- Page 1 User manual Atria Atria Duo Atria Duo Optimum Atria Optimum Comfort Diplomat Diplomat Duo Diplomat Duo Optimum Diplomat Duo Optimum G2 Diplomat Optimum Diplomat Optimum G2 086U6297 Rev. 6 EN...
- Page 2 If these instructions are not followed during installation and service, Thermia Värme ABliability according to the applicable war‐ ranty is not binding. Thermia Värme AB retains the right to make changes to com‐ ponents and specifications without prior notice. © 2010 Copyright Thermia Värme AB.
-
Page 3: Table Of Contents
Contents Important information.................. 3 Safety precautions..................4 Protection....................5 About your heat pump................. 6 Principles of function..................6 Components....................7 Outdoor and defroster function..............10 Passive cooling function................12 Speed (rpm) control..................12 HGW technology..................12 Auxiliary heat..................... 13 Water heater....................14 Control computer.................. - Page 4 Room sensor....................39 Troubleshooting..................41 Alarm......................41 Terms and abbreviations................43 Default setting in the control computer............45 References..................... 46 11.1 Check list....................46 11.2 Installation carried out by:................. 47 2 – 086U6297 Rev. 6 EN...
-
Page 5: Important Information
Important information Note! If the installation is not used during the winter, the heating system must be drained of water, otherwise there is a risk of frost damage to the installation. The system can be considered maintenance free but certain checks are necessary. -
Page 6: Safety Precautions
Safety precautions 1.1.1 Installation och underhåll DANGER! Only authorized installers may install, operate and carry out maintenance and repair work on the heat pump. DANGER! Only authorized electricians may modify the electrical installation. DANGER! DANGER TO LIFE! Only authorized refrigeration technicians may work on the refrigerant circuit. -
Page 7: Protection
Protection 1.2.1 Korrosionsskydd Due to the risk of corrosion, avoid using different types of sprays in the vicinity of the heat pump. This particularly applies to: • Solvents • Chlorinated cleaning agents • Paints • Adhesives User manual 086U6297 Rev. 6 EN – 5... -
Page 8: About Your Heat Pump
About your heat pump Principles of function A heat pump utilises the free energy from the sun and that is also found in a natural heat source, such as rock, ground, ground water or air. The heat pump can be compared to a reversed refrigerator; in a refrigerator heat is transferred from the inside of the refrigerator to the outside, whereas in a heat pump, the solar energy that is stored in a heat source is transferred to the inside of the house. -
Page 9: Components
separate fluid circuits are required. The figure below shows the different circuits and how they work together in the transfer of heat energy. A fluid (brine) (A) filled hose is lowered into a lake, buried in the ground or low‐ ered into bedrock. - Page 10 Heat enters the house via a water borne heating system. The heat pump supplies as much of the heat demand as possible before auxiliary heating is engaged and assists. 8 – User manual 086U6297 Rev. 6 EN...
- Page 11 The heat pump unit consists of five basic units: Symbol explanation Heat pump unit • Compressor • Stainless steel heat exchanger • Circulation pumps for brine and heating systems • Valves and safety equipment for cooling systems and corresponding electrical components. Water heater •...
-
Page 12: Outdoor And Defroster Function
Outdoor and defroster function Atria models are equipped with an outdoor unit that uses air as a heat source down to -20°C. The outdoor unit has a coil where brine recovers free energy from the outside air. It also has a fan that increases the airflow through the coil. - Page 13 • The shunt valve closes the flow of hot brine from the defrosting tank. • Operation returns to normal. The unit (Atria models) consists of the following basic components: Heat pump unit • Compressor • Stainless steel heat exchanger •...
-
Page 14: Passive Cooling Function
Passive cooling function Note! Not sold on all markets. Heat pump Comfort is equipped with an extra heat exchanger to use the passive cooling effect from the brine. Because the temperature in the collector (borehole or equivalent) is lower than the indoor temperature, the temperature difference can be exploited to cool the radiator circuit. -
Page 15: Auxiliary Heat
AUTO is selected and that at least one additional step is permitted. Atria models The auxiliary heater for 400V 3N heat pumps is made up of an electric heating element on the supply line that has three outputs, AUX. HEAT 1, AUX. -
Page 16: Water Heater
AUTO is selected and that at least one additional step is permitted. Water heater Thermia heat pumps Diplomat, Diplomat Optimum, Diplomat Optimum G2 and Comfort supplied with an integrated 180 litre water heater. They 14 – User manual 086U6297 Rev. 6 EN... - Page 17 are equipped with a TWS coil that means more effective heat transfer and efficient layering of the water in the water heater. Symbol explanation Tap hot water Peak temperature sensor Water heater TWS coil Start temperature sensor Supply line to TWS coil Return line from TWS coil Cold water line Water heater for Diplomat mod‐...
