Casio 5200 Operation Manual

MO1103-EA
Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out of your
purchase, be sure to read this manual carefully.
• Be sure to keep all user documentation handy for future reference.
E
• The watch continues to operate, even when it is not exposed to light. Leaving the
watch in the dark can cause the battery to run down, which will result in some watch
functions to be disabled. If the battery goes dead, you will have to re-configure watch
settings after recharging. To ensure normal watch operation, be sure to keep it
exposed to light as much as possible.
Battery charges in the light.
Bright Light
Solar cell
(Converts light to
electrical power.)
LEVEL 1
LEVEL 2
LEVEL 3
Charge
LEVEL 4
Rechargeable battery
E-2
About This Manual
• Depending on the model of your watch, display text appears either as dark figures
on a light background, or light figures on a dark background. All sample displays in
this manual are shown using dark figures on a light background.
• Button operations are indicated using the letters shown in the illustration.
• Each section of this manual provides you with the information you need to perform
operations in each mode. Further details and technical information can be found in
the "Reference" section.
E-4
Procedure Lookup
The following is a handy reference list of all the operational procedures contained in
this manual.
To set the time and date ....................................................................................... E-12
To change the Daylight Saving Time (summer time) setting ............................ E-17
To view the time in another city ........................................................................... E-20
To toggle a city code time between Standard Time and
Daylight Saving Time ...................................................................................... E-21
To set an alarm time ............................................................................................. E-23
To turn the Hourly Time Signal on and off .......................................................... E-25
To turn off all alarms and the Hourly Time Signal .............................................. E-26
To measure times with the stopwatch ................................................................ E-28
E-6
General Guide
• Press B to change from mode to mode.
• In any mode, press A to illuminate the face of the watch.
• Holding down B for at least two seconds at any time will return directly to the
Timekeeping Mode.
Timekeeping Mode
E-8
Operation Guide 5200
Battery discharges in the dark.
Electrical
energy
All
LEVEL 1
functions
LEVEL 2
enabled
LEVEL 3
Dis-
charge
LEVEL 4
Battery Mode
Press B.
Keep the watch exposed to bright light
Bright Light
Solar cell
• The actual level at which some functions are disabled depends on the watch model.
• Frequent display illumination can run down the battery quickly and require charging.
The following guidelines give an idea of the charging time required to recover from a
single illumination operation.
Approximately 5 minutes exposure to bright sunlight coming in through a window
Approximately about 8 hours exposure to indoor fluorescent lighting
• Be sure to read "Power Supply" (page E-33) for important information you
need to know when exposing the watch to bright light.
If the display of the watch is blank...
If the display of the watch is blank, it means that the watch's Power Saving function
has turned off the display to conserve power.
• See "Power Saving Function" (page E-47) for more information.
Some or all
functions
disabled
Contents
General Guide ......................................................................................................... E-8
Timekeeping .......................................................................................................... E-11
World Time ............................................................................................................. E-19
Alarms .................................................................................................................... E-22
Stopwatch .............................................................................................................. E-27
Countdown Timer .................................................................................................. E-30
Power Supply ........................................................................................................ E-33
Adjusting Home Positions ................................................................................... E-41
Reference .............................................................................................................. E-45
Specifications ....................................................................................................... E-51
To use the tachymeter .......................................................................................... E-29
To configure the countdown timer ...................................................................... E-31
To use the countdown timer ................................................................................ E-32
To adjust home positions ..................................................................................... E-42
To turn the button operation tone on and off ..................................................... E-46
To recover from the sleep state ........................................................................... E-48
World Time Mode
Countdown Timer Mode
The electricity generated by the solar cell of the watch is
stored by a rechargeable battery. Leaving or using the
watch where it is not exposed to light causes the battery
to run down. Make sure the watch is exposed to light as
much as possible.
• When you are not wearing the watch on your wrist,
position the face so it is pointed at a source of bright
light.
• You should try to keep the watch outside of your sleeve
as much as possible. Charging is reduced significantly if
the face is covered only partially.
Alarm Mode
Stopwatch Mode
E-1
E-3
E-5
E-7
E-9
