- Page 1 OWNER’S MANUAL Dehumidifier Model: GDN100AM-A3EBA1A Thank you for choosing our product. For proper operation, please read this manual carefully and keep it for future reference. 00700_07/11/14 Code GREE : 13-06101...
-
Page 2: Operation Notices
OPERATION NOTICES Operation Area ..................1 Safety Precautions ..................1 Parts Name....................3 Check Before Operation ................4 Operation Instructions Operation Method..................5 Drainage Option ..................8 Clean and Maintenance................10 Troubleshooting ..................12 Malfunction Codes...................14 Warranty ....................15 Note: The images in this manual are only for reference. Please refer to actual products for specific details. - Page 3 ● This dehumidifier is intended for indoor residential applications only. It should not be used for commercial or industrial applications. ● Place the dehumidifier on a smooth and level floor. ● A dehumidifier operating indoors will have no effect in drying an adjacent enclosed area, such as a closet.
- Page 4 ● Before operating, please check the power cord to make sure it complies with the requirement indicated on the nameplate. ● Before cleaning, please turn the unit off and unplug it. ● Make sure the power cord is not being compressed by any hard object. ●...
-
Page 5: Front Side
AIR OUTLET Front side CONTROL AIR-IN-GRILLE PANEL WATER BUCKET Back Side REAR CASE COVER PLATE (CONTINIOUS DRAINAGE) POWER CORD... - Page 6 Before operating, please first check that the float is properly placed. Below are the steps to do this: 1. Hold the handles on both sides of the water bucket and pull out in the direction indicated by the arrows. 2. Check that the float in the water bucket is properly placed. It may have shifted during transportation.
-
Page 7: Basic Functions Of The Buttons
space indicator indicator indicator proper place operation on indicator indicator indicator Notes: ● The water bucket must be correctly installed for the dehumidifier to operate. ● Do not remove the bucket while the unit is in operation. ● If you want to use a drain hose to drain water away, please install the hose according to the section "Drainage method". - Page 8 will lock the buttons. If this function is turned on, the Button Locked Indicator will come on and the display window shows LC, which will blink 3 times. Then the ambient humidity is displayed again. To turn off this function, hold « + » and «...
-
Page 9: Other Instructions
Continuous button Press this button to set continuous dehumidify. Note: The drain hose must be installed to use the CO mode. Otherwise, unit will stop when the water bucket is full. FILTER Button Press this button to turn off the Filter Cleaning Indicator. (When the dehumidifier has been operating for 250 hours, the Filter Cleaning Indicator will light up to remind to clean the filter.) Other Instructions... - Page 10 Option 1 Emptying Manually Notes ● Do not remove the bucket when the unit is in operation or has just stopped. This may cause the water to drip on the floor. ● Do not use the hose if using the water bucket to collect water. When the hose is connected, the water will drain out through it instead of into the bucket.
- Page 11 Option 2 Gravity Drain Hose 1. Open the drain cover on the back of the unit. 2. Remove the drainage joint from the package. Drainage Joint 3.Install and secure the drainage joint onto the drainage connector. 4. Insert the garden hose(not supplied) onto the drainage joint so that it is fully seated.
- Page 12 Warning: ● Before cleaning, turn off the dehumidifier and disconnect the power to avoid electric shock. ● Do not wash the dehumidifier with water to avoid electric shock. ● Do not use volatile liquid (such as thinner or gasoline) to clean dehumidifier. Otherwise it will damage unit's appearance.
-
Page 13: Long Term Storage
Check Before Use-seasonally ● Check whether air outlet is blocked. ● Check whether power plug and power socket are in good condition. ● Check whether air filter is clean. ● Check whether drain hose is damaged. Care After Use-seasonally ● Disconnect power. ●... - Page 14 ● Not all the following problems are malfunctions. PROBLEM POSSIBLES CAUSES Dehumidifier is not operating. ● Unit is operating in an area where the temperature Controls cannot be set. is higher than 32°C or lower than 5°C. ● Bucket is full. Noise suddenly starts when ●...
- Page 15 ● Dehumidifier does not start. PROBLEM Possible causes Solu ons ● Power is not supplied to ● Check if power is lost. If When using the drain hose, there is water in the dehumidifier or the yes, wait for the power to power plug is not well restore.
- Page 16 ● Unit's Malfunction Codes Display Malfunc on Possible Causes Solu on Code Name 1. Connection terminal between 1. Re-energize the unit after Malfunction of indoor ambient sensor and controller is turning it off and pulling out temperature loosened or poorly contacted; the plug for 30min;...
-
Page 17: Limited Warranty
ONE (1) year from the date of original purchase in Canada. Note: The compressor is covered by a 5-year limited warranty. During the warranty period, if the dehumidifier fails under normal use, GREE will, at its option, either repair the unit or replace it, free of charge, within a reasonable period of time after the dehumidifier is returned.