- Page 18 The hot water heaters for Atria models differ from the other heat pumps in that the function for defrosting the outdoor unit is different. The only difference between an Atria/Atria Optimum and an Atria Duo/ Atria Duo Optimum is that the water heater is integrated in Atria/Atria Optimum and a separate unit for Atria Duo/Atria Duo Optimum.
-
Page 19: Control Computer
Control computer Control system The heat pump has an integrated control system which automatically calculates the heat demand in the house to ensure that the correct amount of heat is produced and emitted where necessary. There are many different values (parameters), which are required in order to do the calculation of the heat demand. - Page 20 tings and values. During operation, the display always shows the set ROOM value, the operating mode and the status of the heat pump. ROOM 20°C NO HEAT DEMAND OPERAT. AUTO Figure 4. Display, keypad and indicator. (20°C) Position Description The display text and symbols are only shown as examples. Cer‐ tain symbols cannot be displayed at the same time.
-
Page 21: Display
• Operating time • Menu system language The INFORMATION menu is opened by pressing the left or right buttons. The indicator at the bottom of the control panel has three modes: • Not lit, means that the heat pump is not powered. •... - Page 22 3.2.1 Operating modes Table 1. Shows the set operating mode of the heat pump. Operating mode Meaning The installation is fully switched off. This mode is also (OFF) used to acknowledge certain alarms. Caution! If the operating mode OFF is to be used for long periods during the winter, the water in the heating system in the heating system must be drained, otherwise there is...
- Page 23 DEFROST Appears when defrosting is activated (applies to Atria models). Displayed when the fan is active (applies to Atria mod‐ els). L = Low speed, H = High speed COOLING Displayed if cooling is produced.
- Page 24 COOLING A Displayed if cooling is active. DEFROST X(Y) Displayed when defrosting is active. X shows the actual reached temperature. Y shows at which temperature defrost is complete (applies to Atria models). 22 – User manual 086U6297 Rev. 6 EN...
-
Page 25: Trimming The Heating System
Trimming the heating system To obtain a heating system balance and obtain an even and comfortable indoor temperature, you must adjust your heating system according to the example below. Note! Adjust the heating system during the winter to obtain the greatest possible output. - Page 26 other rooms so that their indoor temperatures are the same tem‐ perature or lower than the reference room. 24 – User manual 086U6297 Rev. 6 EN...
-
Page 27: Instructions
• Calculate the heat pump’s total energy consumption • For Atria, Atria Duo: defrost the outdoor unit Setting operating mode In the control computer you can choose between five operating modes: To change the operating mode: Press either the right or left button once to open the INFORMA‐... -
Page 28: Adjusting Curve Values
Raise or reduce the ROOM value using the up or down buttons to change the indoor temperature. Wait ten seconds or press the left button once to exit the menu. Adjusting CURVE values To change the CURVE value: Press either the right or left button once to open the INFORMA‐ TION menu. -
Page 29: Setting Heatstop
Press the down button to move the cursor to the HEATCURVE menu option. Open the menu by pressing the right button once. The cursor is at the CURVE value. Press the down button to move the cursor to MIN. Open your selection by pressing the right button once. The text row MIN is marked. -
Page 30: Calculating Energy Consumption
Open your selection by pressing the right button once. A graph of the hot water temperature over the last hour is shown. Press the left button three times to exit the menu. To view the TEMPERATURE history: Press either the right or left button once to open the INFORMA‐ TION menu. - Page 31 The indicated outputs include circulation pumps. Table 4. Energy consumption Diplo‐ mat, Diplo‐ mat Duo Under 1.02 kW 1.45 kW 1.82 kW 2.41 kW 2.83 kW 3.99 kW floor heating Radiators 1.38 kW 1.84 kW 2.33 kW 3.04 kW 3.60 kW 5.07 kW User manual 086U6297 Rev.
- Page 32 Table 5. Energy consumption Diplomat Optimum Diplomat Duo Opti‐ Diplomat Optimum Diplomat Duo Opti‐ mum G2 Under floor 1.37 kW 1.74 kW 2.24 kW 2.64 kW 3.92 kW heating Radiators 1.76 kW 2.25 kW 2.85 kW 3.41 kW 5.0 kW Table 6.
- Page 33 Multiply the number of ADD.HEAT 2 hours by 6. Note the result. Add up the multiplied values to obtain the total energy consump‐ tion. Atria models The energy consumption calculation is difficult to specify exactly, but the average output for a normal house with normal hot water consumption in the following tables gives a relatively accurate result for each heat pump and heating system.
- Page 34 The specified outputs include the circulation pumps and also the outdoor unit’s fan. Table 7. Energy consumption Atria models 6 Under floor 1.70 kW 2.30 kW 2.89 kW 3.18 kW heating Radiators 2.30 kW 2.80 kW 3.59 kW 4.09 kW Table 8.
