Electrical Hazard: Only qualified personnel should perform installation
procedures.
Notice
Enterasys Networks reserves the right to make changes in specifications and other information
contained in this document and its web site without prior notice. The reader should in all cases
consult Enterasys Networks to determine whether any such changes have been made.
The hardware, firmware, or software described in this document is subject to change without
notice.
IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL,
INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT
NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS DOCUMENT,
WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF ENTERASYS
NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE KNOWN OF, THE
POSSIBILITY OF SUCH DAMAGES.
Enterasys Networks, Inc.
50 Minuteman Road
Andover, MA 01810
© 2004 Enterasys Networks, Inc. All rights reserved.
Part Number: 9033975-01 October 2004
ENTERASYS NETWORKS, ENTERASYS MATRIX, LANVIEW, MATRIX, NETSIGHT, WEBVIEW,
and any logos associated therewith, are trademarks or registered trademarks of Enterasys
Networks, Inc. in the United States and other countries.
All other product names mentioned in this manual may be trademarks or registered trademarks of
their respective companies.
Regulatory Compliance Information
Federal Communications Commission (FCC) Notice
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a class A digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment uses, generates, and can radiate radio frequency energy and if not
installed in accordance with the operator's manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause interference in
which case the user will be required to correct the interference at his own expense.
WARNING: Changes or modifications made to this device which are not expressly approved by
the party responsible for compliance could void the user's authority to operate the equipment.
Industry Canada Notice
This digital apparatus does not exceed the class A limits for radio noise emissions from digital
apparatus set out in the Radio Interference Regulations of the Canadian Department of
Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage
radioélectrique édicté par le ministère des Communications du Canada.
AS/NZS CISPR 22
N826
VCCI Notice
This is a class A product based on the standard of the Voluntary Control Council for Interference
by Information Technology Equipment (VCCI). If this equipment is used in a domestic
environment, radio disturbance may arise. When such trouble occurs, the user may be required to
take corrective actions.
Class A ITE Notice
WARNING: This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
BSMI EMC Statement — Taiwan
This is a class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
Environmental Requirements
Operating Temperature:
0°C to 50°C (32°F to 122°F)
Storage Temperature:
-40°C to 70°C (-40°F to 158°F)
Operating Relative Humidity:
5% to 95% (non-condensing)
Product Safety
This product complies with the following: UL 60950, CSA C22.2 No. 60950, 73/23/EEC, EN 60950,
IEC 60950, EN 60825, 21 CFR 1040.10.
Electromagnetic Compatibility (EMC)
This product complies with the following: 47 CFR Parts 2 and 15, CSA C108.8, 89/336/EEC,
EN 55022, EN 61000-3-2, EN 61000-3-3, EN 55024, AS/NZS CISPR 22, VCCI V-3.
Safety Compliance
Warning: Fiber Optic Port Safety
When using a fiber optic media expansion module, never look at the
transmit laser while it is powered on. Also, never look directly at the
fiber TX port and fiber cable ends when they are powered on.
Avertissment: Ports pour fibres optiques - sécurité sur le plan optique
Ne regardez jamais le laser tant qu'il est sous tension. Ne regardez
jamais directement le port TX (Transmission) à fibres optiques et les
embouts de câbles à fibres optiques tant qu'ils sont sous tension.
Warnhinweis: Faseroptikanschlüsse - Optische Sicherheit
Niemals ein Übertragungslaser betrachten, während dieses
eingeschaltet ist. Niemals direkt auf den Faser-TX-Anschluß und auf
die Faserkabelenden schauen, während diese eingeschaltet sind.
Safety Information
Class 1 Laser Transceivers
Laser Radiation and Connectors
When the connector is in place, all laser radiation remains within the fiber. The maximum amount
of radiant power exiting the fiber (under normal conditions) is -12.6 dBm or
-6
55 x 10
watts.
Removing the optical connector from the transceiver allows laser radiation to emit directly from
the optical port. The maximum radiance from the optical port (under worst case conditions) is 0.8
-2
3
2
W cm
or 8 x 10
W m
sr-1.
Do not use optical instruments to view the laser output. The use of optical instruments to view
laser output increases eye hazard. When viewing the output optical port, power must be removed
from the network adapter.
Please read the following safety information carefully before installing the switch:
WARNING: Installation and removal of the unit must be carried out by qualified personnel only.
