Installation
Guide:
OmniAccess
601, 602, and
604
June 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OmniAccess 601 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alcatel OmniAccess 601

Summary of Contents for Alcatel OmniAccess 601

  • Page 1 Installation Guide: OmniAccess 601, 602, and June 2005...

  • Page 2: Copyright

    Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. The Lithium battery in this product is part of a non-volatile memory device and will retain data for 10 years in the absence of power. Alcatel does not consider the lithium battery in this unit a field replaceable or serviceable part and should not be accessed by the customer.

  • Page 3: Table Of Contents

    ABLES BOUT UIDE Organization............................2 Conventions ............................3 Notices ............................3 Documentation ........................... 4 About the Alcatel Router Documentation CD ................4 Navigation ..........................4 Printing Documents........................4 Related Alcatel Guides........................4 RODUCT NTRODUCTION Overview ............................7 OmniAccess 601 ..........................8 OmniAccess 601 Front Panel......................
  • Page 4 Tools Required ..........................17 Unpacking and Inspecting ........................18 Wall-Mounting Option ........................19 Rack-Mounting Option ........................20 Installing the OmniAccess 601, OmniAccess 602, and OmniAccess 604 Router ......21 Table Top Installation ........................21 Wall-Mount Installation ......................... 22 Rack-Mount Installation......................... 24 Network Connections .........................
  • Page 5 Compliance ............................67 FCC Conformance ..........................68 FCC Part 15............................ 68 FCC Part 68............................ 68 Incidence of Harm.......................... 69 Rights of the Telephone Company....................69 Proper Disposal of Alcatel Equipment....................70 NDEX ORPORATE OLICY Standard Warranty ..........................73 Hardware ............................73 Software ............................

  • Page 7: Figures

    8 Ethernet Cable..........................16 9 WAN Cable..........................17 10 Required Tools ........................... 17 11 Items Shipped with the OmniAccess 601, OmniAccess 602, and OmniAccess 604 Router..18 12 Wall-Mount Components......................19 13 Rack-Mount Components ......................20 14 Table Top Installation ........................ 21 15 Wall Mounting the Model OmniAccess 601 Router ..............

  • Page 9: Tables

    1 Guide Organization: Chapters..................... 2 2 Guide Organization: Appendices ....................2 3 Text Conventions ........................3 4 LED and Port Descriptions ......................8 5 OmniAccess 601 Back-Panel Ports..................... 9 6 LED Descriptions........................10 7 OmniAccess 602 Back-Panel Ports..................... 11 8 LED Descriptions........................12 9 OmniAccess 604 Back-Panel Ports.....................

  • Page 11: About This Guide

    UIDE Detailed instructions are provided in this guide for installing, configuring, and troubleshooting the Alcatel OmniAccess 601, OmniAccess 602, and OmniAccess 604 router. This guide is designed for network managers, administrators, and technicians who are responsible for the installation and management of networking equipment in Enterprise and Service Provider environments.

  • Page 12: Organization

    Alcatel OmniAccess 601, OmniAccess 602, and OmniAccess 604 router. Installation - describes the system front and back panels and how to install the Alcatel OmniAccess 601, OmniAccess 602, and OmniAccess 604 router. Information is also provided about the operator interface, network cabling, and the operator interface.

  • Page 13: Conventions

    Notices Notice paragraphs alert you about issues that require your attention. The following paragraphs describe the types of notices used in this guide. Notes provide tips and useful information regarding the installation and operation of Alcatel NOTE: systems. ESD notices provide information about how to avoid discharge of static electricity and subsequent ESD: damage to Alcatel systems.

  • Page 14: Documentation

    Alcatel user guides, which are provided in portable document format (PDF), are included on the Alcatel Router Documentation CD-ROM that ships with the OmniAccess 601, OmniAccess 602, and OmniAccess 604 router. The PDF files are also available on the Alcatel website: http://eservice.ind.alcatel.com.
  • Page 15 Command Reference Guide This detailed guide provides a complete description of all Alcatel command line interface (CLI) commands. Router User Guide This guide provides descriptions of commands available for Alcatel implementation of BGP (including BGP4), OSPF, RIP and other routing protocols.

  • Page 17: Product Introduction

    OmniAccess 602, and OmniAccess 604 router. Additional information is also provided in following sections about external cables, wiring, and connection points. The Alcatel OmniAccess 601, OmniAccess 602, and OmniAccess 604 are designed to provide WAN-to-LAN networking connectivity for branch office communication and primary Internet access for medium-size businesses.

