  • Page 1 Maintain ONTAP Systems NetApp November 23, 2021 This PDF was generated from https://docs.netapp.com/us-en/ontap-systems/a400/bootmedia-replace- overview.html on November 23, 2021. Always check docs.netapp.com for the latest.

  • Page 2: Table Of Contents

      Replace a PCIe or mezzanine card - AFF A400 ..........

  • Page 3: Maintain

    ◦ If the impaired node is in a standalone configuration and at LOADER prompt, contact NetApp Support. mysupport.netapp.com 2. If AutoSupport is enabled, suppress automatic case creation by invoking an AutoSupport message: system node autosupport invoke -node * -type all -message...
  • Page 4 Check NVE or NSE on systems running ONTAP 9.6 and later Before shutting down the impaired node, you need to verify whether the system has either NetApp Volume Encryption (NVE) or NetApp Storage Encryption (NSE) enabled. If so, you need to verify the configuration.
  • Page 5 Restored yes: a. Restore the external key management authentication keys to all nodes in the cluster: security key- manager external restore If the command fails, contact NetApp Support. mysupport.netapp.com b. Verify that the column equals for all authentication keys: Restored...
  • Page 6 Key Manager external Restored yes: a. Enter the onboard security key-manager sync command: security key-manager external sync If the command fails, contact NetApp Support. mysupport.netapp.com b. Verify that the column equals for all authentication keys: Restored security key-manager key query c.
  • Page 7 Shut down the impaired controller - AFF A400 Option 1: Most configurations After completing the NVE or NSE tasks, you need to complete the shutdown of the impaired node. Steps 1. If the impaired node isn’t at the LOADER prompt: If the impaired node displays…...
  • Page 8 About this task • If you are using NetApp Storage Encryption, you must have reset the MSID using the instructions in the "Returning SEDs to unprotected mode" section of Administration overview with the CLI.
  • Page 9 If the impaired node… Then… Has not automatically switched Review the veto messages and, if possible, resolve the issue and try over, you attempted switchover again. If you are unable to resolve the issue, contact technical support. with the metrocluster command, and the switchover switchover was vetoed...
  • Page 10 8. On the impaired controller module, disconnect the power supplies. Remove the controller module, replace the boot media and transfer the boot image to the boot media - AFF A400 To replace the boot media, you must remove the impaired controller module, install the replacement boot media, and transfer the boot image to a USB flash drive.
  • Page 11 NetApp Support Site. You must log into the NetApp Support Site to display the Statement of Volatility for your system. You can use the following animation, illustration, or the written steps to replace the boot media.
  • Page 12 Locking tabs Slide air duct toward back of controller Rotate air duct up a. Press the locking tabs on the sides of the air duct in toward the middle of the controller module. b. Slide the air duct toward the back of the controller module, and then rotate it upward to its completely open position.
  • Page 13 Press blue button Rotate boot media up and remove from socket a. Press the blue button at the end of the boot media until the lip on the boot media clears the blue button. b. Rotate the boot media up and gently pull the boot media out of the socket. 3.
