SystemBase sLAN/all User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
sLAN/all
User Manual
Version 1.1.1 2018/06/11
www.sysbas.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the sLAN/all and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SystemBase sLAN/all

Summary of Contents for SystemBase sLAN/all

  • Page 1 User Manual Version 1.1.1 2018/06/11 www.sysbas.com...
  • Page 2 Revision History Document Revision Date Pages Description Version March. 6. 2017 June. 11. 2018 24-25 RS-422 Multi-Drop Mode Added...

  • Page 3: Table Of Contents

    User Manual Contents Preface  About This Manual  To Our Readers  Documents Related to sLAN/all  Technical Support Getting Started  Overview Features   Applied Field Hardware Specifications  Case and Connectors  LEDs  Serial Port Pin Specifications ...
  • Page 4 sWiFi/all User Manual Configuration Utility  Search  Configuration Appendix  Troubleshooting  Product Specifications...

  • Page 5: Preface

    This manual explains the connection, communication, configuration, and other management operations with sLAN/all. To Our Readers This manual is written for users and network managers using sLAN/all. We recommend reading this manual before using and configuring sLAN/all. The manual includes the details on utilizing the hardware and setting provided software.

  • Page 6: Technical Support

    User Manual Technical Support SystemBase provides technical support through two methods below: 1. Send an e-mail to our technical support team at tech@sysbas.com to receive fast responses. Any questions, requests, suggestions or comments are welcomed. 2. For instant response, call us. Our technical team will always provide detailed consultation and guides through a simple phone call.

  • Page 7: Getting Started

    This chapter provides an overview, function of sLAN/all, contents of package and applied field. Overview sLAN/all is a small converter allowing data transmission from serial (RS-232, RS-422, RS-485) to Ethernet. The connection standard supports IEEE 802.3 10/100Base-TX. It has a standard DE9 connector to providing maximum serial communication speed of 921.6kbps and RJ45 connector for Ethernet side with maximum 100Mbps...
  • Page 8 1 Unit of 5V DC Adaptor (or a Micro USB B Cable) 1 LAN Cable 1 sLAN/all Quick Manual (Paper Manual) Class A equipment Sellers or users should be aware of the fact that this device is intended for industrial use(Class A), not for...

  • Page 9: Applied Field

    Applied Field sLAN/all can be applied in many areas. Some examples are shown below. Serial Communication using Network Serial devices can be used from a computer, if a computer and a sLAN/all device are connected through the network. sLAN Serial Tunneling This allows the serial cable between a computer and a serial device to be extended through the network.
  • Page 10 User Manual COM Port Redirector By using COM port redirector, a virtual COM port utility, sLAN/all serial port (on the network) can be used as a physical serial port connected to a computer. sLAN Factory / Industry Automation PLC, Robot Arms, Human-Machine Interface, Logistic Storage Conveyor Belt...

  • Page 11: Hardware Specifications

     LED: Shows the status of sLAN/all.  LAN Port: This 8-pin RJ45 port is used for connecting sLAN/all to devices such as Ethernet card, hub, router, and other network devices.  Power Connector: The device supports both DC Adapters and Micro USB type B Power 5V DC 1A, Power Consumption: 0.90 W...

  • Page 12: Serial Port Pin Specifications

    Pin No. RS-232 RS-422 RS-485 TXD- TRXD- TXD+ TRXD+ RXD+ RXD- Reset Tact Switch Function Action Result Warm Booting Press for shorter than 3 seconds Restart sLAN/all Factory Default Press for longer than 3 seconds Re-initialize to the out-of-the-box status...

  • Page 13: Connecting Network

    (or Ethernet) port supports MDIX. Because the device automatically detects “Cross Ethernet Cable” and “Direct Ethernet Cable”, any types of cables can be used. Connect one end of a cable to sLAN/all, and another end to a network device. Making Connection To check the configure of the sLAN/all, you can either connect to the device with a web browser or use configuration utility.
  • Page 14 sWiFi/all User Manual...

