Chapter 3 — MA25300A mmWave Module

3-1 Introduction

This chapter provides a description of the MA25300A millimeter-Wave (mmWave or as labeled, mm-W)
Module. The MA25300A Module is used with the VectorStar ME7838 Series Broadband/BB/mmWave VNA
System.
When the ME7838 system is ordered, the typical configuration provides a 3739C Broadband Test Set and two
mmWave modules to be used with the VNA. Each module is characterized for a specific VNA Serial Number
and a specific VNA Test Port. Additional information for heat sinking and user-defined mounting is given in
Chapter 8. Complete installation documentation is in the applicable VectorStar ME7838 Series System
Installation Guide. Refer to

3-2 MA25300A mmWave Module and Bracket

As-Shipped Configuration

Figure 3-1 on page 3-2
torque values in the as-shipped configuration. It is easier to make the cable connections before mounting the
module to the bracket. The shipping container provides the following components for one module:
• MA25300A Module, mounted in bracket assembly
• Bracket Assembly and Knurled Thumbscrews, M3 x 8 mm, four each, holding the module into the
bracket
To avoid connector damage or inaccurate measurements, before making any connections, ensure
Caution the connectors are clean, undamaged, and meet pin depth specification. Observe connector torque
requirements where indicated in this guide.
VectorStar ME7838 Modules RM
Section 1-3 "Related Documentation" on page 1-2
shows the MA25300A module-to-bracket orientation, connection assignments, and
PN: 10410-00311 Rev. H
for the document part number.
3-1