  • Page 14 Steps 1. Download and copy the appropriate service image from the NetApp Support Site to the USB flash drive. a. Download the service image to your work space on your laptop. b. Unzip the service image.
  • Page 15 7. Complete the installation of the controller module: a. Plug the power cord into the power supply, reinstall the power cable locking collar, and then connect the power supply to the power source. b. Firmly push the controller module into the chassis until it meets the midplane and is fully seated. The locking latches rise when the controller module is fully seated.
  • Page 16 The changes will be implemented when the system is booted. Booting the recovery image - AFF A400 The procedure for booting the impaired node from the recovery image depends on whether the system is in a two-node MetroCluster configuration.
  • Page 17 If your system has… Then… No network connection a. Press when prompted to restore the backup configuration. b. Reboot the system when prompted by the system. c. Select the Update flash from backup config (sync flash) option from the displayed menu. If you are prompted to continue with the update, press y.
  • Page 18 Reboot the node. Switch back aggregates in a two-node MetroCluster configuration - AFF A400 After you have completed the FRU replacement in a two-node MetroCluster configuration, you can perform the MetroCluster switchback operation. This returns the configuration to its normal operating state, with the sync-source storage virtual machines (SVMs) on the formerly impaired site now active and serving data from the local disk pools.
  • Page 19 cluster_B::> metrocluster node show Configuration Group Cluster Node State Mirroring Mode ----- ------- -------------- -------------- --------- -------------------- cluster_A   controller_A_1 configured enabled heal roots completed   cluster_B   controller_B_1 configured enabled waiting for switchback recovery 2 entries were displayed. 2. Verify that resynchronization is complete on all SVMs: metrocluster vserver show 3.
  • Page 20 Restore OKM, NSE, and NVE as needed - AFF A400 Once environment variables are checked, you must complete steps specific to systems that have Onboard Key Manager (OKM), NetApp Storage Encryption (NSE) or NetApp Volume Encryption (NVE) enabled. 1. Determine which section you should use to restore your OKM, NSE, or NVE configurations: If NSE or NVE are enabled along with Onboard Key Manager you must restore settings you captured at the beginning of this procedure.
  • Page 21 --------------------------BEGIN BACKUP-------------------------- TmV0QXBwIEtleSBCbG9iAAEAAAAEAAAAcAEAAAAAAADuD+byAAAAACEAAAAAAAAA QAAAAAAAAABvOlH0AAAAAMh7qDLRyH1DBz12piVdy9ATSFMT0C0TlYFss4PDjTaV dzRYkLd1PhQLxAWJwOIyqSr8qY1SEBgm1IWgE5DLRqkiAAAAAAAAACgAAAAAAAAA 3WTh7gAAAAAAAAAAAAAAAAIAAAAAAAgAZJEIWvdeHr5RCAvHGclo+wAAAAAAAAAA IgAAAAAAAAAoAAAAAAAAAEOTcR0AAAAAAAAAAAAAAAACAAAAAAAJAGr3tJA/ LRzUQRHwv+1aWvAAAAAAAAAAACQAAAAAAAAAgAAAAAAAAACdhTcvAAAAAJ1PXeBf ml4NBsSyV1B4jc4A7cvWEFY6lLG6hc6tbKLAHZuvfQ4rIbYAAAAAAAAAAAAAAAAA AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA ..H4nPQM0nrDRYRa9SCv8AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA AAAAAAAA ---------------------------END BACKUP--------------------------- 7. At the Boot Menu select the option for Normal Boot. The system boots to Waiting for giveback… prompt. 8. Move the console cable to the partner node and login as "admin". 9.
  • Page 22 If the column = anything other than yes/true, contact Customer Support. Restored d. Wait 10 minutes for the key to synchronize across the cluster. 13. Move the console cable to the partner node. 14. Give back the target node using the command.