  • Page 18: Omniaccess 601

    Compact Flash OmniAccess 601 Back Panel The OmniAccess 601 router back panel provides connections for one WAN port, two 10/100 Base-T Ethernet ports, one AUX port, one Console port, and a 12 VDC power input jack. Figure 2 OmniAccess 601 Router Back Panel...
  • Page 19 Off = power off Compact Flash Port for compact flash — module Table 5 OmniAccess 601 Back-Panel Ports Connector Description WAN 1 WAN connection port. This port accepts cables with RJ-48C connectors. Backup WAN An ISDN backup option is supported in releases 8.3 and higher. This option provides a backup if the primary network connection is lost.

  • Page 20: Omniaccess 602

    OmniAccess 602 OmniAccess 602 Front Panel The router front panel houses the system LEDs. Figure 3 OmniAccess 602 Router Front Panel Power LED LINK/ACT HS LINK/ACT HS WAN Port Ethernet 0 LEDs Ethernet 1 LEDs LEDs 1-2 OmniAccess 602 Back Panel The OmniAccess 602 router back panel provides connections for two WAN ports, two 10/100 Base-T Ethernet ports, one AUX port, one Console port, and a 12 VDC power input jack.
  • Page 21 Table 6 LED Descriptions (continued) Port Description Color Indicates traffic speed Off = 10 Mbps on the interface Green = 100 Mbps Indicates the type of Off = Half duplex duplex mode Green = Full duplex Power Indicates system power Green = power on status Off = power off...

  • Page 22: Omniaccess 604

    CHAPTER 2 Product Introduction OmniAccess 604 OmniAccess 604 OmniAccess 604 Front Panel The router front panel houses the system LEDs. The following section identifies and describes the OmniAccess 604 router network ports and LEDs. Figure 5 OmniAccess 604 Router Front Panel Power LED LINK/ACT HS LINK/ACT HS...
  • Page 23 Table 8 LED Descriptions (continued) Port Description Color LINK/ACT Indicates traffic activity on Green = link is operational this interface Blinking Yellow = either receiving or sending traffic Red = packet collisions Indicates traffic speed on Off = 10 Mbps the interface Green = 100 Mbps Indicates the type of duplex...

  • Page 25: Installation

    Environment Site location is important for the proper operation of the OmniAccess 601, OmniAccess 602, and OmniAccess 604 router. Place the unit in a clean, dry environment with adequate air circulation.

  • Page 26: Power Requirements

    Installation Site Preparation Power Requirements The OmniAccess 601, OmniAccess 602, and OmniAccess 604 router operates on 12 VDC power. A 12 VDC power supply and an AC power cord are shipped with the router. Network Connection To successfully complete the installation, the router must be connected to a network. Before you start the installation, make sure that a live network connection is available at the installation site.

  • Page 27: Tools Required

    Figure 9 WAN Cable Tools Required The following tools are required to install the Alcatel OmniAccess 601, OmniAccess 602, and OmniAccess 604 router. Figure 10 Required Tools #3 Phillips screwdriver 1/4 inch flat blade screwdriver #2 Phillips screwdriver Installation Guide: 601, 602, and 604 Routers...

  • Page 28: Unpacking And Inspecting

    Check the packing slip and contents of the shipping carton to ensure that you have received the following items. Figure 11 Items Shipped with the OmniAccess 601, OmniAccess 602, and OmniAccess 604 Router Alcatel router (OmniAccess 604 shown) Quick Start Guide, CD ROM, product information...

  • Page 29: Wall-Mounting Option

    Inspect the OmniAccess 601, OmniAccess 602, and OmniAccess 604 and the shipping carton for damage that may have occurred during shipping. If you discover damage or that items are missing, contact Alcatel Technical Support. Refer to the Alcatel website for contact information: http://eservice.ind.alcatel.com.

  • Page 30: Rack-Mounting Option

    CHAPTER 3 Installation Unpacking and Inspecting Rack-Mounting Option An optional rack-mounting tray is available for installing two Model OmniAccess 602 or Model OmniAccess 604 routers in an equipment rack. The following items are shipped in a separate carton: Figure 13 Rack-Mount Components (2) Rack Carriage Assemblies Rack Tray 2) Mounting Brackets...

