- Page 1 1221F Tier 4 Wheel Loader SERVICE MANUAL Part number 47544213 edition English August 2013...
- Page 2 The specifications contained in this shop manual are subject to change at any time and without any advance notice. Contact your Case distributor for the latest information. Find manuals at https://best-manuals.com...
- Page 3 Revised edition mark ( Any additions, amendments or other changes When a manual is revised, an edition mark is will be sent to Case distributors. recorded on the bottom outside corner of the Get the most up-to-date information before you pages.
-
Page 4: Conversion Table
3. CONVERSION TABLE Method of using the Conversion Table The Conversion Table in this section is provided to enable simple conversion of figures. For details of the method of using the Conversion Table, see the example given below. Example Method of using the Conversion Table to convert from millimeters to inches Convert 55 mm into inches. - Page 5 Millimeters to inches 1mm = 0.03937in 0.039 0.079 0.118 0.157 0.197 0.236 0.276 0.315 0.354 0.394 0.433 0.472 0.512 0.551 0.591 0.630 0.669 0.709 0.748 0.787 0.827 0.866 0.906 0.945 0.984 1.024 1.063 1.102 1.142 1.181 1.220 1.260 1.299 1.339 1.378 1.417 1.457...
- Page 6 Liter to U.S. Gallon = 0.2642 U.S.Gal 0.264 0.528 0.793 1.057 1.321 1.585 1.849 2.113 2.378 2.642 2.906 3.170 3.434 3.698 3.963 4.227 4.491 4.755 5.019 5.283 5.548 5.812 6.6076 6.340 6.604 6.869 7.133 7.397 7.661 7.925 8.189 8.454 8.718 8.982 9.246 9.510...
- Page 7 kgf m to lbf ft 1kgf m = 7.233lbf ft 14.5 21.7 28.9 36.2 43.4 50.6 57.9 65.1 72.3 79.6 86.8 94.0 101.3 108.5 115.7 123.0 130.2 137.4 144.7 151.9 159.1 166.4 173.6 180.8 188.1 195.3 202.5 209.8 217.0 224.2 231.5 238.7 245.9...
- Page 8 kgf/cm to lbf/in 1kgf / cm = 14.2233lbf / in 14.2 28.4 42.7 56.9 71.1 85.3 99.6 113.8 128.0 142.2 156.5 170.7 184.9 199.1 213.4 227.6 241.8 256.0 270.2 284.5 298.7 312.9 327.1 341.4 355.6 369.8 384.0 398.3 412.5 426.7 440.9 455.1 469.4...
- Page 9 TEMPERATURE Fahrenheit-Centigrade Conversion. A simple way to convert a fahrenheit temperature reading into a centigrade temperature reading or vice verse is to enter the accompanying table in the center or boldface column of figures. These figures refer to the temperature in either Fahrenheit or Centigrade degrees. If it is desired to convert from Fahrenheit to Centigrade degrees, consider the center column as a table of Fahrenheit temperatures and read the corresponding Centigrade temperature in the column at the left.
- Page 10 CONTENTS SECTION 1 GENERAL Group 1 Safety Hints - - - - - - - - - - - - - - - - - - - - --- ---- --- --- --- --- --- -- - -- - -- -- -- - -- - -- - -- - -- - -- - -- - -- -- - -- - -- - -- - -- - -- - -- - -- - -- -- - 1-1 Group 2 Specifications - - - - - - - - - - - - - - - - - - --- --- ---- --- --- --- -- -- - -- - -- - -- -- -- - -- -- - -- - -- - -- - -- - -- - -- - -- - -- - -- - -- - -- -- - -- - -- - 1-13 Group 3 Operational Checkout Record Sheet - -- - -- - -- - -- - -- - -- - -- - -- - -- - -- - -- - -- -- - -- - -- - -- - -- -- -- - -- - -- - -- 1-26 SECTION 2 ENGINE...
- Page 11 SECTION 7 ELECTRICAL SYSTEM Group 1 Component Location - - - - -- -------- ---------- ----------- ----------- ------- ----------- ---------- ----------- -- 7-1 Group 2 Electrical Circuit - - - - - - - - - - - - - -------- ----------- ---------- ------------------- ---------- ----------- ----------- -- 7-3 Group 3 Monitoring System - - - - - - - - ---- -------- ----------- ---------- ------------------ ----------- ----------- --------- 7-21 Group 4 Electrical Component Specification ----------- ---------- ----------- ----------- ------------------ -- 7-64 Group 5 Connectors - - - - - - - - - - - - - - - - - - - - ----- --- ---------- ----------- -------- ---------- ----------- ----------- ---------- ---- 7-71...
