Technical description
Atlas & Calibra
www.thermia.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Atlas and is the answer not in the manual?

Questions and answers

Summary of Contents for Thermia Atlas

  • Page 1 Technical description Atlas & Calibra www.thermia.com...
  • Page 2 Thermia AB is not liable or bound by warranty if these instructions are not adhered to during installation or service. The English language is used for the original instructions. Other languages are a translation of the original instructions. (Directive 2006/42/EC)
  • Page 3: Table Of Contents

    Estimated flow and pressure for heating circuit, Atlas 12 ....... .
  • Page 4: Transportation, Space Requirement And Recommended Location

    Technical description Atlas & Calibra Transportation, space requirement and Recommended location Transportation The heat pump must not be transported lying down! Maximum tilt 45 ° Max 45 Atlas & Calibra Atlas Duo & Calibra Duo 115-159kg! 145-199kg! BWCA01TD0202 Thermia AB...
  • Page 5: Space Requirement And Recommended Location

    Technical description Atlas & Calibra Space requirement and recommended location Avoid placing the heat pump in a corner or near a bedroom. The surrounding walls can amplify the sound from the heat pump. 300 mm 300 mm 300 mm 40°C 10 mm 0°C...
  • Page 6 Technical description Atlas & Calibra When the heat pump is in position, remove the transport safety. (If the heat pump should be moved further, put back the transport safety screw.) Make sure all parts of the transport safety is removed! The heat pump should be placed on a stable floor with a floor well (so any condensation may drain from the condensation hole in the bottom of the heat pump), preferably a concrete floor.
  • Page 7: Heat Pump Data, Dimensions And Connections

    Cold water line, 22 mm Lead-in for supply, sensor and communication ca- bles Top hood, Atlas (accessory for Calibra) The brine lines (1) and (2) can be connected on either the left or right-hand sides or to the two knock out holes on the top.
  • Page 8: Atlas Duo And Calibra Duo

    Connection for bleed valve, 28 mm Lead-in for supply, sensor and communication cables Top hood, Atlas (accessory for Calibra) The brine lines (1) and (2) can be connected on either left or right-hand side or to the two knock out holes on the top.
  • Page 9: Envelope For Atlas And Calibra

    Technical description Atlas & Calibra Envelope for Atlas and Calibra Calibra 7 Calibra12 Atlas 12 R410A T brine °C T water °C T brine ° Thermia AB BWCA01TD0202...
  • Page 10 Technical description Atlas & Calibra Atlas 18 R410A T brine °C T water °C T brine ° BWCA01TD0202 Thermia AB...
  • Page 11: Atlas 12 400V & 230V

    Technical description Atlas & Calibra Atlas 12 400V & 230V Technical data, Atlas 12 Atlas 12 400V and 230V Unit 3-12 kW Refrigerant Type R410A 1,40 Amount 2088 tons 2923 equivalent Design pressure Bar (g) Compressor Type Scroll Electrical data, 400V, 3-N...
  • Page 12: Estimated Flow And Pressure For Brine For Atlas 12

    400V versions: The power supply and the frequency converter for the compressor are pow- ered by L1, L2 and L3. Control and circulation pumps are operated with L1. Meets IEC61000-3-12 at Ssc connection point <1.3 MVA for Atlas 12 and for Atlas 18 <2.1 MVA without action 230V versions: The feeding for auxilliary heater and compressor can be physically separated.
  • Page 13: Estimated Flow And Pressure For Heating Circuit, Atlas 12

    0,50 0,40 0,30 Flow l/s Available 0,20 pressure kPa 0,10 0,00 Estimated flow and pressure for heating circuit, Atlas 12 Flow heating circuit and external available pressure B0W35 ( Δt 5 ) 0,60 0,50 0,40 0,30 Flow l/s 0,20 Available...
  • Page 14 Technical description Atlas & Calibra Flow heating circuit and external available pressure B0W55 ( Δt 8 ) 0,35 0,30 0,25 0,20 Flow l/s 0,15 Available pressure kPa 0,10 0,05 0,00 BWCA01TD0202 Thermia AB...
  • Page 15: Supply Line Temp 35° And 55°C For Atlas 12 And Atlas Duo 12

    Technical description Atlas & Calibra Supply line temp 35° and 55°C for Atlas 12 and Atlas Duo 12 Heating capacity with a desired supply line temperature at 35°C at different compressor speed and brine temperature. At higher brine temperatures max compressor speed may be automatically reduced to below 5300 max RPM...
  • Page 16 Technical description Atlas & Calibra Heating capacity with a desired supply line temperature at 55°C at different compressor speed and brine temperature. At higher brine temperatures max compressor speed may be automatically reduced to below 5300 max RPM 14,00 12,00...
  • Page 17: Atlas 18 400V

    Technical description Atlas & Calibra Atlas 18 400V Technical data, Atlas 18 Atlas 18 400V and 230V Unit 4-18 kW Refrigerant Type R410A 1,95 Amount tons 4,072 equivalent Design pressure Bar (g) Compressor Type Scroll Electrical data, 400V, 3-N Mains power supply...
  • Page 18: Estimated Flow And Pressure For Brine For Atlas 18

    400V versions: The power supply and the frequency converter for the compressor are pow- ered by L1, L2 and L3. Control and circulation pumps are operated with L1. Meets IEC61000-3-12 at Ssc connection point <1.3 MVA for Atlas 12 and for Atlas 18 <2.1 MVA without action 230V versions: The feeding for auxilliary heater and compressor can be physically separated.
  • Page 19: Estimated Flow And Pressure For Heating Circuit, Atlas 18

