INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
NOTICE: DO NOT discard this manual!
MERIDIAN
SERIES
Models:
Models:
DBDV36IN
DBDV36IL
DBDV42IN
DBDV42IL
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certifi ed kit is used.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See appliance installation manual for additional
Commonwealth of Massachusetts requirements.
Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner's Manual • 2397-981 • 5/16
Owner's Manual
Care and Operation
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
DANGER
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DBDV36IL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Majestic DBDV36IL

  • Page 1 In the Commonwealth of Massachusetts installation must be performed by a licensed plumber or gas fi tter. See appliance installation manual for additional Commonwealth of Massachusetts requirements. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 2: Welcome

    00,000 00,000 00,000 00,000 MIN. MIN. INPUT INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 Serial Serial XXXXXXXX XXXXXXXX ORIFICE ORIFICE SIZE: SIZE: #XXXXX #XXXXX #XXXXX #XXXXX (Serie): (Serie): Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 3: Table Of Contents

    C. Contact Information ......26  = Contains updated information. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 4: Limited Lifetime Warranty

    3 years Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645H 10/15 Page 1 of 2 Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 5 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645H 10/15 Page 2 of 2 Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 6: Product Specifi C Information

    Hearth & Home DBDV42IL (LP) (0-2000 FT) 34,000 17,000 Technologies suggests NFI certifi ed or factory trained professionals, or technicians supervised by an NFI certifi ed professional (www.nfi certifi ed.org). Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 7: Important Safety And Operating Information

    • Keep remote controls out of reach of children. • Never leave children alone near a hot fi replace, whether operating or cooling down. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 8: General Operating Parts

    30 degrees or more depending on the thermometer settings and material characteristics being measured. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 9 Sugges ons on how to further reduce TV temperatures: Increase “A” dimension. Increase “C” dimension, however, increasing “B” dimension beyond maximum recommended typically results in higher temperatures. Figure 3.4. Good Faith TV Guidelines Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 10: Before Lighting Appliance

    • Ensure that the glass is sealed and in the proper position and that the integral barrier is in place. WARNING! Risk of Fire or Asphyxiation! DO NOT op- erate fi replace with fi xed glass assembly removed. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 11: Lighting Instructions (Ipi)

    Keep burner and control compartment clean. See installation and operating instruc- Propane Installation code, CSA B149.1. tions accompanying appliance. For additional information on operating your 593-913i Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 12: Appliance Break-In

    • Some people may be sensitive to smoke and odors. NOTICE: Batteries should only be used as a power source • Smoke detectors may activate. in the event of an emergency such as an outage. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 13: Operation During A Power Outage (Ipi Plus)

    Slide the ON/REMOTE/OFF switch to the REMOTE position. Remove the batteries from the battery tray. Replace door or decorative front on appliance. CONTROL CAVITY VALVE 3.5 Control Cavity Location Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 14: Detailed Component Operating Instructions - Intellifi Re™ Plus

    Section 3.H. Detailed instructions are in- cluded with the fan kit. SELECTOR SWITCH FLAME HI/LOW STATUS NG/LP GAS-TYPE SWITCH INDICATOR LED SELECTOR SWITCH Figure 3.6 Control Module Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 15: Maintenance And Service

    CAUTION! Risk of Burns! The fi replace shall be turned off and cooled before servicing. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 16: Maintenance Tasks - Qualifi Ed Service Technician

    (summer months, vacations/trips, etc), to prevent unin- tended operation: • Remove batteries from remote controls. • Unplug 6 volt transformer plug on IPI models. • Unplug battery backup from control module. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 17 • Inspect pilot fl ame pattern and strength. See Figure 4.2 for proper pilot fl ame pattern. Clean or replace orifi ce spud as necessary. Figure 4.3 Burner identifi cation Examples Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 18: Frequently Asked Questions And Troubleshooting

    Some optional control systems available with IPI models may allow pilot fl ame to continually? remain lit. Contact your dealer for additional information regarding operation and troubleshooting. Visit www.majesticproducts.com to locate a dealer. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 19: Troubleshooting

    D. Pilot valve solenoid. Verify that 1.5 to 1.8 VDC is supplied to pilot solenoid from module. If below 1.5 volts, replace module. If 1.5 volts or greater, replace valve. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 20 fi ne steel wool to remove any contaminants that may have accumulated on fl ame sensing rod. Verify continuity with a multi-meter with ohms set at lowest range. Replace pilot if any damage is detected. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 21: Reference Materials

    Optional Refractory An optional refractory kit is available for this appliance. Contact your dealer to order. A qualifi ed service techni- cian may install the optional refractory kit. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 22: Service Parts

    Burner Skirt 2208-102 Base Pan Assembly 2397-024 Valve Assembly Refer to valve page Glass Assembly GLA-6000G Junction Box (Plastic) 4021-013 Additional service part numbers appear on following page. 6/16 Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 23 Burner Skirt 2208-102 Base Pan Assembly 2398-024 Valve Assembly Refer to valve page Glass Assembly GLA-950TR Junction Box (Plastic) 4021-013 Additional service part numbers appear on following page. 6/16 Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 24 582-851 **Fuse for battery pack can be sourced locally, not a warranty item. Specs are 250v, 1A fuse, 3/4” long Additional service part numbers appear on following page. Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 25 Conversion Kit NG DBDV42IN DBDV42NGK DBDV36IN DBDV36LPK Conversion Kit LP DBDV42IN DBDV42LPK Ori ce, Pilot NG 593-528 Ori ce, Pilot LP 593-527 Regulator NG NGK-DXV-50 Regulator LP LPK-DXV-50 Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
  • Page 26: Contact Information

    5941237, 6006743, 6019099, 6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7098269, 7258116, 7470729, 8147240 or other U.S. and foreign patents pending. 2000-945C Printed in U.S.A. - Copyright 2016 Majestic • DBDV36IN, DBDV36IL, DBDV42IN, DBDV42IL Owner’s Manual • 2397-981 • 5/16...