-
Page 12: Section 1 General
SECTION 1 GENERAL Group 1 Safety Hints - - - - - - - - - - - - - - - - - - - - ---- -------- ----------- ------------------ ----------- ---------- ----------- ----------- 1-1 Group 2 Specifications - - - - - - - - - - - - - - - - - ----- --------- ---------- ------------------- ---------- ----------- ----------- ---------1-13 Group 3 Operational Checkout Record Sheet -- ----------- ----------- ---------- ----------- -------- ----------1-26... -
Page 14: Helpful Hints
Foreword - Ecology and the environment Soil, air, and water are vital factors of agriculture and life in general. When legislation does not yet rule the treatment of some of the substances required by advanced technology, sound judgment should govern the use and disposal of products of a chemical and petrochemical nature. -
Page 15: Personal Safety
Personal safety Most accidents involving machine operation and maintenance can be avoided by following basic safety rules and precautions. Read and understand all the safety messages in this manual, the safety manual and the safety signs on the machine before you operate or service the machine. See your dealer if you have any questions. READ THIS MANUAL COMPLETELY and make sure you understand the controls. -
Page 16: California Proposition 65 Warning
Safety rules – California Proposition 65 Warning RCIL08CCH001EAA California Proposition 65 Warning Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, and other reproductive harm. Battery posts, terminals and related accessories contain lead and lead compounds. Wash hands after handling. -
Page 17: General Safety Rules
Safety rules General Safety Rules Use caution when operating the machine on slopes. Raised equipment, full tanks and other loads will change the center of gravity of the machine. The machine can tip or roll over when near ditches and embankments or uneven surfaces. -
Page 18: Parking The Machine
Operate controls only when seated in the operator’s seat, except for those controls expressly intended for use from other locations. Parking the Machine Before leaving the machine, do the following: 1. Park the machine on a firm, level surface. 2. Put all controls in the neutral or park lock position. 3. - Page 19 Scalding can result from incorrect removal of coolant caps. The cooling system operates under pressure. Hot coolant can spray out if a cap is removed while the system is hot. Allow the system to cool before removing cap. When removing a cap, turn it slowly to allow pressure to escape before completely removing the cap. Replace damaged or worn tubes, hoses, electrical wiring, etc.
-
Page 20: Fire And Explosion Prevention
On machines with independently operated wheel brakes, lock the brake pedals together when roading to provide equalized brake applications. Dual brake pedals (if equipped) should be locked together for road travel. Use the safety chains for trailed equipment. Lift implements and attachments high enough above the ground to prevent accidental contact with road. When transporting equipment or machine on a transport trailer, ensure the machine is properly secured. - Page 21 When using auxiliary batteries or connecting booster cables to start the engine, use the procedure shown in the operator’s manual. Do not short across terminals. Follow the manufacturer’s instructions when storing and handling batteries. Battery post, terminals, and related accessories contain lead and lead compounds. Wash hands after handling. This is a California Proposition 65 warning.
-
Page 22: Air Conditioning System
DO NOT attach any device to the protective structure for pulling purposes. DO NOT drill holes in the protective structure. The protective structure and interconnecting components are a certified system. Any damage, fire, corrosion, or modification will weaken the structure and reduce your protection. If this occurs, THE PROTECTIVE STRUCTURE MUST BE REPLACED so that it will provide the same protection as a new protective structure. - Page 23 Keep hazardous chemicals out of reach or children or other unauthorized persons. Additional precautions are required for applied chemicals. Obtain complete information from the manufacturer or distributor of the chemicals before using them. Utility Safety When digging or using ground-engaging equipment, be aware of buried cables and other services. Contact your local utilities or authorities, as appropriate to determine the locations of services.
- Page 24 Lifting and Overhead Loads Never use loader buckets, forks, etc. or other lifting, handling, or digging equipment to lift persons. Do not use raised equipment as a work platform. Know the full area of movement of the machine and equipment and do not enter or permit anyone to enter the area of movement while the machine is in operation.
- Page 25 Check the coupler operation periodically for any unusual movement and/or noise. Inspect hydraulic hoses for any leaks or damage. Inspect welds and make any repairs as necessary. Check for any loose bolts. Torque as required. Do not modify the machine or attachments. Such modifications can damage and/or affect the integrity of the attach- ment and can effect safety and function of the attachment and/or machine.