  • Page 31: Installing The Omniaccess 601, Omniaccess 602, And Omniaccess 604 Router

    Installing the OmniAccess 601, OmniAccess 602, and OmniAccess 604 Router The OmniAccess 601, OmniAccess 602, and OmniAccess 604 router can be installed on a table top, in a Telco equipment rack (using the optional rack-mounting tray), or on a vertical surface (using the optional wall-mounting assembly).

  • Page 32: Wall-Mount Installation

    Installing the OmniAccess 601, OmniAccess 602, and OmniAccess 604 Router Wall-Mount Installation Follow this procedure to attach the Alcatel OmniAccess 601, OmniAccess 602, and OmniAccess 604 router to a vertical surface. Figure 15 Wall Mounting the Model OmniAccess 601 Router...
  • Page 33 Attach the assembly with the mounted router to the wall surface with four (provided) 6 x 1 inch (for OmniAccess 602 and OmniAccess 604) or 4 x 1 (for OmniAccess 601) Phillips pan head screws and hollow wall plastic anchors.

  • Page 34: Rack-Mount Installation

    To mount the OmniAccess 602, and OmniAccess 604 in an equipment rack, follow this procedure. (This procedure does not apply to the Model OmniAccess 601.) Refer to Figure 17. Figure 17 Rack Mounting the OmniAccess 602 and OmniAccess 604 Router Determine the mounting position for the rack tray in the equipment rack (front or mid mount) and attach the mounting brackets using the four (provided) 6-32 x .250 inch flat...

  • Page 35: Network Connections

    Ethernet cable with RJ-45 connectors to connect to the LAN. Refer to Figure 8 on page 16 to identify this cable. Follow this procedure to connect the OmniAccess 601, OmniAccess 602, and OmniAccess 604 to an Ethernet LAN network.

  • Page 36: Connecting Drop And Insert Cables

    Provider’s Demarcation Point WAN Port 1 Figure 19 shows the WAN cabling for a Model OmniAccess 602. A Model OmniAccess 601 only has one WAN port. A Model OmniAccess 604 has four WAN ports. Connecting Drop and Insert Cables WAN ports 1 and 2 can alternatively be used for drop and insert traffic. Port 1 is designated for voice;...

  • Page 37: Operator Interface

    Operator Interface Local Management The OmniAccess 601, OmniAccess 602, and OmniAccess 604 can be locally configured, operated, and managed using an operator console connected to the Console port. A terminal (VT-100 or equivalent) or workstation with terminal emulation software can be used for the operator console.

  • Page 38: Console Messages

    Connect the male end of the DB-25 adapter to the female DB-25 port on the modem. Connect one end of a supplied RJ-45 cable to the RJ-45 port in the DB-25 adapter. Connect the other end of the RJ-45 cable to the Console port on the OmniAccess 601, OmniAccess 602, and OmniAccess 604.

  • Page 39: Configuration

    Scroll through the available commands using the Tab key. Ethernet Configuration Tip To avoid Ethernet mismatch problems, the OmniAccess 601, OmniAccess 602, and OmniAccess 604 router and the network device to which it is attached should both be configured identically for speed and duplex. For example, if the router is configured for auto-negotiation...
  • Page 40 CHAPTER 4 Configuration Logging In and the far end is configured manually, the router detects the speed, but defaults to half-duplex mode. To ensure correct operation, either manually configure each device for speed and duplex settings, or configure both devices to auto-negotiate. Installation Guide: 601, 602, and 604 Routers...

  • Page 41: Changing Login Parameters

    The System Administrator login consists of two components: the user name and the password. The initial login name is always alcatel, but you can change this to suit your needs after logging in for the first time. The default password for user alcatel, switch, should be changed as soon as possible to ensure only authorized access to the router.

  • Page 42: System Host Name

    Configuration Changing Login Parameters System Host Name Use the configure hostname command to assign a host name to the Alcatel router. Once assigned, the host name becomes the command line interface (CLI) prompt name. To configure the host name: Access the terminal configuration mode: Alcatel> configure term Type hostname, and then type a new host name.

  • Page 43: Adding Users

    To add a new user: Enter the terminal configuration mode: Alcatel> configure term Type user name, enter the name that you want to add, and then enter the access level to be assigned to that name (optional). The user name may be up to 30 characters. The password must be 3-10 characters.