  • Page 23: Chassis

    -auto-giveback true Return the failed part to NetApp - AFF A400 After you replace the part, you can return the failed part to NetApp, as described in the RMA instructions shipped with the kit. Contact technical support at NetApp...
  • Page 24 • This procedure is disruptive. For a two-node cluster, you will have a complete service outage and a partial outage in a multi-node cluster. Shut down the controllers - AFF A400 Option 1: Shut down the controllers when replacing a chassis You must shut down the node or nodes in the chassis prior to moving them to the new chassis.
  • Page 25 About this task • If you are using NetApp Storage Encryption, you must have reset the MSID using the instructions in the "Returning SEDs to unprotected mode" section of Administration overview with the CLI.
  • Page 26 command from the surviving cluster. controller_A_1::> metrocluster heal -phase aggregates [Job 130] Job succeeded: Heal Aggregates is successful. If the healing is vetoed, you have the option of reissuing the command with the metrocluster heal -override-vetoes parameter. If you use this optional parameter, the system overrides any soft vetoes that prevent the healing operation.
  • Page 27   Errors: - 8. On the impaired controller module, disconnect the power supplies. Move and replace hardware - AFF A400 Step 1: Remove the controller modules To replace the chassis, you must remove the controller modules from the old chassis.
  • Page 28 that it does not swing out of the chassis. The fan modules are short. Always support the bottom of the fan module with your free hand so that it does not suddenly drop free from the chassis and injure you. 5.
  • Page 29 If your system stops at the boot menu, select the option to boot to LOADER. 4. Repeat the preceding steps to install the second controller into the new chassis. Complete the restoration and replacement process - AFF A400 Step 1: Verify and set the HA state of the chassis You must verify the HA state of the chassis, and, if necessary, update the state to match your system configuration.
  • Page 30 ▪ mcc-2n ▪ mccip ▪ non-ha b. Confirm that the setting has changed: ha-config show 3. If you have not already done so, recable the rest of your system. 4. Reinstall the bezel on the front of the system. Step 2: Run diagnostics After you have replaced a component in your system, you should run diagnostic tests on that component.
  • Page 31 cluster_B::> metrocluster node show Configuration Group Cluster Node State Mirroring Mode ----- ------- -------------- -------------- --------- -------------------- cluster_A   controller_A_1 configured enabled heal roots completed   cluster_B   controller_B_1 configured enabled waiting for switchback recovery 2 entries were displayed. 2. Verify that resynchronization is complete on all SVMs: metrocluster vserver show 3.

