- Page 1 S IMP HOME ® AVINGTON / MIA / HAYES FLOOR STORAGE CABINET MODEL # AXCBSAVN01-WH...
- Page 2 S IMP HOME ® Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –4 pm EST or go to www.simpli-home.com/parts request In order to assist you in a timely manner, please have the following...
-
Page 3: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. -
Page 4: Care And Maintenance
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. -
Page 5: Pre-Assembly Information
PRE-ASSEMBLY INFORMATION MODEL # AXCBSAVN01-WH PART DESCRIPTION LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 MIDDLE SHELF BOTTOM SHELF BACK BAR QTY 1 QTY 1 QTY 1 FRONT BAR BACK PANEL DOOR QTY 2 QTY 1 QTY 1 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext. -
Page 6: Hardware Description
PRE-ASSEMBLY INFORMATION MODEL # AXCBSAVN01-WH HARDWARE DESCRIPTION CAM LOCK PIN WOOD DOWEL CAM LOCK HINGE Ø8 X 30mm QTY 8 SETS QTY 2 QTY 24 PHILLIPS SCREW PHILLIPS SCREW MAGNET AND PLATE M4 X 50mm M3 X 15mm QTY 1 SET QTY 4 QTY 12 HANDLE... - Page 7 COMPONENTS-KEY DIAGRAM MODEL # AXCBSAVN01-WH...
- Page 8 ASSEMBLY MODEL # AXCBSAVN01-WH STEP-1 1. Attach four Cam Lock Pins 1 into pre-drilled holes on each Side BL , BR . 2. Insert two Dowels 2 into guide holes on each Side BL , BR . 3. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of Dowels should be exposed.
- Page 9 ASSEMBLY MODEL # AXCBSAVN01-WH STEP-2 1. Insert four Dowels 2 into guide holes on each part C , D , E , F . 2. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of Dowels should be exposed.
- Page 10 ASSEMBLY MODEL # AXCBSAVN01-WH STEP-3 1. Align Cam Lock Pin and Wood Dowels with guide holes on parts BR , C , D and attach parts C , D to Right Side BR . 2. Insert two Cam Locks 1 into guide holes on each part C , D . 3.
- Page 11 ASSEMBLY MODEL # AXCBSAVN01-WH STEP-5 1. Repeat Step-3 and Step-4 for the Left Side BL .
- Page 12 ASSEMBLY MODEL # AXCBSAVN01-WH STEP-6 1. Align Wood Dowels with guide holes and attach Top A to Sides BL , BR . 2. Use four Phillips Screws 5 to attach Top A through guide holes from Sides BL , BR to pre-drilled holes of Top A . 3.
- Page 13 ASSEMBLY MODEL # AXCBSAVN01-WH STEP-8 STEP-9...
- Page 14 FURNITURE TIP OVER RESTRAINT ASSEMBLY WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. STEP-10 NOTE: The screwdriver is not included in the hardware pack.
- Page 15 FURNITURE TIP OVER RESTRAINT ASSEMBLY Furniture Tip Over Restraint Instructions: Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
-
Page 16: Warranty
S IMP HOME ® WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase. This warranty does not affect your statutory rights.
