Ascon tecnologic e31 Series Operating Instructions Manual

e31-
DIGITAL ELECTRONIC
TEMPERATURE CONTROLLER
WITH DEFROSTING FUNCTION
OPERATING INSTRUCTIONS
19/05 - code.: ISTR_M_e31-_E_03_--
ASCON TECNOLOGIC S.r.l.
Viale Indipendenza 56, 27029 - VIGEVANO (PV) ITALY
Tel.: +39 0381 69871 - Fax: +39 0381 698730
http:\\www.ascontecnologic.com
info@ascontecnologic.com
PREFACE
D D This manual contains the information necessary for
the product to be installed correctly and also instruc-
tions for its maintenance and use; we therefore recom-
mend that the utmost attention is paid to the following
instructions and to save it
This document is the exclusive property of Ascon Tecnologic
S.r.l. which forbids any reproduction and divulgation, even
partially, of the document, unless expressly authorized.
Ascon Tecnologic S.r.l. reserves the right to make any formal
or functional changes at any moment and without any notice.
Ascon Tecnologic S.r.l. and its legal representatives do not
assume any responsibility for any damage to people, things
or animals deriving from violation, wrong or improper use or
in any case not in compliance with the instrument features.
Whenever a failure or a malfunction of the device
D D
may cause dangerous situations for persons, thing
or animals, please remember that the plant has to be
equipped with additional electromechanical devices
which will guarantee safety.
Ascon Tecnologic - e31- - OPERATING INSTRUCTIONS - PAG. 1
Index
1. Instrument description ............................................. 1
1.1 General description ......................................................... 1
1.2 Front panel pescription ................................................... 2
2. Programming ............................................................. 2
2.1 Fast Set point programming ............................................ 2
2.2 Standard mode parameters programming ...................... 2
2.3 Parameter protection using the password ....................... 3
2.4 Customized mode parameter programming
(parameters programming level) ..................................... 3
2.5 Reset parameters to default value .................................. 3
2.6 Keyboard lock function .................................................... 3
3. Usage warnings ......................................................... 4
3.1 Admitted use ................................................................... 4
4. Installation warnings ................................................. 4
4.1 Mechanical mounting ...................................................... 4
4.2 Dimensions [mm] ............................................................ 4
4.3 Electrical connections ..................................................... 5
5. Functions ................................................................... 5
5.1 ON/Stand-by function ...................................................... 5
5.2 Normal and economic operation ..................................... 5
5.3 Measure and display configuration ................................. 6
5.4 Digital input configuration ................................................ 6
5.5 Temperature control ........................................................ 6
5.6 Compressor protection function and power-on delay ...... 7
5.7 Defrost control ................................................................. 7
5.8 Alarm functions ............................................................... 8
5.9 Function of keys
6. Accessories ............................................................... 9
6.1 Parameters configuration by A01 .................................... 9
6.2 Parameters configuration by AFC1 ................................. 9
7. Programmable parameters table .............................. 10
8. Problems and maintenance ...................................... 11
8.1 Notifications .................................................................... 11
8.2 Cleaning .......................................................................... 11
8.3 Disposal .......................................................................... 11
9. Warranty and Repairs ............................................... 11
10. Technical data ............................................................ 11
10.1 Electrical characteristics ................................................. 11
10.2 Mechanical characteristics .............................................. 11
10.3 Functional features ......................................................... 12
11. How to order .............................................................. 12
1.

INSTRUMENT DESCRIPTION

1.1

General description

The model e31 is a microprocessor based digital electronic
temperature controller that is typically used in cooling ap-
plications with ON/OFF temperature control and defrost
control with intervals time by stopping compressor
The instrument has 1 relay output and 2 NTC temperature
probes inputs one of which can be configured as digital
input; it can also be equipped with a built-in buzzer for
acoustic report of the alarms.
The operating parameters configuration can be made through
the keypad, through the A01 device connected to the TTL
port (standard) or using the NFC communication (optional).