  • Page 32: Controller Module

    Step 4: Return the failed part to NetApp After you replace the part, you can return the failed part to NetApp, as described in the RMA instructions shipped with the kit. Contact technical support at NetApp Support, 888- 463-8277 (North America), 00-800-44-638277 (Europe), or +800-800-80-800 (Asia/Pacific) if you need the RMA number or additional help with the replacement procedure.
  • Page 33 Option 1: Most systems To shut down the impaired node, you must determine the status of the node and, if necessary, take over the node so that the healthy node continues to serve data from the impaired node storage. If you have a cluster with more than two nodes, it must be in quorum. If the cluster is not in quorum or a healthy node shows false for eligibility and health, you must correct the issue before shutting down the impaired node;...
  • Page 34 About this task • If you are using NetApp Storage Encryption, you must have reset the MSID using the instructions in the "Returning SEDs to unprotected mode" section of Administration overview with the CLI.
  • Page 35 If the impaired node… Then… Has not automatically switched Perform a planned switchover operation from the healthy node: over metrocluster switchover Has not automatically switched Review the veto messages and, if possible, resolve the issue and try over, you attempted switchover again.
  • Page 36 Errors: - 8. On the impaired controller module, disconnect the power supplies. Move the controller module hardware - AFF A400 To replace the controller module hardware, you must remove the impaired node, move FRU components to the replacement controller module, install the replacement controller module in the chassis, and then boot the system to Maintenance mode.
  • Page 37 6. Slide the controller module out of the chassis. Make sure that you support the bottom of the controller module as you slide it out of the chassis. 7. Place the controller module on a stable, flat surface. 8. On the replacement controller module, open the air duct and remove the empty risers from the controller module using the animation, illustration, or the written steps: Removing the empty risers from the replacement controller module...
  • Page 38 a. Press the locking tabs on the sides of the air duct in toward the middle of the controller module. b. Slide the air duct toward the back of the controller module, and then rotate it upward to its completely open position.
  • Page 39 a. Rotate the cam handle so that it can be used to pull the power supply out of the chassis. b. Press the blue locking tab to release the power supply from the chassis. c. Using both hands, pull the power supply out of the chassis, and then set it aside. 2.
  • Page 40 1. Open the air duct: a. Press the locking tabs on the sides of the air duct in toward the middle of the controller module. b. Slide the air duct toward the back of the controller module, and then rotate it upward to its completely open position.
  • Page 41 You can use the following animation, illustration, or the written steps to move the boot media from the impaired controller module to the replacement controller module. Moving the boot media 1. Locate and remove the boot media from the controller module: a.
  • Page 42 Step 5: Move the PCIe risers and mezzanine card As part of the controller replacement process, you must move the PCIe risers and mezzanine card from the impaired controller module to the replacement controller module. You can use the following animations, illustrations, or the written steps to move the PCIe risers and mezzanine card from the impaired controller module to the replacement controller module.
  • Page 43 2. Remove riser number 3, remove the mezzanine card, and install both into the replacement controller module: a. Remove any SFP or QSFP modules that might be in the PCIe cards. b. Rotate the riser locking latch on the left side of the riser up and toward air duct. The riser raises up slightly from the controller module.
  • Page 44 1. Locate the DIMMs on your controller module. 2. Note the orientation of the DIMM in the socket so that you can insert the DIMM in the replacement controller module in the proper orientation. 3. Verify that the NVDIMM battery is not plugged into the new controller module. 4.
  • Page 45 b. Locate the corresponding DIMM slot on the replacement controller module. c. Make sure that the DIMM ejector tabs on the DIMM socket are in the open position, and then insert the DIMM squarely into the socket. The DIMMs fit tightly in the socket, but should go in easily. If not, realign the DIMM with the socket and reinsert it.
  • Page 46 Interrupt the boot process and boot to the LOADER prompt by pressing Ctrl-C. If your system stops at the boot menu, select the option to boot to LOADER. Restore and verify the system configuration - AFF A400 After completing the hardware replacement and booting to Maintenance mode, you verify the low-level system configuration of the replacement controller and reconfigure system settings as necessary.
  • Page 47 1. If the replacement node is not at the LOADER prompt, halt the system to the LOADER prompt. 2. On the healthy node, check the system time: show date The date and time are given in GMT. 3. At the LOADER prompt, check the date and time on the replacement node: show date The date and time are given in GMT.
  • Page 48 ▪ A prompt warning that when entering Maintenance mode in an HA configuration you must ensure that the healthy node remains down. You can safely respond to these prompts. Recable the system and reassign disks - AFF A400 Continue the replacement procedure by recabling the storage and confirming disk reassignment.
  • Page 49 This procedure applies only to systems running ONTAP in an HA pair. 1. If the replacement node is in Maintenance mode (showing the prompt, exit Maintenance mode and go *> to the LOADER prompt: halt 2. From the LOADER prompt on the replacement node, boot the node, entering if you are prompted to override the system ID due to a system ID mismatch:boot_ontap...
  • Page 50 If the giveback is vetoed, you can consider overriding the vetoes. Find the High-Availability Configuration Guide for your version of ONTAP 9 b. After the giveback has been completed, confirm that the HA pair is healthy and that takeover is possible: storage failover show The output from the storage failover show...
  • Page 51 11. If you disabled automatic takeover on reboot, enable it from the healthy node: storage failover modify -node replacement-node-name -onreboot true Complete system restoration - AFF A400 Step 1: Install licenses for the replacement node in ONTAP You must install new licenses for the replacement node if the impaired node was using ONTAP features that require a standard (node-locked) license.
  • Page 52 If any LIFs are listed as false, revert them to their home ports: network interface revert 2. Register the system serial number with NetApp Support. ◦ If AutoSupport is enabled, send an AutoSupport message to register the serial number. ◦ If AutoSupport is not enabled, call NetApp Support to register the serial number.
  • Page 53 1. Verify that all nodes are in the enabled state: metrocluster node show cluster_B::> metrocluster node show Configuration Group Cluster Node State Mirroring Mode ----- ------- -------------- -------------- --------- -------------------- cluster_A   controller_A_1 configured enabled heal roots completed   cluster_B  ...

