- Page 1 SystemBase ISDN CODECS USER MANUAL C510xr-C520xr Page 1 REL206 upwards...
-
Page 2: Table Of Contents
Table of Contents INTRODUCTION........3 Backup Master / Slave....11 Key Features........3 Nailed ISDN.......12 Auxiliary Data Port.....12 INSTALLATION.........4 Alarm..........12 Headroom........12 CONTROLS AND INDICATORS..4 System Options......12 VFD Display .........4 Country Options......12 VU Meters........4 ISDN Network......12 Menu Buttons.......4 ISDN SPID CH1 to 4....13 DIAL Button .........4 Password........13 Keypad Dial........4 Loopback........13... -
Page 3: Introduction
INTRODUCTION The C510xr / C520xr Audio Codecs have been designed for the broadcast of high quality audio over digital networks, such as ISDN, dedicated digital lines, optical fibre networks, digital microwave links and satellite links. To achieve an efficient utilisation of the available network data bandwidth, the C510xr / C520xr can be configured to use Dual G722, Dual G711 or apt-X100 4:1 fixed audio encoding system to provide full duplex, point-to-point audio transmission. -
Page 4: Installation
The first depression of the DIAL button will take the unit into the Keypad Dial menu as the first option. This allows the user to type in an ISDN number via All Systembase C500 series codecs are designed to the keypad. fit a standard 19” rack. Each unit measures 44.45mm high (1U). -
Page 5: Patch Dial
Note: The Keypad Dial Option will use the Audio configurations for the currently selected patch. Patch Dial The first depression of the DIAL button followed immediately by a second depression will take the unit into the Patch Dial menu, allowing the user to access 1 of 26 pre-stored configuration memories: MENU : Patch Dial PATCH 1... -
Page 6: Front & Rear Panels
FRONT & REAR PANELS Page 6... -
Page 7: Menu Map
MENU MAP TITLE ISDN CH 1 CLEARING SCREEN STATUS CALLER ID CAUSE 1 CH 2 CLEARING CALLER ID CAUSE 2 CH 3 CLEARING CALLER ID CAUSE 3 CH 4 CLEARING CALLER ID CAUSE 4 AUDIO STATUS STATUS SELECT PATCH MODIFY PATCH PATCH NAME... -
Page 8: Menu System
The select patch menu is used to load 1 to 26 Nail (Nailed Up Mode) available patch memories. Note: If the C510xr/C520xr is configured in X.21 Mode, the ISDN port can still function, however the audio will not be routed through to the ISDN connector. MENU: Select Patch... -
Page 9: Modify Patch
ISDN Audio Options Modify Patch MENU: ISDN Audio Options The user can then modify the settings associated with the selected patch by pressing the button. MENU: Modify Patch ISDN Audio Format PATCH 1 MENU: ISDN Audio Format APTX: 15K2 Stereo 256Kbps Patch Name ... -
Page 10: Auto Hunt
The ISDN parameters associated with each ISDN B MENU: CH1 Loc Subaddress Channel can be changed. The C510xr has 2 ISDN B Channels available and the C520xr has 4 ISDN B Channels. The following 3 option menus are repeated for all available Channels. -
Page 11: X21 Audio
Backup Monitor MENU: Codec Function ISDN Mode INFO: Backup Monitor Sync Errors The C510xr/C520xr Codec can operate in 1 of 5 selectable modes :- This menu displays the percentage of Sync Loss Errors in the last 10 seconds. ISDN Mode... -
Page 12: Nailed Isdn
ISDN Network MENU: ISDN Network The Auxiliary Data Port can be configured for the Euro ETSI following modes: Off, 9600bps, The C510xr/C520xr can be re-configured to operate 4800bps, on 1 of 12 International ISDN Standards: 2400bps, 9600bps(alt), Euro ETSI 4800bps(alt),... -
Page 13: Isdn Spid Ch1 To 4
001441256880123 100BASE-TX full-duplex The user can configure the ISDN SPID Codes which The C510xr / C520xr can be remotely managed via are required for operation in the USA and Canada the Ethernet Port. The display will show:- (National 1, DMS100 & Custom 5ESS). If the SPID... -
Page 14: Set Defaults
Set Defaults MENU: Set Defaults The codec can be re-configured back to the Factory Defaults. MENU: Set Defaults Confirm Yes/No ? Press the YES button to confirm, and the NO button to abort. NOTE: All changes made to the patch configurations will be lost and there is no Undo option. -
Page 15: Web Server
A Windows Login screen will be displayed. The default Username is “admin” and the default password is “admin”. If you wish to disable the password prompt then simply leave the password field blank. The screen shots below shows the layout of the Webserver for the C510xr/C520xr Codec. Page 15... -
Page 16: Easymon Network Monitor
EasyMON is a free network monitor tool that allows an organisation to monitor multiple codecs in a single browser window with minimal overhead. EasyMON is free, and maybe downloaded from the systembase website, www.systembase.com. Included in the download are instructions that will guide you through the correct configuration. -
Page 17: Remote Management
REMOTE MANAGEMENT set password (Not Set (pin), Edit Lock (pin), Full lock (pin)) The C510xr / C520xr Codec can be configured remotely by connecting a straight 9 Way D-Type set isdn (G711:3K2 Dual 64Kbps, cable to the MGR IP port, and using the Standard G722:7K5 Dual 64Kbps, Windows Terminal Program. - Page 18 0108-001>status SYSTEMBASE C510xr(c) Patch Name= Patch 1 Country= EURO ETSI Mode= ISDN Mode ISDN 1= Ready ISDN 2= Ready APTX Status= SYNC Loopback= Off Aux Data= Off Alarm= Sync Loss ISDN OPTIONS ISDN Audio= APTX:15K2 Mono 128Kbps ISDN Autohunt= Off...
-
Page 19: Physical Connections
PHYSICAL CONNECTIONS ISDN Ports Analogue Audio C510ip 1 x RJ45 Connector The audio interface presents balanced stereo XLR Listed below are the 12 international standards inputs and outputs. The electrical characteristics of supported. these connections is detailed below :- Euro ETSI I/P Impedance >10K Ohms China... -
Page 20: Manager Input Port
Relay 1 N/O Alarm Signal Opto 1 (i/p) The C510xr / C520xr provides a set of alarm relay contacts with a minimum of 0.5 second duration. * Opto Input – Trigger by strapping to ground. These relay contacts are provided on the auxiliary data port connector. -
Page 21: Physical Properties
PHYSICAL PROPERTIES WARRANTY INFORMATION Dimensions Systembase Limited warrants that this product is free from defects in materials or workmanship for 12 months from delivery. Upon proof of purchase, the Enclosure 1U, 19 inches - Rackmount product will be repaired or replaced (with same or... - Page 22 Information furnished is believed to be accurate and reliable at the time of publication. The manufacturer reserves the right to change details without notice. Systembase is a trademark of Systembase Limited. apt- X is a trademark of APT Licensing Ltd. All trademarks and tradenames acknowledged. This document is not part of a contract or licence except as may be expressly agreed in writing.