• This guide is intended for use by network administrators who are responsible for setting up
and installing network equipment; consequently it assumes a basic working knowledge of
LANs (Local Area Networks).
• The unit must be connected to an earthed (grounded) outlet to comply with international safety
standards.
• Do not connect the unit to an A.C. outlet (power supply) without an earth (ground) connection.
• The appliance coupler (the connector to the unit and not the wall plug) must have a
configuration for mating with an EN 60320/IEC 320 appliance inlet.
• The socket outlet must be near to the unit and easily accessible. You can only remove power
from the unit by disconnecting the power cord from the outlet.
• This unit operates under SELV (Safety Extra Low Voltage) conditions according to IEC 60950.
The conditions are only maintained if the equipment to which it is connected also operates
under SELV conditions.
France and Peru only
This unit cannot be powered from IT
supplies. If your supplies are of IT type, this unit must be
powered by 230 V (2P+T) via an isolation transformer ratio 1:1, with the secondary connection
point labelled Neutral, connected directly to earth (ground).
Impédance à la terre
Power Cord Set
U.S.A. and Canada
The cord set must be UL-approved and CSA certified.
The minimum specifications for the flexible cord are:
- No. 18 AWG - not longer than 2 meters, or 16 AWG.
- Type SV or SJ
- 3-conductor
The cord set must have a rated current capacity of at least 10 A
The attachment plug must be an earth-grounding type with NEMA 5-15P
(15 A, 125 V) or NEMA 6-15P (15 A, 250 V) configuration.
Denmark
The supply plug must comply with Section 107-2-D1, Standard DK2-1a
or DK2-5a.
Switzerland
The supply plug must comply with SEV/ASE 1011.
U.K.
The supply plug must comply with BS1363 (3-pin 13 A) and be fitted with
a 5 A fuse which complies with BS1362.
The mains cord must be <HAR> or <BASEC> marked and be of type
HO3VVF3GO.75 (minimum).
Europe
The supply plug must comply with CEE7/7 ("SCHUKO").
The mains cord must be <HAR> or <BASEC> marked and be of type
HO3VVF3GO.75 (minimum).
IEC-320 receptacle.
Veuillez lire à fond l'information de la sécurité suivante avant d'installer le Switch:
AVERTISSEMENT: L'installation et la dépose de ce groupe doivent être confiés à un personnel
qualifié.
• Ne branchez pas votre appareil sur une prise secteur (alimentation électrique) lorsqu'il n'y a pas
de connexion de mise à la terre (mise à la masse).
• Vous devez raccorder ce groupe à une sortie mise à la terre (mise à la masse) afin de respecter
les normes internationales de sécurité.
• Le coupleur d'appareil (le connecteur du groupe et non pas la prise murale) doit respecter une
configuration qui permet un branchement sur une entrée d'appareil EN 60320/IEC 320.
• La prise secteur doit se trouver à proximité de l'appareil et son accès doit être facile. Vous ne
pouvez mettre l'appareil hors circuit qu'en débranchant son cordon électrique au niveau de
cette prise.
• L'appareil fonctionne à une tension extrêmement basse de sécurité qui est conforme à la norme
IEC 60950. Ces conditions ne sont maintenues que si l'équipement auquel il est raccordé
fonctionne dans les mêmes conditions.
France et Pérou uniquement:
Ce groupe ne peut pas être alimenté par un dispositif à impédance à la terre. Si vos alimentations
sont du type impédance à la terre, ce groupe doit être alimenté par une tension de 230 V (2 P+T) par
le biais d'un transformateur d'isolement à rapport 1:1, avec un point secondaire de connexion
portant l'appellation Neutre et avec raccordement direct à la terre (masse).
Cordon électrique - Il doit être agréé dans le pays d'utilisation
Etats-Unis et
Le cordon doit avoir reçu l'homologation des UL et un certificat de la CSA.
Canada:
Les spe'cifications minimales pour un cable flexible sont AWG No. 18, ouAWG
No. 16 pour un cable de longueur infe'rieure a` 2 me'tres.
- type SV ou SJ
- 3 conducteurs
Le cordon doit être en mesure d'acheminer un courant nominal d'au moins 10 A.
La prise femelle de branchement doit être du type à mise à la terre (mise à la
masse) et respecter la configuration NEMA 5-15P (15 A, 125 V) ou NEMA 6-15P
(15 A, 250 V).
