- Page 1 SIMP HOME L I F E B Y D E S I G N ADRIEN / NOLAN / REMINGTON ENTRYWAY STORAGE BENCH MODEL # INT-AXCADR-BNCH-EB 1/15...
- Page 2 SIMP HOME L I F E B Y D E S I G N Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...
-
Page 3: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. Hardware package may have spare parts. -
Page 4: Care And Maintenance
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. - Page 5 MODEL # INT-AXCADR-BNCH-EB PRE-ASSEMBLY INFORMATION PARTS DESCRIPTION SEAT LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 BOTTOM SHELF LEFT DIVIDER RIGHT DIVIDER QTY 1 QTY 1 QTY 1 BACKREST BACK PANEL BOTTOM SUPPORT LEG QTY 1 QTY 1 QTY 1 BASKET QTY 3...
-
Page 6: Pre-Assembly Information
PRE-ASSEMBLY INFORMATION MODEL # INT-AXCADR-BNCH-EB HARDWARE DESCRIPTION WOOD DOWEL ALLEN KEY SCREW 8 X 30 mm M6 x 30 mm ALLEN KEY QTY 8 QTY 16 QTY 1 PHILLIPS SCREW ROUND HEAD ALLEN KEY BOLT M4 x 15 mm WOOD BOLT CAP M6 x 50 mm QTY 16 QTY 4... - Page 7 COMPONENTS – KEY DIAGRAM MODEL # INT-AXCADR-BNCH-EB 7/15...
- Page 8 ASSEMBLY MODEL # INT-AXCADR-BNCH-EB STEP 1 1. Insert 4 Wood Dowels 3 into Dividers C & C ( 2 Dowels per each Divider ). 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of dowels should be exposed.
- Page 9 ASSEMBLY MODEL # INT-AXCADR-BNCH-EB STEP 2 1. Attach Seat B to Dividers C & C using 4 Allen Key Screws 1 . 2. Use Allen Key 2 to tighten Screws. Do not over-tighten. 9/15...
- Page 10 ASSEMBLY MODEL # INT-AXCADR-BNCH-EB STEP 3 1. Insert 2 Dowels 3 into Bottom Shelf D . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of dowels should be exposed. 3. Attach Left Side AL to Bottom Shelf D and Seat B using 4 Allen Key Scews 1 . 4.
- Page 11 ASSEMBLY MODEL # INT-AXCADR-BNCH-EB STEP 4 1. Attach Backrest E to Left Side AL using 2 Allen Key Bolts 5 . 2. Use Allen Key 2 to tighten Bolts. Do not over-tighten. 11/15...
- Page 12 ASSEMBLY MODEL # INT-AXCADR-BNCH-EB STEP 5 1. Repeat Step-3 for the Right Side AR . 12/15...
- Page 13 ASSEMBLY MODEL # INT-AXCADR-BNCH-EB STEP 6 1. Attach Bottom Support Leg G to Bottom Shelf D . STEP 7 1. Attach Backrest E to Right Side AR using 2 Allen Key Bolts 5 . 2. Use Allen Key 2 to tighten Bolts. Do not over-tighten. 13/15...
- Page 14 ASSEMBLY MODEL # INT-AXCADR-BNCH-EB STEP 8 1. Attach Back F to back frame using 16 Phillips Screw Round Heads 4 . 2. Use Phillips screwdriver to snugly tighten screws. 3. Insert 4 Wood Bolt Caps 6 into exposed bolt holes on side of bench. STEP 9 14/15...
-
Page 15: Warranty
SIMP HOME L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase.