    Technical description Atlas & Calibra Estimated flow and pressure for heating circuit, Atlas 18 Flow heating circuit and external available pressure B0W35 ( Δt 5 ) 1,00 0,90 0,80 0,70 0,60 0,50 Flow l/s 0,40 0,30 Available pressure kPa 0,20...
  • Page 20: Supply Line Temp 35° And 55°C For Atlas 18 And Atlas Duo 18

    Technical description Atlas & Calibra Supply line temp 35° and 55°C for Atlas 18 and Atlas Duo 18 Heating capacity with a desired supply line temperature at 55° at different compressor speed and brine temperatures. 20,00 18,00 16,00 14,00 12,00...
  • Page 21 Technical description Atlas & Calibra Heating capacity with a desired supply line temperature at35° at different compressor speed and brine temperatures. 22,00 20,00 18,00 16,00 14,00 12,00 1200 rpm 2110 rpm 10,00 3200 rpm 4350 rpm 8,00 5300 rpm 6,00...
  • Page 22: Calibra 7 400V & 230V

    Technical description Atlas & Calibra Calibra 7 400V & 230V Technical data, Calibra 7 Calibra 7 400V and 230V Unit 1,5-7 kW Refrigerant Type R410A 0,95 Amount tons 198,3 equivalent Design pressure Bar (g) Compressor Type Scroll Electrical data, 400V, 3-N...
  • Page 23 400V versions: The power supply and the frequency converter for the compressor are pow- ered by L1, L2 and L3. Control and circulation pumps are operated with L1. Meets IEC61000-3-12 at Ssc connection point <1.3 MVA for Atlas 12 and for Atlas 18 <2.1 MVA without action 230V versions: The feeding for auxilliary heater and compressor can be physically separated.
  • Page 24: Estimated Flow And Pressure For Brine, Calibra 7 And Calibra Duo 7

    Technical description Atlas & Calibra Estimated flow and pressure for brine, Calibra 7 and Calibra Duo 7 Flow brine and external available pressure B0W35 ( Δt 3 ) 0,50 0,45 0,40 0,35 0,30 0,25 0,20 Flow l/s 0,15 Available 0,10...
  • Page 25: Estimated Flow And Pressure For Heating Circuit, Calibra 7 And Calibra Duo 7

    Technical description Atlas & Calibra Estimated flow and pressure for heating circuit, Calibra 7 and Calibra Duo 7 Flow heating circuit and external available pressure B0W35 ( Δt 5 ) 0,45 0,40 0,35 0,30 0,25 0,20 Flow l/s 0,15 Available...
  • Page 26: Supply Line Temp 35°C And 55°C For Calibra 7, Calibra Duo 7

    Technical description Atlas & Calibra Supply line temp 35°C and 55°C for Calibra 7, Calibra Duo 7 Heating capacity with a desired supply line temperature at 55°C at different compressor speed and brine temperature. 8,00 7,00 6,00 5,00 1200 rpm...
  • Page 27 Technical description Atlas & Calibra Heating capacity with a desired supply line temperature at 35°C at different compressor speed and brine temperature. 9,00 8,00 7,00 6,00 5,00 1200 rpm 1900 rpm 4,00 2600 rpm 3500 rpm 4300 rpm 3,00 2,00...
  • Page 28: Calibra 12 400V & 230V

    Technical description Atlas & Calibra Calibra 12 400V & 230V Technical data, Calibra 12 Calibra 12 400V and 230V Unit 3-12 kW Refrigerant Type R410A 1,40 Amount tons 292,3 equivalent Design pressure Bar (g) Compressor Type Scroll Electrical data, 400V, 3-N...
  • Page 29: Estimated Flow And Pressure For Brine, Calibra 12 And Calibra Duo 12

    400V versions: The power supply and the frequency converter for the compressor are pow- ered by L1, L2 and L3. Control and circulation pumps are operated with L1. Meets IEC61000-3-12 at Ssc connection point <1.3 MVA for Atlas 12 and for Atlas 18 <2.1 MVA without action 230V versions: The feeding for auxilliary heater and compressor can be physically separated.
  • Page 30: Estimated Flow And Pressure For Heating Circuit, Calibra 12 And Calibra Duo 12

    Technical description Atlas & Calibra Flow brine and external available pressure B0W55 ( Δt 3 ) 0,70 0,60 0,50 0,40 0,30 Flow l/s Available 0,20 pressure kPa 0,10 0,00 Estimated flow and pressure for heating circuit, Calibra 12 and Calibra Duo 12 Flow heating circuit and external available pressure B0W35 ( Δt 5 )
  • Page 31 Technical description Atlas & Calibra Flow heating circuit and external available pressure B0W55 ( Δt 8 ) 0,35 0,30 0,25 0,20 Flow l/s 0,15 Available pressure kPa 0,10 0,05 0,00 Thermia AB BWCA01TD0202...
  • Page 32: Supply Line Temp 35° And 55°C For Calibra12 And Calibra Duo 12

    Technical description Atlas & Calibra Supply line temp 35° and 55°C for Calibra12 and Calibra Duo 12 Heating capacity with a desired supply line temperature at 35°C at different compressor speed and brine temperature. At higher brine temperatures max compressor speed may be automatically reduced to below 5300 max RPM...
  • Page 33 Technical description Atlas & Calibra Heating capacity with a desired supply line temperature at 55°C at different compressor speed and brine temperature. At higher brine temperatures max compressor speed may be automatically reduced to below 5300 max RPM 14,00 12,00...
  • Page 34 Technical description Atlas & Calibra BWCA01TD0202 Thermia AB...
  • Page 35 Technical description Atlas & Calibra Thermia AB BWCA01TD0202...
  • Page 36 Internet: www.thermia.com Thermia can accept no responsibility for possible errors in catalogues, brochures and other printed material. Thermia reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequential changes being necessary in specifications already agreed. All trademarks in this material are property of the respective companies.
