Summary of Contents for Home Decorators Collection AM909-NI
Page 1
USE AND CARE GUIDE HERITAGE POINT LED 25 IN. CEILING FAN Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS...
Table of Contents Table of Contents ............Operation ..............Remote Control Operating Instructions ........Safety Information ............Reverse Switch Operating Instructions ........Warranty ................. Care and Cleaning ............Pre-installation .............. Troubleshooting ............Specifications ................Tools Required ................. Service Parts ............... Hardware Included ..............
The fan must be mounted with a minimum of 7 ft (2.1m) clearance from the trailing edge of the blades to the floor. responsible for this declaration: Model Number: AM909-NI Avoid placing objects in the path of the blades. Company Name: TAL INTERNATIONAL CORPORATION Company Address: 2919 E.
Warranty The manufacturer warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser. The manufacturer warrants the light kit (excluding any glass), to be free from defects in workmanship and material present at time of shipment from the factory for a period of five years after the date of purchase by the original purchaser.
Pre-Installation (continued) HARDWARE INCLUDED HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Part Description Description Quantity Quantity Plastic wire nut Blade attachment screw and fiber washer 1.5V AAA battery Extension cord HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
Installation MOUNTING OPTIONS MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain proper WARNING: To reduce the risk of fire, electric shock, or blade clearance when installing on a steep, sloped ceiling. personal injury, mount the fan to an outlet box marked The maximum angle allowable is 18°...
Assembly Assembling the rear guard on the fan motor assembly □ Remove three rear guard mounting screws (EE) from the rear guard (F) on the top of the fan motor assembly (G). □ Attach the rear guard (F) to the fan motor assembly (G) by tightening the rear guard mounting screws (EE) previously removed.
Page 9
Assembly (continued) Preparing the canopy Preparing the motor □ □ Remove the cotter pin (GG) and clevis pin (HH), and Remove the canopy ring (B) from the canopy (C). loosen the two collar setscrews (II) from the motor collar. □ Remove the two non-slotted canopy mounting screws with lock washers (FF) from the canopy (C), and □...
Assembly — Hanging the Fan Hanging the fan to the mounting Installing the mounting bracket bracket to the electrical box WARNING: To reduce the risk of fire, electric shock or WARNING: The tab in the ring must rest in the groove of other personal injury, mount the fan only to an outlet box or the hanger ball / downrod assembly (D).
Page 11
Assembly — Hanging the Fan (continued) Preparing the receiver and remote control NOTE: The frequencies on your receiver and remote control have been preset at the factory. Before installing the receiver, make sure the dip switches on the receiver and remote control are set to the same frequency.
Page 12
Assembly — Hanging the Fan (continued) Making the electrical connections Ground conductor Black White WARNING: Check to see that all connections are tight, including ground, and that no bare wire is visible at the wire nuts, except for the ground wire. Outlet Box WARNING: To reduce the risk of electric shock, this fan must be installed with an isolating wall control/switch.
Page 13
Assembly — Hanging the Fan (continued) Installing the canopy Outlet box WARNING: Make sure the tab on the mounting bracket (A) properly sits in the groove in the hanger ball / downrod assembly (D) before attaching the canopy (C) to the mounting bracket (A) by turning the canopy (C) until it drops into place.
Assembly — Attaching the Fan Blades Attaching the blades to the Fastening the blade blade arms assemblies to the motor □ Attach the blades (H) to the blade arms (I) using the WARNING: To reduce the risk of personal injury, do not three blade attachment screws and fiber washers bend the blade arms (I) while installing, balancing the blades (BB).
Assembly — Installing the Light Kit Attaching the light kit mounting Attaching the LED light kit plate to the mounting ring and glass shade □ Remove one of the three light kit mounting plate CAUTION: Before starting installation, disconnect the screws (QQ) from the mounting ring (RR) and loosen power by turning off the circuit breaker or removing the fuse the other two screws.
Assembly — Installing the Front guard Attaching the front guard to the fan motor assembly CAUTION: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at the fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock.
Operation REMOTE CONTROL OPERATING INSTRUCTIONS REMOTE CONTROL OPERATING INSTRUCTIONS - Press and release the button to turn the fan on or off. - Press and release 1 time - turns the fan on high speed. - Press and release 2 times - turns the fan on medium speed. - Press and release 3 times - turns the fan on low speed.
Operation (continued) REVERSE SWITCH OPERATING INSTRUCTIONS REVERSE SWITCH OPERATING INSTRUCTIONS The reverse switch is located on the top of the motor housing. Slide the switch to the left for warm weather operation. Slide the switch to the right for cool weather operation. NOTE: Wait for the fan to stop before reversing the direction of the blade rotation.
Troubleshooting WARNING: Make sure the power is off at the electrical panel box before you attempt any repairs. Refer to step 8 “Making the electrical connections” on page 12. Problem Problem Solution Solution □ Check the main and branch circuit fuses or breakers. □...
Service Parts Part Part Description Description Part Part Description Description Mounting bracket (preassembled) Plastic wire nut Blade attachment screws and fiber washers Canopy ring (preassembled) 1.5V AAA battery Canopy Extension cord Hanger ball / downrod assembly Coupling cover Rear guard Fan motor assembly Blade Blade arm...
Page 21
Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