  • Page 54: Replace A Dimm - Aff A400

    Step 5: Return the failed part to NetApp After you replace the part, you can return the failed part to NetApp, as described in the RMA instructions shipped with the kit. Contact technical support at NetApp Support, 888- 463-8277 (North America), 00-800-44-638277 (Europe), or +800-800-80-800 (Asia/Pacific) if you need the RMA number or additional help with the replacement procedure.
  • Page 55 If the impaired node is Then… displaying… The LOADER prompt Go to the next step. Waiting for giveback… Press Ctrl-C, and then respond when prompted. System prompt or password Take over or halt the impaired node: prompt (enter system password) •...
  • Page 56 About this task • If you are using NetApp Storage Encryption, you must have reset the MSID using the instructions in the "Returning SEDs to unprotected mode" section of Administration overview with the CLI.
  • Page 57 controller_A_1::> metrocluster heal -phase aggregates [Job 130] Job succeeded: Heal Aggregates is successful. If the healing is vetoed, you have the option of reissuing the command with the metrocluster heal -override-vetoes parameter. If you use this optional parameter, the system overrides any soft vetoes that prevent the healing operation.
  • Page 58 mcc1A::> metrocluster operation show   Operation: heal-root-aggregates   State: successful  Start Time: 7/29/2016 20:54:41   End Time: 7/29/2016 20:54:42   Errors: - 8. On the impaired controller module, disconnect the power supplies. Step 2: Remove the controller module To access components inside the controller module, you must remove the controller module from the chassis.
  • Page 59 4. Remove the cable management device from the controller module and set it aside. 5. Press down on both of the locking latches, and then rotate both latches downward at the same time. The controller module moves slightly out of the chassis. 6.
  • Page 60 The DIMMs are located in sockets 2, 4, 13, and 15. The NVDIMM is located in slot 11. 1. Open the air duct: a. Press the locking tabs on the sides of the air duct in toward the middle of the controller module. b.
  • Page 61 5. Remove the replacement DIMM from the antistatic shipping bag, hold the DIMM by the corners, and align it to the slot. The notch among the pins on the DIMM should line up with the tab in the socket. 6. Make sure that the DIMM ejector tabs on the connector are in the open position, and then insert the DIMM squarely into the slot.
  • Page 62 the following sections. You will connect the rest of the cables to the controller module later in this procedure. 4. Complete the installation of the controller module: a. Plug the power cord into the power supply, reinstall the power cable locking collar, and then connect the power supply to the power source.
  • Page 63 5. Select an option from the displayed sub-menu and run the test. 6. Proceed based on the result of the preceding step: ◦ If the test failed, correct the failure, and then rerun the test. ◦ If the test reported no failures, select Reboot from the menu to reboot the system. Step 6: Restore the controller module to operation after running diagnostics After completing diagnostics, you must recable the system, give back the controller module, and then reenable automatic giveback.

  • Page 64: Hot-Swap A Fan Module - Aff A400

    6. Reestablish any SnapMirror or SnapVault configurations. Step 8: Return the failed part to NetApp After you replace the part, you can return the failed part to NetApp, as described in the RMA instructions shipped with the kit. Contact technical support at...
  • Page 65 You can use the following animation, illustration, or the written steps to hot-swap a fan module. Replacing a fan 1. If you are not already grounded, properly ground yourself. 2. Remove the bezel (if necessary) with two hands, by grasping the openings on each side of the bezel, and then pulling it toward you until the bezel releases from the ball studs on the chassis frame.

