Blue Sea Systems M2 Instructions Manual page 3

Flat Mount
M2 Flat
Head Mount
Unit Bezel
Surface Mount
Surface M2
Mount Head
Cover Unit
NOTE: During
installation use cover
to align the bezel
and gasket
Mounting
Ring and Nut
Clamp
Mounting
Substrate
Mounting
Ring and Nut
Surface
Mounting
Mount
Gasket Substrate
Surface
Mount
Bezel
and Seal
360 Panel Mount
PN 1525
STEP 1
Use 1/4"
Mounting
Screws
STEP 2
Snap header
and footer
into mounting
clips and post.
Snap the
mounting bezel
into place
with the flat
edge up.
Footer
STEP 3
Header
M2
Head Footer
Unit
360 Panel
Mount
Carrier
Panel
Frame
Header
Bezel
Panel
Frame
Mounting
Ring and Nut
Bezel Panel
Frame
3
