- Page 1 SystemBase User Manual...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ----------------------------------------------------------------------------------- 3 Key Features ----------------------------------------------------------------------- 3 CONTROLS AND INDICATORS --------------------------------------------------------------- 4 VFD Display ----------------------------------------------------------------------- 4 VU Meters -------------------------------------------------------------------------- 4 Menu Buttons --------------------------------------------------------------------- 4 DIAL Button ----------------------------------------------------------------------- 4 HANG Button ---------------------------------------------------------------------- 4 Numerical 0 - 9 Buttons --------------------------------------------------------- 4 FRONT &... -
Page 3: Introduction
INTRODUCTION The C530xr Audio Codec has been designed for the broadcast of high quality audio over digital networks, such as dedicated digital lines, optical fibre networks, digital microwave links and satellite links. To achieve an efficient utilisation of the available network data bandwidth, the C530xr uses apt-X100 4:1 fixed audio compression system to provide full duplex, point-to-point audio transmission. -
Page 4: Controls And Indicators
CONTROLS AND INDICATORS NO / Cancel button is used to answer No or to abort the configuration change. The NO button is also used to exit a menu level VFD Display and return to the level above. Pressing the A 24 character by 2 line VFD (Vacuum NO button several times will always take the Fluorescent Display), provides user back to the Title display. -
Page 5: Front & Rear Panels
FRONT & REAR PANELS... -
Page 6: Menu Map
MENU MAP TITLE AUDIO SCREEN STATUS STATUS X.21 AUDIO AUDIO SOURCE AUX DATA SYSTEM PASSWORD OPTIONS PASSWORD LOOP BACK ETHERNET ETHERNET OPTIONS DHCP DEFAULTS ADDRESS ETHERNET MASK ETHERNET GATEWAY DOWN RIGHT / EDIT BACKSPACE CONFIRM EDIT CANCEL EDIT / LEFT... -
Page 7: Menu System
MENU SYSTEM The menu system on the C530xr Audio Codec has been designed to allow the user to configure the unit with ease. Six keys are used to drive the menu system :- DOWN RIGHT / EDIT BACKSPACE CONFIRM EDIT... -
Page 8: X21 Audio
X21 Audio MENU: X21 Audio MENU: X 21 Audio MENU: X MENU: X 21 Audio 21 Audio APTX: 15K2 Stereo APTX: 15K2 Stereo 2 2 2 256Kbps APTX: 15K2 Stereo APTX: 15K2 Stereo 56Kbps 56Kbps 56Kbps buttons can be used to select the required X21 Audio format: APTX: 22K5 Stereo 384Kbps APTX: 15K2 Stereo... -
Page 9: System Options
MENU: Loopback MENU: Loopback MENU: Loopback The C530xr can be configured to provide an internal digital loopback of the compressed audio signal prior to the X.21 / ISDN interface. The loopback function will automatically use the highest data rate available. -
Page 10: Ip Address
IP Address MENU: Ethernet IP MENU: Ethernet IP MENU: Ethernet IP MENU: Ethernet IP 192.168.000.002 192.168.000.002 192.168.000.002 192.168.000.002 The current Ethernet IP Address of the codec can be configured. Ethernet Mask MENU: Ethernet MASK MENU: Ethernet MASK MENU: Ethernet MASK MENU: Ethernet MASK 255.255.255.000 255.255.255.000... -
Page 11: Ethernet Webserver
Ethernet Webserver Firstly configure the appropriate settings for your network in the Ethernet options menu. Once configured correctly connect the port labelled “LAN” to your router. On your computer web browser type in the IP address of the codec (http://192.168.0.2). A Windows Login screen will be displayed. -
Page 12: Email Alert Messages
Email Timing sent. Enter the full e-mail address (for example, test@systembase.com. If you leave this box blank, no alerts or logs will be sent Once the Email Alert has been configured to you. -
Page 13: Remote Management
(displays the codecs current status, /s option for short) The C530xr Codec can be configured remotely by connecting a straight 9 Way D- set x21 (APTX:3K7 Stereo 64Kbps, Type cable to the MGR IP port, and using the APTX:7K5 Mono 64Kbps, Standard Windows Terminal Program. -
Page 14: Physical Connections
X.21 Port PHYSICAL CONNECTIONS The electrical characteristics and the pin out of the connector is detailed below:- Analogue Audio X.21 Type Fixed DTE The audio interface presents balanced stereo X.21 Speed 64Kbps to 384Kbps XLR inputs and outputs. The electrical characteristics of these connections is X.21 Signals C, I, TXD, RXD, CLK... -
Page 15: Manager Output Port
Manager Output Port Alarm Signal The C530xr provides a set of alarm relay Type V.24/RS232 - Fixed DTE contacts with a minimum of 0.5 second Speed 9600bps (8,n,1) duration. These relay contacts are provided Signals TXD, RXD, SIG GND on the auxiliary data port connector. -
Page 16: Warranty Information
A “Declaration of Conformity” is available by Warranty Information contacting Systembase Limited. Systembase Limited warrants that this This product is designed and manufactured product is free from defects in materials or with high quality materials and components workmanship for 12 months from delivery. - Page 18 Information furnished is believed to be accurate and reliable at the time of publication. The manufacturer reserves the right to change details without notice. Systembase is a trademark of Systembase Limited. apt-X is a trademark of Audio Processing Technology Ltd. All trademarks and tradenames acknowledged. This document is not part of a contract or licence except as may be expressly agreed in writing.