  • Page 66: Replace The Nvdimm Battery - Aff A400

    10. Align the bezel with the ball studs, and then gently push the bezel onto the ball studs. 11. After you replace the part, you can return the failed part to NetApp, as described in the RMA instructions shipped with the kit. Contact technical support at...
  • Page 67 If the impaired node is Then… displaying… The LOADER prompt Go to the next step. Waiting for giveback… Press Ctrl-C, and then respond when prompted. System prompt or password Take over or halt the impaired node: prompt (enter system password) •...
  • Page 68 About this task • If you are using NetApp Storage Encryption, you must have reset the MSID using the instructions in the "Returning SEDs to unprotected mode" section of Administration overview with the CLI.
  • Page 69 controller_A_1::> metrocluster heal -phase aggregates [Job 130] Job succeeded: Heal Aggregates is successful. If the healing is vetoed, you have the option of reissuing the command with the metrocluster heal -override-vetoes parameter. If you use this optional parameter, the system overrides any soft vetoes that prevent the healing operation.
  • Page 70 mcc1A::> metrocluster operation show   Operation: heal-root-aggregates   State: successful  Start Time: 7/29/2016 20:54:41   End Time: 7/29/2016 20:54:42   Errors: - 8. On the impaired controller module, disconnect the power supplies. Step 2: Remove the controller module To access components inside the controller module, you must remove the controller module from the chassis.
  • Page 71 4. Remove the cable management device from the controller module and set it aside. 5. Press down on both of the locking latches, and then rotate both latches downward at the same time. The controller module moves slightly out of the chassis. 6.
  • Page 72 1. Open the air duct: a. Press the locking tabs on the sides of the air duct in toward the middle of the controller module. b. Slide the air duct toward the back of the controller module, and then rotate it upward to its completely open position.
  • Page 73 3. Cable the management and console ports only, so that you can access the system to perform the tasks in the following sections. You will connect the rest of the cables to the controller module later in this procedure. 4. Complete the installation of the controller module: a.
  • Page 74 4. Select Test Memory from the displayed menu to run diagnostics tests. 5. Proceed based on the result of the preceding step: ◦ If the scan show problems, correct the issue, and then rerun the scan. ◦ If the scan reported no failures, select Reboot from the menu to reboot the system. Step 6: Restore the controller module to operation after running diagnostics After completing diagnostics, you must recable the system, give back the controller module, and then reenable automatic giveback.

  • Page 75: Replace An Nvdimm - Aff A400

    6. Reestablish any SnapMirror or SnapVault configurations. Step 8: Return the failed part to NetApp After you replace the part, you can return the failed part to NetApp, as described in the RMA instructions shipped with the kit. Contact technical support at...
  • Page 76 Step 1: Shut down the impaired controller You can shut down or take over the impaired controller using different procedures, depending on the storage system hardware configuration. Option 1: Most configurations To shut down the impaired node, you must determine the status of the node and, if necessary, take over the node so that the healthy node continues to serve data from the impaired node storage.
  • Page 77 About this task • If you are using NetApp Storage Encryption, you must have reset the MSID using the instructions in the "Returning SEDs to unprotected mode" section of Administration overview with the CLI.
  • Page 78 1. Check the MetroCluster status to determine whether the impaired node has automatically switched over to the healthy node: metrocluster show 2. Depending on whether an automatic switchover has occurred, proceed according to the following table: If the impaired node… Then…...
  • Page 79 controller_A_1::> storage aggregate show Aggregate Size Available Used% State #Vols Nodes RAID Status --------- -------- --------- ----- ------- ------ ---------------- ------------ aggr_b2 227.1GB 227.1GB 0% online 0 mcc1-a2 raid_dp, mirrored, normal... 6. Heal the root aggregates by using the command. metrocluster heal -phase root-aggregates mcc1A::>...
  • Page 80 LED turns off. • Although the contents of the NVDIMM is encrypted, it is a best practice to erase the contents of the NVDIMM before replacing it. For more information, see the Statement of Volatility on the NetApp Support...
  • Page 81 Site. You must log into the NetApp Support Site to display the Statement of Volatility for your system. You can use the following animation, illustration, or the written steps to replace the NVDIMM. The animation shows empty slots for sockets without DIMMs. These empty sockets are populated with blanks.
  • Page 82 2. Eject the NVDIMM from its slot by slowly pushing apart the two NVDIMM ejector tabs on either side of the NVDIMM, and then slide the NVDIMM out of the socket and set it aside. Carefully hold the NVDIMM by the edges to avoid pressure on the components on the NVDIMM circuit board.
  • Page 83 1. If you have not already done so, close the air duct. 2. Align the end of the controller module with the opening in the chassis, and then gently push the controller module halfway into the system. Do not completely insert the controller module in the chassis until instructed to do so. 3.
  • Page 84 After you issue the command, you should wait until the system stops at the LOADER prompt. 2. At the LOADER prompt, access the special drivers specifically designed for system-level diagnostics to function properly: boot_diags 3. Select Scan System from the displayed menu to enable running the diagnostics tests. 4.
  • Page 85 cluster_B::> metrocluster node show Configuration Group Cluster Node State Mirroring Mode ----- ------- -------------- -------------- --------- -------------------- cluster_A   controller_A_1 configured enabled heal roots completed   cluster_B   controller_B_1 configured enabled waiting for switchback recovery 2 entries were displayed. 2. Verify that resynchronization is complete on all SVMs: metrocluster vserver show 3.

