Mixing Valve; Service Menu - Roth Softline – Controller 8 ch Master Manual

View in display during cooling operation
Mo.
27.5°C
1 2 3 4 5 6
Diagram – montörsmeny
TEMPERATURE
21.0°
22.3°
1
Internet Repeater
module configuration

9. MIXING VALVE

The master controller may control additional valve with the use of a Softline Valve module. The device offers a range of parameters to adjust the
valve operation to individual needs, and also includes the possibility to run the system based on outdoor compensation.
The Roth Softline Valve module must be connected to the master controller with the RS cable. Please see the specific manual for the Softline
Valve module.
!
NOTE
This type of control is available only after purchasing and connecting the additional Roth Softline Valve module, which is not
included in the controller delivery.
Diagram – servicemeny
XII. SERVICE MENU
Diagram - Service menu
Output type
Diagram – meny för programvaruversion
Service menu should only be used by a highly qualified person and only when it is necessary to adjust advanced settings that can have a big
influence on the functionality and performance of the system.
Therefore the access to this MENU is also secured with a password code which is: 1234
To enter menu choose "Service menu" in the main menu – pres MENU button. Enter password by using ▼ or ▲ – press MENU to go to the next
number. Finally confirm by pressing MENU. Due to security reasons you will be automaticly thrown out of the service menu after 1 minute.
13:51
1. The arrows point downwards, which means that it is cooling.
2. A fan is displayed when cooling
SET
CON
If the maximum humidity is exceeded in a zone, the symbol 1. will switch off, but the
symbol 2. will still be on.
100% 65%
Contact
Radiators
Additional
operation
zones 1 - 8
contacts
mode
Potential-free
Pump
contact
Antifreeze
Relay delay
protection
2
Fitters menu
DHW Open Therm
Heating
Service
menu
Zones
temperature
Floor
Hysteresis
heating
Hysteresis
Menu
Software
Heating
Mixing valve
cooling humidity
Operation
mode
Cooling Automatic
Max Min
temperature
Max. Factory
settings
Factory
settings
User Manual - 25/32
