tighten the all the bolts after all 5 sets of bolt attached. Step 2: put the Cushion (C) and the Lumbar pillow (D) onto the assembled chair. CARE AND MAINTENANCE: To keep your patio furniture looking like new, fabric and frames should be cleaned often with a sponge and water.
- Page 8 The item is warranted to be free from defects in material or workmanship for a period of Two (2) year. If any defect is found, please call Sunjoy Industries customer service department at 1-866-578-6569 for help. The manufacturer will not cover transportation or delivery costs, or compensate the individual or any outside party for assembling or disassembling the product.