  • Page 86: Replace A Pcie Or Mezzanine Card - Aff A400

    Step 8: Return the failed part to NetApp After you replace the part, you can return the failed part to NetApp, as described in the RMA instructions shipped with the kit. Contact technical support at NetApp Support, 888- 463-8277 (North America), 00-800-44-638277 (Europe), or +800-800-80-800 (Asia/Pacific) if you need the RMA number or additional help with the replacement procedure.
  • Page 87 If the impaired node is Then… displaying… The LOADER prompt Go to the next step. Waiting for giveback… Press Ctrl-C, and then respond when prompted. System prompt or password Take over or halt the impaired node: prompt (enter system password) •...
  • Page 88 About this task • If you are using NetApp Storage Encryption, you must have reset the MSID using the instructions in the "Returning SEDs to unprotected mode" section of Administration overview with the CLI.
  • Page 89 controller_A_1::> metrocluster heal -phase aggregates [Job 130] Job succeeded: Heal Aggregates is successful. If the healing is vetoed, you have the option of reissuing the command with the metrocluster heal -override-vetoes parameter. If you use this optional parameter, the system overrides any soft vetoes that prevent the healing operation.
  • Page 90 mcc1A::> metrocluster operation show   Operation: heal-root-aggregates   State: successful  Start Time: 7/29/2016 20:54:41   End Time: 7/29/2016 20:54:42   Errors: - 8. On the impaired controller module, disconnect the power supplies. Step 2: Remove the controller module To access components inside the controller module, you must remove the controller module from the chassis.
  • Page 91 4. Remove the cable management device from the controller module and set it aside. 5. Press down on both of the locking latches, and then rotate both latches downward at the same time. The controller module moves slightly out of the chassis. 6.
  • Page 92 The riser raises up slightly from the controller module. d. Lift the riser up straight up and set it aside on a stable flat surface, 2. Remove the PCIe card from the riser: a. Turn the riser so that you can access the PCIe card. b.
  • Page 93 1. Remove riser number 3 (slots 4 and 5): a. Open the air duct by pressing the locking tabs on the sides of the air duct, slide it toward the back of the controller module, and then rotate it to its completely open position. b.
  • Page 94 c. Rotate the latch down flush with the sheet metal on the riser. Step 5: Install the controller module After you have replaced the component in the controller module, you must re-install the controller module into the chassis, and then boot it to Maintenance mode. You can use the following animation, illustration, or the written steps to install the controller module in the chassis.
  • Page 95 Do not use excessive force when sliding the controller module into the chassis to avoid damaging the connectors. The controller module begins to boot as soon as it is fully seated in the chassis. Be prepared to interrupt the boot process. c.
  • Page 96 cluster_B::> metrocluster node show Configuration Group Cluster Node State Mirroring Mode ----- ------- -------------- -------------- --------- -------------------- cluster_A   controller_A_1 configured enabled heal roots completed   cluster_B   controller_B_1 configured enabled waiting for switchback recovery 2 entries were displayed. 2. Verify that resynchronization is complete on all SVMs: metrocluster vserver show 3.