  • Page 44: Default Configuration

    If you change any of the factory default settings, issue the save local command to retain the changed configuration before rebooting. The following tables show the factory default configuration for the Alcatel OmniAccess 601, OmniAccess 602, and OmniAccess 604 router.
  • Page 45 Table 12 T1 Interface Default Configuration Parameter Default Value Optional Values framing linecode b8zs clock_source internal line linemode 0 dB 7.5 db 15 db 22.5 db cable length 1 (0 - 110 ft.) 2 (110 - 220 ft.) 3 (220 - 330 ft.) 4 (330 - 440 ft.) 5 (440 - 550 ft.) 6 (550 - 660 ft.)

  • Page 46: Configuring Drop And Insert Multiplexing

    Configuration Configuring Drop and Insert Multiplexing Configuring Drop and Insert Multiplexing Use the Drop and Insert feature to terminate IP traffic on the Alcatel OmniAccess 602 and OmniAccess 604 routers while passing through the DS0s that carry voice traffic. NOTE: The pass through Channel Associated Signaling (CAS) on the E1 interfaces is not supported in this release.

  • Page 47: T1 Configuration

    This data bundle is pointed toward the network, and the corresponding DS0s on E1 number 2 are not configured. Alcatel NOTE: starts counting DS0s from 1 for both T1 and E1. Be careful when connecting to other equipment as some vendors start counting from 0.
  • Page 48 CHAPTER 4 Configuration Configuring Drop and Insert Multiplexing Note that there is no signaling DS0 on a T1. The signaling on the T1 will be a Robbed Bit from within each individual voice DS0, or will be carried within the Facility Data Link (FDL) of an Extended Super Frame (ESF) mode T1.

  • Page 49: Port Upgrade/Activation

    WAN ports. This key is different than the software upgrade key. To obtain a port upgrade key, contact your reseller or Alcatel. You will be asked to provide the serial number, model number, and the number of ports that are currently active on your router.

  • Page 50: Installing The Software License Key

    (such as IPSec VPN) 604 router for . To obtain a software license upgrade key, contact your reseller or Alcatel. You will be asked to provide the serial number and model number. This key is different than the port activation key. advanced VPN...

  • Page 51: Boot Process

    Boot Process When power is applied to the Alcatel system, the Flash is checked for a downloadable boot image. If a boot image file is found in the Flash, the file is executed. Otherwise, the boot image is executed from the factory image stored in the boot ROM. Next, the Alcatel operating system is loaded from the T1000.Z file residing in the Flash.

  • Page 52: Upgrading System Software

    OmniAccess 601, OmniAccess 602, and OmniAccess 604 router with new software. Every system is furnished with a software image file (T1000.Z) and a boot image file (T1000.bin). Using the TFTP protocol, the latest versions of these files can be loaded onto a Alcatel router from any accessible TFTP server.

  • Page 53: Upgrading Software

    TFTP daemon. Ensure that network connectivity exists between the Alcatel system being upgraded and the TFTP server holding the new file. Pinging the server from the Alcatel system is a good method to use to prove connectivity.

  • Page 54: Booting From A Network Tftp Server

    Upon a download failure (and corruption or deletion of the T1000.Z file in Flash), the OmniAccess 601, OmniAccess 602, and OmniAccess 604 router may not be able to boot. Make note of which Ethernet interface (0 or 1) connects the system to the tftp server host.
  • Page 55 The following text is output to the terminal: inet on ethernet [e] : 10.1.0.1:fff0000 Input the address for the Alcatel system to use as an tftp client to the tftp host. Type 111.2.3.3:ffffff00 (or whatever is appropriate for your network configuration) and press the Enter key.
  • Page 56 The following text is output to the terminal: target name [tn] :T1000 The name that you use to configure the Alcatel router will become the system prompt. Ensure that the startup script parameter is blank. The “other” parameter may be blank or left as “lnPci.”...

  • Page 57: Interface Configuration

    Interface Configuration The following are examples of T1, CT3, and DS3 interface configurations. To scroll through the options available at any command prompt, press the Tab key. For descriptions of the options available at any command prompt, type help and press Enter. E1 Interface Router>...

