Comfee 2D-18K Owner's Manual

Inverter one-two/one-three/one-four/one-five split-type air conditioner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INVERTER ONE-TWO/ONE-THREE/ONE-FOUR/ONE-FIVE
Owner's Manual
2D-18K
3D-27K
IMPORTANT NOTE:
•
Read this manual carefully before installing or
operating your new air conditioning unit.
Make sure to save this manual for future reference.
This manual only describes the outdoor unit of
•
user's. When using the indoor unit,refer to the
user's manual of indoor unit.
SPLIT-TYPE AIR CONDITIONER
