3. ZONES MENU

Diagram - Zones menu
Sensor
ON
type
This submenu enables the user to configure operation parameters for the particular zones. When the pre-set temperature value in a zone is
reached, the controller labels the zone as sufficiently heated and the status remains unchanged until the temperature drops below the pre-set
temperature by hysteresis value. When the temperature in all the zones is sufficient, the controller disables both the pump and the heatsource
(potential-free contact).
3.1 ON
After the room thermostat has been activated and registered in a given zone, it can be regulated by the controller. The function "ON" is inactive
by default, but it may be activated when the room thermostat has been registered.
Press MENU button to cancel "ON".

3.2 SENSOR TYPE

Here you can choose between wired (NTC) or wireless room sensor. Wired sensors are connected at the terminals marked "Sensor 1 – 8" in the
top of the controller.

3.3 PRE-SET TEMPERATURE

Temperature will normally be set on the room thermostat, but can also be set on the Controller display.
Press MENU button - , set temperature with ▼ or ▲ – press MENU. Press MENU to "CONFIRM" or choose "CANCEL" with ▲ – press MENU.

3.4 OPERATION MODE

schedule
Select Preview
Here you can choose between different modes, pres MENU button and scroll with ▼ or ▲, select with MENU button.
Local schedule
Global schedule
Constant temperature
Floor pump
With time limitation
On Off
Holiday
Normal
mode
mode
Operation
Set temp.
mode settings
Local
Edit
Here you can select a schedule which you can customize only for this zone. You can choose "Select" immediately,
"Preview" if you want to see the schedule first or "Edit" if you want to edit the schedule. Editing of the schedule is
described in chapter VII Time settings menu.
Here you can choose to let the zone follow one of the 5 (G1 – G5) predefined global schedules. You can choose
"Select" immediately, "Preview" if you want to see the schedule first or "Edit" if you want to edit the schedule.
Editing of the schedule is described in chapter VII Time settings menu.
Here you choose to run the zone with a constant temperature. Press MENU button - , set temperature with
▼ or ▲ – press MENU. Press MENU to "CONFIRM" or choose "CANCEL" with ▲ – press MENU.
Here you choose to overwrite the current setting for a certain time. Press MENU button - , set temperature with ▼
or ▲ – press MENU. Set time "Hours" with▼ – press MENU, then set "Minutes" with ▲ – press MENU.
Press MENU to "CONFIRM" or choose "CANCEL" with ▲ – press MENU.
On
ECO
Comfort
mode
mode
Zones
1-8
User Floor Optimum
heating start
2
Operation
mode
Select
User
settings
Heating
Schedule Constant
settings temperature
Hysteresis Calibration
Global
Constant
schedule
temperature
G1 - G5
Preview Edit
Temperature
settings
Temp.
Economical
comfortable
Window
Actuators
sensors
With time
limitation
Holidays
