Summary of Contents for Enterasys Vertical Horizon VHIM1000-S1TX
-
Page 1: Gigabit Ethernet
VERTICAL HORIZON VHIM1000-S1TX GIGABIT ETHERNET EXPANSION MODULE USER GUIDE 9033666... - Page 3 Enterasys Networks reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made. The hardware, firmware, or software described in this manual is subject to change without notice.
-
Page 4: Fcc Notice
Notice FCC NOTICE This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. - Page 5 WICHTIGE SICHERHEITSHINWEISE (GERMANY) Bitte lesen Sie diese Hinweise sorgfältig durch. Heben Sie diese Anleitung für den späteren Gebrauch auf. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssigoder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung. Die Netzanschlu ßsteckdose soll nahe dem Gerät angebracht und leicht zugänglich sein.
-
Page 6: Program License Agreement
This document is an agreement (“Agreement”) between You, the end user, and Enterasys Networks, Inc. (“Enterasys”) that sets forth your rights and obligations with respect to the Enterasys software program (“Program”) in the package. The Program may be contained in firmware, chips or other media. - Page 7 Software-Restricted Rights Clause and its successors, and (iii) in all respects is proprietary data belonging to Enterasys and/or its suppliers. For Department of Defense units, the Product is considered commercial computer software in accordance with DFARS section 227.7202-3 and its successors, and use, duplication, or disclosure by the Government is subject to restrictions set forth herein.
-
Page 8: Declaration Of Conformity
Compliance Engineering Manager ___________________________________ Title Rochester, NH, USA ___________________________________ Location 89/336/EEC 73/23/EEC Enterasys Networks, Inc. 35 Industrial Way PO Box 5005 Rochester, NH 03867 Mr. J. Sims Enterasys Networks Limited Nexus House, Newbury Business Park London Road, Newbury Berkshire RG14 2PZ, England... -
Page 9: Table Of Contents
TABLE OF CONTENTS 1. DESCRIPTION OF HARDWARE........1 Gigabit Uplink Module . - Page 10 viii Table of Contents VHIM1000-S1TX...
-
Page 11: Description Of Hardware
1. DESCRIPTION OF HARDWARE Gigabit Uplink Module The Enterasys Networks VHIM1000-S1TX module is designed for use in Vertical Horizon switch models that have a Gigabit Ethernet transceiver slot. At present, suitable units include these Vertical Horizon models – VH-2402S and VH-4802. Detailed information about configuring these modules and advice about Gigabit Ethernet configuration rules can be found in the switch’s User Guide. -
Page 12: 1000Base-T Cable Requirements
1000Base-T Cable Requirements All Category 5 UTP cables that are used for 100Base-TX connections should also work for 1000Base-T, providing that all four wire pairs are connected. However, it is recommended that for all critical connections, or any new cable installations, Category 5e (enhanced Category 5) cable should be used. -
Page 13: Installing The Module
2. INSTALLING THE MODULE CAUTION: Do not install this module in any unit other than the VH-2402S or VH-4802. Contact Enterasys for advice on newly released switches that may be designed for use with these modules. The VHIM1000-S1TX module is field installable. Just follow the instructions below. -
Page 14: Instructions
Power off the switch: Disconnect the AC power cord from the switch. If a redundant power unit (RPU) is present, disconnect its DC cable connection from the switch. Remove network cables: If you are replacing a module, remove the cable attached to any port on the module. - Page 15 Be sure the new module’s front panel is flush with the switch panel.
- Page 16 Power on the switch: Reconnect the previously removed power sources to the switch. Check the LED indicators for the module port on the switch’s front panel to be sure that it is operating correctly. Refer to “Gigabit Port LEDs” on page 1 for a description of the LED indications.
-
Page 17: Appendix A. Troubleshooting
APPENDIX A. TROUBLESHOOTING If you experience any problems with the module, check the following items before contacting Enterasys Technical Support: • Ensure that the switch with the module is powered up. • Ensure that the device attached to the module is powered up and operating correctly. - Page 18 8 Troubleshooting VHIM1000-S1TX...
-
Page 19: Appendix B. Technical Specifications
APPENDIX B. TECHNICAL SPECIFICATIONS General Standards Compliance IEEE 802.1D Transparent Bridging Specifications (ISO/IEC 10038) IEEE 802.1p Traffic Class Expediting and Dynamic Multicast Filtering IEEE 802.1Q Virtual Bridged Local Area Networks IEEE 802.2 Local Area Networks, Logical Link Control (LLC) IEEE 802.3 CSMA/CD 9 (ISO/IEC 8802-3) IEEE 802.3i 10Base-T (ISO/IEC 8802-3, clause 14) IEEE 802.3u 100Base-TX (ISO/IEC 8802-3, clause 25) IEEE 802.3ab 1000Base-T... -
Page 20: Physical Specifications
Physical Specifications Height: Length: Width: 10 Technical Specifications 1.08 in. (2.74 cm) 3.57 in. (9.07 cm) 4.82 in. (12.25 cm) VHIM1000-S1TX... -
Page 21: Port Specifications
The figure below shows the wiring scheme for implementing a crossover cable if needed for connection to the switch’s 10Base-T or 100Base-TX ports. Such a cable may be required when connecting the switch to another switch or a hub device. -
Page 22: 1000Base-T Ports
1000Base-T Ports The table below shows the 1000Base-T pinouts for a straight-through cable connection. These ports require that all four pairs of wires be connected. Note that for 1000Base-T operation, all four pairs of wires are used for both transmit and receive. Connector A 12 Technical Specifications <- - - - - - - - - - - - - - - - - ->... -
Page 23: Appendix C. Maximum Cable Lengths
APPENDIX C. MAXIMUM CABLE LENGTHS Cable 10Base-T 100Base-TX 100Base-FX 1000Base-SX 1000Base-LX 1000Base-T Maximum 1000Base-SX Gigabit Ethernet Cable Length Fiber Size 62.5/125 micron MMF 50/125 micron MMF Maximum 1000Base-LX Gigabit Ethernet Cable Length Fiber Size 62.5/125 micron MMF 50/125 micron MMF 10/125 micron SMF 9033666 Cable Types and Specifications... - Page 24 14 Maximum Cable Lengths VHIM1000-S1TX...
- Page 26 150609-102 R01...