Danemark:
La prise mâle d'alimentation doit respecter la section 107-2 D1 de la norme DK2
1a ou DK2 5a.
Suisse:
La prise mâle d'alimentation doit respecter la norme SEV/ASE 1011.
Europe
La prise secteur doit être conforme aux normes CEE 7/7 ("SCHUKO")
LE cordon secteur doit porter la mention <HAR> ou <BASEC> et doit être de type
HO3VVF3GO.75 (minimum).
Bitte unbedingt vor dem Einbauen des Switches die folgenden
Sicherheitsanweisungen durchlesen:
WARNUNG: Die Installation und der Ausbau des Geräts darf nur durch Fachpersonal erfolgen.
• Diese Anleitung ist fr die Benutzung durch Netzwerkadministratoren vorgesehen, die fr die
Installation und das einstellen von Netzwerkkomponenten verantwortlich sind; sie setzt
Erfahrung bei der Arbeit mit LANs (Local Area Networks) voraus.
• Das Gerät sollte nicht an eine ungeerdete Wechselstromsteckdose angeschlossen werden.
• Das Gerät muß an eine geerdete Steckdose angeschlossen werden, welche die internationalen
Sicherheitsnormen erfüllt.
• Der Gerätestecker (der Anschluß an das Gerät, nicht der Wandsteckdosenstecker) muß einen
gemäß EN 60320/IEC 320 konfigurierten Geräteeingang haben.
• Die Netzsteckdose muß in der Nähe des Geräts und leicht zugänglich sein. Die
Stromversorgung des Geräts kann nur durch Herausziehen des Gerätenetzkabels aus der
Netzsteckdose unterbrochen werden.
• Der Betrieb dieses Geräts erfolgt unter den SELV-Bedingungen (Sicherheitskleinstspannung)
gemäß IEC 60950. Diese Bedingungen sind nur gegeben, wenn auch die an das Gerät
angeschlossenen Geräte unter SELV-Bedingungen betrieben werden.
Stromkabel. Dies muss von dem Land, in dem es benutzt wird geprüft werden:
Schweiz
Dieser Stromstecker muß die SEV/ASE 1011Bestimmungen einhalten.
Europe
Das Netzkabel muß vom Typ HO3VVF3GO.75 (Mindestanforderung)
sein und die Aufschrift <HAR> oder <BASEC> tragen.
Der Netzstecker muß die Norm CEE 7/7 erfüllen ("SCHUKO").
Declaration of Conformity
Application of Council Directive(s): 89/336/EEC
73/23/EEC
Manufacturer's Name: Enterasys Networks, Inc.
Manufacturer's Address: 50 Minuteman Road
Andover, MA 01810
USA
European Representative Address: Enterasys Networks Ltd.
Nexus House, Newbury
Business Park
London Road, Newbury
Berkshire RG14 2PZ, England
Conformance to Directive(s)/
Product Standards: EC Directive 89/336/EEC
EN 55022
EN 55024
EC Directive 73/23/EEC
EN 60950
EN 60825
Equipment Type/Environment: Networking Equipment,
for use in a Commercial
or Light Industrial Environment.
Enterasys Networks, Inc. declares that the equipment packaged with this notice
conforms to the above directives.
Product Warranty
The Matrix V-Series includes a Limited Lifetime Warranty.
You must register your product with Enterasys Networks
within 30 days after receipt.
To register your product, go to
http://www.enterasys.com/products/switching/v-warranty/
Please complete all sections of the form to ensure warranty coverage.
Getting Help
For additional support related to the product or this document, contact Enterasys Networks using
one of the following methods:
Web
http://www.enterasys.com/support
Phone
603-332-9400
1-800-872-8440 (toll-free in U.S. and Canada)
For the Enterasys Networks Support toll-free number in your country:
http://www.enterasys.com/support/gtac-all.html
Internet mail
support@enterasys.com
To expedite your message, please type [eth] in the subject line.
Matrix V-Series
V2H124-24FX
Fast Ethernet Switch

Quick Reference Guide

Note: You can view and download all V2H124-24FX
documentation from the Enterasys web site:
http://www.enterasys.com/support/manuals
Enterasys Networks
50 Minuteman Road
Andover, MA 018107
Phone: 978.684.1000
www.enterasys.com
PN 9033975-01

Advertisement

loading
