3. Technical specifications
(continuation)
3.7. Firmware · Upgradable via RS485
or UART/TTL
3.8. Limitations
ULP is engineered to be a robust device with
minimal downtime. This new shape has been
designed for optimum water spillage which implies
lower probability of ice formation. Frost might
affect measurements if it blocks the wave path.
The input wires are protected by Transient Voltage
Suppression (TVS) diodes. Also, the instrument
body is built in Polyamide.
3.9. Quality control
Every single unit is automatically calibrated on a
wind tunnel. A Q/C report for both module and
angle is generated and keptin our files. Standard
deviation is checked to warranty that each unit is
been calibrated to the hightest standards.
4. Configuration options
baudrate 2400 to 115200 (8n1) bauds
output rate: 0.1 to 20 Hz.
The Ultrasonic ULP can be set up by using a special
App made by Calypso Instruments.
In order to use the APP you should download the
following documentation:
Ultrasonic ULP configurator.exe
ULTRASONIC ULP
Main screen.
Image 8.
ULTRASONIC ULP
