MECHANICAL LIFTING EQUIPMENT
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
This handbook contains all the necessary information on how to safely use the mechanical lifting equipment manufactured by:
The reproduction of this document, even partial, without written authorization from OMCN S.p.A. is strictly prohibited.
EQUIPMENT FEATURES
1) Lifting/lowering pedal
2) Rolls
3) Frame
4) Pivoting wheels
5) operating lever
6) safety lever
7) Handle
8) Pedal stop lever
9) Wheel securing device
SPECIFIC USE:
Intended use lists the admitted uses for which the manufacturer designed and constructed the equipment, sensibly foreseeable
improper uses have been listed.
FORESEEN USE:
This mechanical lifting equipment was designed and manufactured to help assembling, disassembling and move shortly truck wheels
that weigh no more than the load capacity.
Load capacity : 200 Kg
The equipment must be operated for the sole use it has been designed for. Any other use is defined irregular thus prohibited.
IMPROPER USE:
It is forbidden to:
 Overload the equipment
 Supporting and/or lifting persons and/or animals
 Supporting and/or lifting a vehicle
 Put more than one wheel at a time on the equipment
 Using the equipment to lift, support and/or transport objects that are not listed in the admitted uses.
24020 VILLA DI SERIO (BG) ITALIA
Via Divisione Tridentina, 23
Tel:035/423.44.11 r.a.
Fax Italia 035/423.44.41 - 035/423.44.42
Fax Export: +39/035/423.44.49
http:// www.omcn.com - http:// www.omcn.it
e-mail: info@omcn.com - e-mail: info@omcn.it
OMCN S.p.A.
1
7
8
4
L388BS002
INSTRUCTIONS FOR USE,
MAINTENANCE AND SPARE
5
2
6
PARTS
Art. 388/B
Art. 388/B
EN
9
3
1

Advertisement

loading

Related Manuals for OMCN 388/B

Summary of Contents for OMCN 388/B

  • Page 1 This handbook contains all the necessary information on how to safely use the mechanical lifting equipment manufactured by: OMCN S.p.A. The reproduction of this document, even partial, without written authorization from OMCN S.p.A. is strictly prohibited. EQUIPMENT FEATURES 1) Lifting/lowering pedal...

  • Page 2: General Safety Rules

    GENERAL SAFETY RULES: OMCN S.p.A. cannot be held responsible for direct or indirect injury or damage to persons, animals or things caused by the failure to observe the instructions contained in this handbook. any tampering or modifications to the equipment automatically and immediately nullifies the guarantee and relieves the manufacturer of any liability for direct or indirect injury caused by such tampering or modifications.
  • Page 3  It is compulsory to check that there are no hazardous conditions for persons at risk during operation. If there are, stop any operations underway immediately and keep people away.  Use only original OMCN spare parts for maintenance operations. The manufacturer cannot be held responsible for any damage caused by the use of unoriginal fittings.
  • Page 4  It is forbidden to use the equipment for washing.  Do not use the equipment in the following cases:  inside freezers,  in environments where potentially explosive atmospheres may develop,  in mines,  on ships,  near food, ...
  • Page 5 Use the knob (1) to adjust the wheel securing device in order to se- cure the wheel to the equipment. Assemble or disassemble the wheel. Move the wheel. The hydraulic equipment is not an internal handling and transport means and must not be used to per- form long movements with a load.

  • Page 6: Routine Maintenance

    ROUTINE MAINTENANCE: To ensure that the machine operates correctly and efficiently, follow the instructions below.  Every time you use it Keep appliance and components clean. Check that securing screws are properly tightened. Check whether operating pedal and safety lever are in perfect working order. ...
  • Page 7 Your attention is drawn to the importance of the check to be made on your equipment periodically. Periodic checks and inspections must always be conducted by specialised OMCN S.p.A. personnel or our specifically trained personnel. FILL IN THE INFORMATION BELOW...
  • Page 8 DECLARACIÓN CE DE CONFORMIDAD con arreglo al Art. 12, paràgrafo 2. de la Directiva 2006/42/CE Noi/We/Wir/Nous/Nosotros: OMCN S.p.A. via Divisione Tridentina 23, 24020 Villa di Serio (Bergamo), ITALIA dichiariamo sotto la nostra esclusiva responsabilità che il prodotto declare, with sole responsibility on our part, that the product erklären unter unserer alleinigen Verantwortung, daß...