  • Page 58: Bundle Configuration

    CHAPTER 4 Configuration Bundle Configuration Bundle Configuration Alcatel systems support PPP, MLPPP, FR, MFR, and Cisco-compatible HDLC for WAN data transmission. NOTE: Bundle names cannot exceed eight characters. E1/PPP Bundle Router> configure term Router/configure> interface bundle HongKong Router/configure/interface/bundle HongKong> link e1 4 Router/configure/interface/bundle HongKong>...
  • Page 59 Fractional T1/Cisco-compatible HDLC Bundle Router> configure term Router/configure> interface bundle Denver Router/configure/interface/bundle Denver> link t1 3:1-6 Router/configure/interface/bundle Denver> encapsulation hdlc Router/configure/interface/bundle Denver> hdlc keepalive 20 Router/configure/interface/bundle Denver> ip address 192.168.2.1 255.255.255.0 Router/configure/interface/bundle Denver> exit 3 T1/PPP Bundle Router> configure term Router/configure>...

  • Page 60: Routing Configuration

    Router/configure/ interface/bundle Rome/fr/pvc 16> exit Router/configure/ interface/bundle Rome/fr> enable interface Router/configure/ interface/bundle Rome/fr> exit 4 Routing Configuration Alcatel products support RIP, OSPF, and BGP4 routing protocols. Configuring RIP for Ethernet 0 and WAN 1 interfaces. Router> configure terminal Router/configure> router rip Router/configure/router rip>...
  • Page 61 BGP4 Configuring EBGP between two different autonomous systems. Router/configure> interface bundle Chicago Router/configure/interface/bundle Chicago> link ct3 1 1-10 Router/configure/interface/bundle Chicago> encapsulation ppp Router/configure/interface/bundle Chicago> ip address 20.20.20.1 24 Router/configure/interface/bundle Chicago> exit Router/configure> router bgp 10 Router/configure/router/bgp 10> neighbor 20.20.20.2 20 Router/configure/router/bgp 10/neighbor 20.20.20.2 20>...

  • Page 62: Compact Flash Configuration

    Compact Flash Configuration The Model OmniAccess 601 supports compact flash memory. For a list of supported flash sizes and vendors supported, refer to the release notes that shipped with the Model OmniAccess 601 router. To configure and use compact flash memory, the following file commands are supported in TiOS 8.1 or later:...

  • Page 63: Troubleshooting

    ROUBLESHOOTING This chapter provides general troubleshooting tips in addition to network tests and diagnostics information for the Alcatel OmniAccess 601, OmniAccess 602, and OmniAccess 604 router. Alarms and System Status The OmniAccess 601, OmniAccess 602, and OmniAccess 604 router reports various alarms upon detecting certain irregular conditions in the incoming WAN signals.

  • Page 64: Network Tests

    LAN port, WAN link, or serial interface ports. Ping Test The Ping test checks connectivity between the Alcatel system and another host system on the LAN. If an “unknown host” error occurs after initiating this test, the destination host is either unreachable or unstable, or it does not exist.

  • Page 65: Diagnostics Tips

    The information in the following tables may help to isolate or resolve certain system problems. General Symptoms The following table provides general diagnostics information that applies the OmniAccess 601, OmniAccess 602, and OmniAccess 604 router. Table 17 Common Symptoms and Actions...
  • Page 66 WAN Status LED is yellow. The link is faulty Perform the BERT test (and other steps above from the far (far-end system has end) in conjunction with a T1 line loopback at the Alcatel detected an abnormal router. incoming T1 signal).
  • Page 67 (s): Not needed. other (o): lnPci (This is a lowercase “L”, not a “1”.) At this point, you will be at the Alcatel prompt [Alcatel Boot]. Type @ and press Enter. This will boot the system from the network.
  • Page 69 This appendix includes technical information about the operating environment, power application, interfaces, cable pinouts, MIBs, and physical cables and adapters used to connect the Alcatel OmniAccess 601, OmniAccess 602, and OmniAccess 604 router to a network. Installation Guide: 601, 602, and 604 Routers...

  • Page 70: System Specifications

    APPENDIX A Specifications System Specifications System Specifications The following tables provide various technical specifications for the Alcatel OmniAccess 601, OmniAccess 602, and OmniAccess 604 router. Table 18 Environment, Hardware, Memory, and Power Environment Operating temperature 32° F to 104° F (0° C to 40° C) Storage temperature –...

  • Page 71: Wan Interfaces

    Table 19 Performance Monitoring Statistics Storage Statistics for the last 24 hours in 15-minute increments Statistics for 24-hour increments Reporting G.821 performance reports Alarm history Interface statistics Alarms RRAI receive yellow TAIS transmit alarm indication signal TRAI transmit yellow RAIS receive alarm indication signal RLOF receive loss of frame...