-
Page 26: Major Component
Bucket Head light Hydraulic tank Battery Tire Boom Bucket cylinder Main control valve Step Counterweight Radiator Air cleaner DPF assy Bucket link Bell crank Steering cylinder Engine Front axle Boom cylinder Transmission Rear axle Fuel tank Main pump 1221F 1-13... - Page 27 2. SPECIFICATIONS WITH BOLT-ON CUTTING EDGE TYPE BUCKET (1221F) 7809A2SE03 Description Unit Specification Operating weight kg (lb) 30300 (66800) Struck 4.6 (6.0) Bucket capacity Heaped 5.4 (7.1) Overall length 9630 (31' 7") Overall width 3450 (11' 4") Overall height 3865 (12' 8") Ground clearance 495 (1' 7")
- Page 28 WITH BOLT-ON CUTTING EDGE TYPE BUCKET (1221F XR) 7809A2SE03-1 Description Unit Specification Operating weight kg (lb) 31100 (68560) Struck 4.6 (6.0) Bucket capacity Heaped 5.4 (7.1) Overall length 10060 (33' 0") Overall width 3450 (11' 4") Overall height 3865 (12' 8") Ground clearance 485 (1' 7")
- Page 29 WITH TOOTH TYPE BUCKET (1221F) 7809A2SE04 Description Unit Specification Operating weight kg (lb) 30300 (66800) Struck 4.4 (5.8) Bucket capacity Heaped 5.2 (6.8) Overall length 9820 (32' 3") Overall width 3500 (11' 6") Overall height 3865 (12' 8") Ground clearance 495 (1' 7")
- Page 30 WITH TOOTH TYPE BUCKET (1221F XR) 7809A2SE04-1 Description Unit Specification Operating weight kg (lb) 31100 (68560) Struck 4.4 (5.8) Bucket capacity Heaped 5.2 (6.8) Overall length 10250 (33' 8") Overall width 3500 (11' 6") Overall height 3865 (12' 8") Ground clearance 495 (1' 7")
- Page 31 Item Front frame assembly 2695 5940 Rear frame assembly 3282 7240 Front fender (LH & RH) Counterweight (1221F) 1200 2650 Additional counterweight (3EA, 1221F XR) 1210 Cab assembly 1050 2320 Engine assembly 1269 2800 Transmission assembly 1840 Drive shaft (front)
- Page 32 4. SPECIFICATION FOR MAJOR COMPONENTS ENGINE Item Specification Model Cummins QSX 11.9 Type 4-cycle turbocharged, charge air cooled diesel engine Control type Electronic control Cooling method Water cooling Number of cylinders and arrangement 6 cylinders, in-line Firing order 1-5-3-6-2-4 Combustion chamber type Direct injection type Cylinder bore ×...
-
Page 33: Main Control Valve
CYLINDER Item Specification Boom cylinder Bore dia Rod dia Stroke 105 863 mm 1221F 75 575 mm Bucket Bore dia Rod dia Stroke cylinder 1221F XR 75 570 mm Steering cylinder Bore dia Rod dia Stroke 55 480 mm 1-20... - Page 34 DYNAMIC POWER TRANSMISSION DEVICES Item Specification Model ZF 4WG 310 Converter Single-stage, double-phase Type Transmission Full-automatic power shift Converter stall ratio 2.51 : 1 Gear shift Forward fourth gear, reverse third gear 4-speed transmission (std) Electrical single lever type, kick-down system Control Automatic kick down from 2nd to 1st gear FNR switch on joystick lever (option)
- Page 35 5. TIGHTENING TORQUE OF MAJOR COMPONENT Torque Descriptions Bolt size kgf m lbf ft Engine mounting bolt, nut (rubber, 4EA) M24 3.0 15.0 Engine mounting bolt (bracket, 8EA) 3/4-10UNC 19.4 21.7 Engine mounting bolt (bracket, 2EA) M20 2.5 57.9 62.9 Engine Engine mounting bolt (flywheel housing) 7/16-14UNC...
-
Page 36: Torque Chart
6. TORQUE CHART Use following table for unspecified torque. BOLT AND NUT Coarse thread Bolt size kg m lb ft kg m lb ft 0.85 ~ 1.25 6.15 ~ 9.04 1.14 ~ 1.74 8.2 ~ 12.6 1.25 2.0 ~ 3.0 14.5 ~ 21.7 2.73 ~ 4.12 19.5 ~ 29.8... - Page 37 PIPE AND HOSE (FLARE type) Thread size Width across flat (mm) kgf m lbf ft 1/4" 28.9 3/8" 36.2 1/2" 68.7 3/4" 1" 1-1/4" PIPE AND HOSE (ORFS type) Thread size Width across flat (mm) kgf m lbf ft 9/16-18 28.9 11/16-16 36.2...
-
Page 38: Recommended Lubricants
7. RECOMMENDED LUBRICANTS Use only oils listed below or equivalent. Do not mix different brand oil. Ambient temperature C ( F) Capacity Service point Kind of fluid (U.S. gal) (-4) (14) (32) (50) (68) (86) (104) SAE 30 SAE 10W Engine oil pan Engine oil 43 (11.4) - Page 39 GROUP 3 OPERATIONAL CHECKOUT RECORD SHEET Owner Date Hours Serial No. Technician Use this sheet to record operational checkout results. Perform the operational check before installing any test equipment. 7809A1GE02 Item Comments 1. Monitor indicator and gauge checks (engine OFF) Hourmeter and gauge check Battery check Monitor indicator circuit check...
- Page 40 4. Brake system and clutch cut off checks Park brake capacity check Park brake transmission lockout check Service brake pump flow check Service brake capacity check Brake accumulator precharge check Brake system leakage check Service brake pedal check Service and park brake system drag check Clutch cut off check 5.
- Page 41 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
