- Page 1 Using PictureMate With a Computer...
- Page 2 The steps in this booklet tell you how and when to connect. View the on-screen User’s Guide . Click PictureMate User’s Guide right on your computer screen for steps on using PictureMate with your computer. It’s your comprehensive guide to PictureMate.
-
Page 3: Installing Software And Connecting Picturemate
® For Macintosh, see page 9. Installing PictureMate for Windows First make sure PictureMate is NOT CONNECTED to your computer, and REMOVE your memory card, if it’s inserted. Then: 1. Press the P button to turn on PictureMate. 2. Turn on your computer. - Page 4 After a moment, you see this screen: 4. Click Next...
- Page 5 Note: If you see a screen like this, remove your memory card from PictureMate and click the in the upper right corner to close the screen, if necessary. Note: If you see a New Hardware Found message at the bottom of your screen, click the the box to close it.
- Page 6 5. When you see this screen, read the license agreement and click AGREE You see this message: 6. Click to begin installing your software.
- Page 7 After a moment, you see this screen: 7. Make sure PictureMate is turned on, then connect the square end of your USB cable to the the flat end of the USB cable to any USB port on your computer. Make sure the handle is all the way down in back port on the back of PictureMate.
- Page 8 Windows installs your software. 8. When you see this screen, click non-photo printing. If PictureMate is your only printer, and you only print photos, click Continue with the instructions in the next section. if you have another printer for...
- Page 9 Installing Additional Software for Windows 1. When you see a message that your printer driver was successfully installed, click Next You see the Optional Software screen: 2. Click Epson Software Film Factory screen and follow the on-screen instructions. Note: If you are asked if you want to install QuickTime, on-screen instructions.
- Page 10 6. Follow the on-screen instructions to register PictureMate. 7. Remove and store your PictureMate CD, then restart your computer. You’re ready to print your photos! Insert your memory card or open your photo file on your computer, as described in the on-screen User’s Guide.
- Page 11 1. If you inserted a memory card, remove it from PictureMate. 2. Connect the square end of your USB cable to the of PictureMate. Then connect the flat end of the USB cable to any open USB port on your Macintosh.
- Page 12 Note: If you have any problems installing the PictureMate software, see page 16. 6. Double-click the Epson . You see a screen reminding you to connect PictureMate to Epson your Macintosh. 7. Click Next 8. When you see this screen, read the license agreement and click...
- Page 13 You see the Install Menu: 9. Click Install Printer Driver and Utilities instructions to install several programs. You’ll need to enter your password, accept license agreements, and click several times as you install. Quit 10. Continue with the instructions in the next section to install additional software.
- Page 14 Installing Additional Software for Macintosh 1. When you return to the Install Menu, click You see this menu: 2. Click Epson Software Film Factory screen and follow the on-screen instructions. 3. Click Epson PhotoCenter Link screen and click 4. When you return to the Optional Software menu shown above, click...
- Page 15 6. When you’re done installing software, click appears. 7. Follow the on-screen instructions to register PictureMate. 8. Remove and store your PictureMate CD, then restart your Macintosh. After you finish installing software, you must select PictureMate as your Macintosh printer. Follow the instructions below.
- Page 16 2. If PictureMate 2005 and click 2005 If it doesn’t appear, make sure PictureMate is turned on and connected to your Macintosh, then click 3. If it isn’t already selected at the top of the screen, choose EPSON USB 4. Click...
- Page 17 You’re ready to print your photos! Insert your memory card or open your photo file on your Macintosh, as described in the on-screen User’s Guide. Double-click the icon on your screen to open PictureMate User’s Guide the User’s Guide.
- Page 18 If you’re printing over a network, see your on-screen User’s Guide. Epson and PictureMate are registered trademarks of Seiko Epson Corporation. Epson Store and Epson PhotoCenter are service marks and Epson Software is a trademark of Epson America, Inc. General Notice: Other product names used herein are for identification purposes only and may be trademarks of their respective owners.
-
Page 19: Where To Get Help
Where To Get Help If you need additional help with PictureMate, see “Where To Get Help” in the Using PictureMate Without a Computer book. PictureMate Accessories You can purchase a PictureMate Print Pack (with PictureMate Photo Paper and a PictureMate Photo Cartridge), a USB cable, and other PictureMate accessories from an authorized Epson dealer.
