- Page 1 Adr ana Bookcase assembly gu de...
- Page 2 ntroduct on Before start ng, please check all Furn ture parts are go ng to several Valued Customer, components and accessor es manufactur ng procedures. Dur ng th s accord ng to the prov ded l st. If process, parts can have l ttle dust or We des gn and carefully manufacture our you purchased more than one marks.
-
Page 3: Before You Start
before you start or o Get requ red nstallat on tools prepared. Do not nstall the product on rough surfaces. Get help from someone else! - Page 4 components Part1 Part2 Part3 Part4 Part5 Part6 TOTAL 3.5x25 mm screw 50 mm screw 12 mm sticker...
- Page 5 step a *Please attach the p eces #5 and #3 together as shown below *Now screw the A13(50 mm screw) w th the help of a screwdr ver clockw se d rect on step b *Please put the one of metal p eces on the p ece #3 as shown below *Now screw the A09(3.5x25 mm screw) w th the help of a screwdr ver clockw se d rect on...
- Page 6 step c *Please attach the p ece #6 to the p eces #3 and #5 as shown below *Now screw the A13(50 mm screw) w th the help of a screwdr ver clockw se d rect on step d *Please put the one of metal p eces on the p ece #3 as shown below *Then screw the A09(3.5x25 mm screw) w th the help of a screwdr ver clockw se d rect on *Please put the p ece #4 on the p ece #3 together as shown below *Now screw the A13(50 mm screw) w th the help of a screwdr ver clockw se d rect on...
- Page 7 step e *Please put the p ece #2 on the metal p ece and p ece #4 as shown below. *Then screw the A09(3.5x25 mm screw) on the metal p ece w th the help of a screwdr ver clockw se d rect on *Please put the p ece #4 and metal p ece on the p ece #2 as shown below *Now screw the A13(50 mm screw) on both p eces #4 w th the help of a screwdr ver clockw se d rect on *Then screw the A09(3.5x25 mm screw) on the metal p ece w th the help of a screwdr ver clockw se d rect on...
- Page 8 step f *Please put the p ece #2 on the metal p ece and p ece #4 as shown below. *Then screw the A09(3.5x25 mm screw) w th the help of a screwdr ver clockw se d rect on as shown below *Now screw the A13(50 mm screw) w th the help of a screwdr ver clockw se d rect on as shown below...
- Page 9 step g *Please put the metal p ece and p ece #4 on the p ece #2 as shown below. *Then screw the A09(3.5x25 mm screw) w th the help of a screwdr ver clockw se d rect on as shown below *Now screw the A13(50 mm screw) w th the help of a screwdr ver clockw se d rect on as shown below...
- Page 10 step h *Please put the p ece #1 on the metal p ece and p ece #4 as shown below. *Then screw the A09(3.5x25 mm screw) w th the help of a screwdr ver clockw se d rect on as shown below *Now screw the A13(50 mm screw) w th the help of a screwdr ver clockw se d rect on as shown below...
- Page 11 step j *For the best appearance of your furn ture please place all A06(12 mm st cker) onto the A13 (50 mm screw)
- Page 12 final look Enjoy your Decorot ka product! www.decorot ka.us contact@decorot ka.com www.decorot ka.com...