-
Page 35: Manual Defrost, Outdoor Unit
Manual defrost, outdoor unit If the heat pump requires defrosting you can run a defrosting procedure manually from the control computer. To defrost manually: Press either the right or left button once to open the INFORMA‐ TION menu. The cursor is in the OPERATION menu option. Press the down button to move the cursor to the DEFROST menu option. -
Page 36: Regular Checks
Regular checks Checking operation During normal operation, the alarm indicator lights green continuously to show that everything is OK. When the alarm is triggered, it flashes green at the same time as a text message is shown in the display. LARM LÅGTRYCK LÖST Figure 5. -
Page 37: Checking The Water Level In The Heating System
For Atria, Atria Duo with pressurized brine circuit the manometer on the expansion tank must show approx. 1.0 bar. Always call your installer for refilling of refrigerant. -
Page 38: Checking The Safety Valve
very hard water) that it is not suitable for filling the heating system. If unsure, contact your installer. Note! Do not use any additives for water treatment in the heating system’s water! Note! The closed expansion tank contains an air filled bladder that absorbs variations in the heating system’s volume. -
Page 39: Cleaning The Strainer For The Heating System
Cleaning the strainer for the heating system Note! The heat pump must be switched off at the main switch before cleaning can be started. Note! The heating circuit’s strainer must be cleaned twice a year after installation. The interval can be extended if there is evidence that cleaning twice a year is not necessary. -
Page 40: Cleaning The Strainer For The Brine Circuit
Cleaning the strainer for the brine circuit Note! The heat pump must be switched off at the main switch before cleaning can be started. Note! The brine circuit’s strainer must be cleaned twice a year after installation. The interval can be extended if there is evidence that cleaning twice a year is not necessary. -
Page 41: Accessories
Accessories Room sensor Contact your installer if you wish to supplement your heat pump instal‐ lation with a room sensor. The room sensor is an accessory that is used to set a desired indoor temperature. It can be installed in the house where the room tempera‐ ture is relatively constant, not in a hallway, kitchen or a room with alter‐... - Page 42 ROOM FACTOR Desired room Actual room Set point for temperature, °C temperature, °C supply line, °C In the event of a surplus of heat the conditions are the opposite: Table 10. In the event of a heating surplus ROOM FACTOR ROOM FACTOR Actual room Set point for temperature, °C supply line, °C...
-
Page 43: Troubleshooting
Fault on sensor for start temperature. No hot water pro‐ duction. DEFROST SENSOR Defrost sensor fault. Heat and hot water production is instead controlled to the outdoor sensor's value (applies to Atria models). SENSOR COOLING Sensor fault. Cooling function stops. User manual 086U6297 Rev. 6 EN – 41... - Page 44 Message Meaning ERR PHASE SEQ. Alarm that indicates that there is an incorrect phase sequence to the compressor. Only display and only the first 10 minutes. HIGH RETURN Alarm that indicates that high return temperature pre‐ vents the compressor’s operation. In event of alarm the heat pump will if possible supply heating to the house, primarily with the compressor, secondarily with the additional heater.
-
Page 45: Terms And Abbreviations
Terms and abbreviations Table 11. Terms and abbreviations Term Explanation Evaporator In the evaporator, energy is retreived from the heat source and the refrigerant passing through the evapora‐ tor turns to gas. De-superheater In the de-superheater part of the total heating output is released (approx. - Page 46 Term Explanation Control computer The control computer controls the entire heating instal‐ lation. All settings are stored and the history of the instal‐ lation is registered here. The control computer’s settings can be changed via the display. Room If ROOM shows 20°C the heat curve is unaffected. If ROOM shows higher or lower, this indicates that the heat curve has been adjusted up or down to change the indoor temperature.
-
Page 47: Default Setting In The Control Computer
Default setting in the control computer The first column in the table below shows the parameters that can be adjusted by the User. The second column shows settings made at the factory, and the third column the settings made by the installation con‐ tractor in connection with installation of the heat pump. -
Page 48: References
References 11.1 Check list Installed model: ..............• Setting up Surface adjustment • Piping installation Leak test Bleeding Open radiator valves Function test safety valve • Electrical Installation Direction of rotation of the compressor Outdoor sensor Accesso‐ ries: ............... • Brine installation Type of brine: ............ -
Page 49: Installation Carried Out By
11.2 Installation carried out by: Piping installation Date ............Company ............Name ............Tel. No............Electrical Installation Date ............Company ............Name ............Tel. No............System adjustment Date ............Company ............Name ............User manual 086U6297 Rev. 6 EN – 47... - Page 50 System adjustment Tel. No............48 – User manual 086U6297 Rev. 6 EN...
- Page 51 086U6297 Rev. 6 EN...