  • Page 97: Replacing A Power Supply - Aff A400

    Step 8: Return the failed part to NetApp After you replace the part, you can return the failed part to NetApp, as described in the RMA instructions shipped with the kit. Contact technical support at NetApp Support, 888- 463-8277 (North America), 00-800-44-638277 (Europe), or +800-800-80-800 (Asia/Pacific) if you need the RMA number or additional help with the replacement procedure.

  • Page 98: Replace The Real-Time Clock Battery - Aff A400

    Once power is restored to the power supply, the status LED should be green. 8. After you replace the part, you can return the failed part to NetApp, as described in the RMA instructions shipped with the kit. Contact technical support at...
  • Page 99 Option 1: Most configurations To shut down the impaired node, you must determine the status of the node and, if necessary, take over the node so that the healthy node continues to serve data from the impaired node storage. About this task If you have a cluster with more than two nodes, it must be in quorum.
  • Page 100 About this task • If you are using NetApp Storage Encryption, you must have reset the MSID using the instructions in the "Returning SEDs to unprotected mode" section of Administration overview with the CLI.
  • Page 101 If the impaired node… Then… Has automatically switched over Proceed to the next step. Has not automatically switched Perform a planned switchover operation from the healthy node: over metrocluster switchover Has not automatically switched Review the veto messages and, if possible, resolve the issue and try over, you attempted switchover again.
  • Page 102 mcc1A::> metrocluster heal -phase root-aggregates [Job 137] Job succeeded: Heal Root Aggregates is successful If the healing is vetoed, you have the option of reissuing the command with the metrocluster heal -override-vetoes parameter. If you use this optional parameter, the system overrides any soft vetoes that prevent the healing operation.
  • Page 103 1. If you are not already grounded, properly ground yourself. 2. Release the power cable retainers, and then unplug the cables from the power supplies. 3. Loosen the hook and loop strap binding the cables to the cable management device, and then unplug the system cables and SFPs (if needed) from the controller module, keeping track of where the cables were connected.
  • Page 104 1. If you are not already grounded, properly ground yourself. 2. Open the air duct: a. Press the locking tabs on the sides of the air duct in toward the middle of the controller module. b. Slide the air duct toward the back of the controller module, and then rotate it upward to its completely open position.
  • Page 105 5. Close the air duct. Step 4: Reinstall the controller module and setting time/date after RTC battery replacement After you replace a component within the controller module, you must reinstall the controller module in the system chassis, reset the time and date on the controller, and then boot it.
  • Page 106 Do not use excessive force when sliding the controller module into the chassis to avoid damaging the connectors. The controller module begins to boot as soon as it is fully seated in the chassis. Be prepared to interrupt the boot process. b.
  • Page 107 cluster_B::> metrocluster node show Configuration Group Cluster Node State Mirroring Mode ----- ------- -------------- -------------- --------- -------------------- cluster_A   controller_A_1 configured enabled heal roots completed   cluster_B   controller_B_1 configured enabled waiting for switchback recovery 2 entries were displayed. 2. Verify that resynchronization is complete on all SVMs: metrocluster vserver show 3.
  • Page 108 Step 6: Return the failed part to NetApp After you replace the part, you can return the failed part to NetApp, as described in the RMA instructions shipped with the kit. Contact technical support at NetApp Support, 888- 463-8277 (North America), 00-800-44-638277 (Europe), or +800-800-80-800 (Asia/Pacific) if you need the RMA number or additional help with the replacement procedure.
  • Page 109 NetApp. The use or purchase of this product does not convey a license under any patent rights, trademark rights, or any other intellectual property rights of NetApp.