  • Page 15: Configuration Web Page

    10Mbps To configure through the web page, the network speed must be 100Mbps or faster. If a sLAN/all is directly connected to the computer it will also work. If setting the below environment is difficult, use the SGConfig utility to configure the device. For directly connecting the device with your computer, please refer to Chapter 4 Connecting Network.

  • Page 16: Network Setting

    sWiFi/all User Manual Network Setting Network Setting page will be initially shown with network information when connecting from a web browser. The page looks like below: In [Network Setting], you can configure network environment. The [Submit] button must be clicked to save the changes you have made.
  • Page 17 The main features are as follows: Menu Default Description Device Name sLAN/all Display current name of the device. MAC Address Unique Address Displays current MAC Address. Choose whether to use a static IP, or DHCP (Dynamic IP) to get a IP...

  • Page 18: Operation Setting

    TCP Client A sLAN/all can run as a client to connect to the server in the same network. When the socket is connected, any data received from the sLAN/all will pass the socket and the serial port. The IP address of the server can be set from [Target IP/Port].
  • Page 19 For example, if the value is set to 0, when the serial device sends 100 bytes of ASCII through a sLAN/all to a socket in a server, the data will be sent to the server immediately. Although this allows for...
  • Page 20 sWiFi/all User Manual Menu Default Description transmission and reception. When this is set to enabled, TCP data is set immediately. Delays between communication is be minimized, but this is not suitable for high-speed data or packet transmission and reception.

  • Page 21: Serial Setting

    sWiFi/all User Manual Serial Setting In [Serial Setting], you can configure serial port environment. The [Submit] button must be clicked to save the changes you have made. For changes to take effect, the device must be rebooted. You can do it from [Reboot] menu. If changes are not saved, changed values will be lost when the device is turned off or rebooted.
  • Page 22 sWiFi/all User Manual Menu Default Description Current stop bit set for the serial communication Stop Bits (Options: 1, 2) Current parity bit set for the serial communication Parity (Options: No, Odd, Even) Current hardware flow control set for the serial communication If the RTS/CTS is chosen, RTS signal will be automatically controlled based on the flow of serial data, and serial data transmission will be automatically Flow Control...

  • Page 23: Change Id And Pw

    sWiFi/all User Manual Change ID and PW To connect to the web settings page, you need an ID and a password. They can be configured as shown in the below screen. This setting will take immediate effect without rebooting the device Reboot The device will be restarted.

  • Page 24: Configuration Utility

    Configuration Select the device you would like to configure from the searched list. Click the [Configure] button. A sLAN/all window will be displayed as shown below. For detailed information on how to use it, please refer to the SGConfig Manual.

  • Page 25: Appendix

    If the sLAN/all is set to receive the IP address automatically from the DHCP server, the IP address of the sLAN/all may change. In this case, set the IP address of the sLAN/all to be fixed from the DHCP server, or change the settings from the sLAN/all to have a fixed IP address.
  • Page 26 User Manual  Check if the computer and the sLAN/all are using the same subnet mask (For example, if the sLAN/all is using 255.255.255.0 as its subnet mask, your computer must use the same subnet mask). Also, check if the default gateway is set properly.

  • Page 27: Product Specifications

    COM Redirector, TestView, SGConfig Configuration A Web Browser, SGConfig Ordering Information sLAN/all *Reset Button Function Action Result Warm Booting Press for shorter than 3 seconds Restart sLAN/all Factory Default Press for longer than 3 seconds Re-initialize to the out-of-the-box status...
  • Page 28 User Manual Copyright Copyright ⓒ 2020 SystemBase CO., Ltd. All rights reserved. This manual is a document protected by Copyright law. Unauthorized copying, duplicating, publishing of some or all of contents without prior consent from SystemBase is against Copyright Law.
  • Page 29 If you have any inconvenience while using the product, please contact us. Email: Working Hour • Purchase/Quotation: overseas@sysbas.com MON ~ FRI 9:00 ~ 18:00 • Technical Support/RMA: tech@sysbas.com www.sysbas.com Tel: +82-2-855-0501 Fax: +82-2-855-0580 Copyright ⓒ 2020 SystemBase Co., Ltd. All Right Reserved.