  • Page 72: Lan Interfaces

    APPENDIX A Specifications System Specifications Table 21: E1 WAN Interface Receive line rate 2.048 Mbps ± 50 ppm (payload = 1.984 Mbps) Line code HDB3 Framing non-crc (ITU G.704) unframed Input signal 0 to -32 db Output signal ITUG.703 Impedance 75 ohm 120 ohm Connectors...

  • Page 73: Cable Pinouts

    Cable Pinouts The following tables provide cable pinout information for the console (RJ-45), Ethernet (RJ-45), T1(RJ-48C), and modem (DB-9 to DB-9) or (DB-25 to DB-9) cables. Table 24 Pinouts: Alcatel-to-Terminal Console Cable (DB-9) Alcatel Workstation DCE Pin Signal Direction DTE Pin data carrier detect <—...
  • Page 74 APPENDIX A Specifications System Specifications Table 27: DB-25 to RJ-45 Modem Adapter Pinouts RJ-45 Pin Signal DB-25 Pin no connection no connection Ground Ground no connection no connection Installation Guide: 601, 602, and 604 Routers...

  • Page 75: Mibs

    MIBs Alcatel systems support standard and enterprise MIBs. The following tables provide information about supported MIBs. Table 28 Standard MIBS Standard MIB Description RFC 1213 Standard MIB-II objects. The following groups or variables are not supported for this MIB: RFC 1315 MIB objects for frame relay DTE interface.
  • Page 76 Random Early Detect (RED) objects and class-based queuing. smi.mib Defines the top-level object assignments for the Alcatel MIB tree. This MIB should be compiled before any other Alcatel MIBs are compiled. This MIB does not contain any objects that can be used for management operations.

  • Page 77: Ompliance And Compliance

    This appendix includes information about regulatory compliance and FCC conformance rules that apply to the Alcatel OmniAccess 600-series router. Compliance The following table provides compliance information about the Alcatel OmniAccess 601, OmniAccess 602, and OmniAccess 604 router. Table 30 Regulatory and Compliance Standards...

  • Page 78: Fcc Conformance

    This section provides information about Alcatel product conformance with FCC rules. FCC Part 15 Alcatel products comply with FCC Part 15 (also known as CFR42, Chapter 2, Part 15) of the Federal Communications Commission (FCC) rules concerning radio frequency emissions for Class A computing devices.

  • Page 79: Incidence Of Harm

    Incidence of Harm If your telephone equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advance notice is not practical, the telephone company will notify you as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.

  • Page 80: Proper Disposal Of Alcatel Equipment

    Proper Disposal of Alcatel Equipment The OmniAccess 601, 602, and 604 routers at end of life are subject to separate collection and treatment in the EU Member States, Norway, and Switzerland and therefore are marked with the symbol shown at the left. Treatment applied at end of life of these products in these countries shall comply with the applicable national laws implementing Directive 2002/96EC on Waste of Electrical and Electronic Equipment (WEEE).

  • Page 81: Index

    LAN interface 25 download command 42 adapter, console cable 27 Drop and Insert 36 adding users 33 DUP 12 alarms 53 Ethernet 12 Alcatel, contacting 74 HS 12 LINK/ACT 12 EMC compliance 67 Power 12 enterprise mibs 66 WAN 12 environment 15...
  • Page 82 Alcatel to console (RJ-45) 63 Ethernet cable 63 RJ-45 console cable 63 wall mount installation 22 RJ-48C T1 cable 63 port statistics 53 Console 9 T1 25 Ethernet 34 WAN STATUS LED 8 power warranty, exclusions 73 LED 55 warranty, standard 73...

  • Page 83: Corporate Policy

    Hardware Alcatel warrants that the Hardware sold hereunder shall be free of defects in workmanship for a period of one (1) year from the Date of Shipment. In the event that Alcatel receives notice from the Customer during the warranty period that any Hardware does not conform to this warranty, Alcatel, shall, at its sole option, either repair or replace the non-conforming Hardware.

  • Page 84: Limitation Of Liability

    Limitation of Liability Alcatel and its suppliers exclude themselves from any liability for any lost revenue or profit, loss of business, loss of information or data, or for special, indirect, consequential, incidental, or punitive damages of any kind caused out of or in connection with the sale, installation, maintenance, use, performance, failure, or interruption of its products, even if Alcatel and its authorized resellers have been advised of the possibility of such damages.
