Install the Ink Tanks

Install the 6 ink tanks by following the guidance displayed on the printer display.
1
Press the power button to turn on the
printer.
4
While pressing the stopper of the ink tank
lock lever inwards, open the ink tank lock
lever upwards.
7
Insert the ink tank into the holder facing as shown, with the ink holes
down.
At this time, detach and reattach the ink tanks 2 to 3 times and
ensure that the ink tanks are security attached.
• If the ink tank does not fit in the holder, make sure the color of the
ink tank lock lever matches the color of the ink tank, and check the
Important
orientation of the ink tank.
9
Once you have installed all 6 ink tanks by repeating steps 4 to 8,
close the ink tank cover.
2
Select your language and time zone.
Use the ▲ and ▼ keys to select and
press OK.
Language
English
日本語
Français
Data
Italiano
Deutsch
Message
Time Zone
0:London (GMT)
+1:Paris,Rome
+2:Athens,Cairo
+3:Moscow
+4:Eerevan,Baku
5
Shake the ink tanks gently 1 to 2 times
before opening the pouch.
• Failure to shake ink tanks may result
in reduced print quality because ink
Important
ingredients have settled on the bottom
of the tank.
• If the ink tank is cold, allow it to adjust to
room temperature before attaching it to
the printer.
8
Important
2
3
Instructions on ink tank installation
are shown on the display screen. As
instructed, grab the handle on the ink tank
cover to open it.
1/2
1/5
6
Open the pouch and remove the ink tank.
• Never touch the ink holes (a)
or metal contacts (b). Touching
Important
these parts may cause stains,
damage the ink tank, and
affect print quality.
• Avoid dropping the ink tank after
removing it from the pouch.Otherwise,
ink may leak and cause stains.
• Do not remove and shake ink tanks that
have already been installed in the printer
because ink may leak out.
Close the ink tank lock lever until it clicks into place. Make sure the
ink lamp is lit in red.
• If the ink lamp is not lit, repeat steps 4 and 8.
a
b
