MU120119A
OC-3/12 STM-1/4 (1310 nm) Module
MU120120A
OC-3 STM-1 (1310 nm) Module
Operation Manual
12th Edition
• For safety and warning information, please read this
manual before attempting to use the equipment.
• Additional
safety
provided within the MD1230B Data Quality Analyzer
Operation Manual or MP1591A Network Performance
Tester Operation Manual. Please also refer to this
document before using the equipment.
• Keep this manual with the equipment.
ANRITSU CORPORATION
Document No.: M-W2121AE-12.0
and warning
information
is

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MU120119A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anritsu MU120119A

Summary of Contents for Anritsu MU120119A

  • Page 1 MU120119A OC-3/12 STM-1/4 (1310 nm) Module MU120120A OC-3 STM-1 (1310 nm) Module Operation Manual 12th Edition • For safety and warning information, please read this manual before attempting to use the equipment. • Additional safety and warning information provided within the MD1230B Data Quality Analyzer Operation Manual or MP1591A Network Performance Tester Operation Manual.
  • Page 2 Ensure that you clearly understand the meanings of the symbols BEFORE using the equipment. Some or all of the following symbols may be used on all Anritsu equipment. In addition, there may be other labels attached to products that are not shown in the diagrams in this manual.
  • Page 3 In addition, this warranty is valid only for the original equipment purchaser. It is not transferable if the equipment is resold. Anritsu Corporation shall assume no liability for injury or financial loss of the customer due to the use of or a failure to be able to use this equipment.
  • Page 4 Notice The following actions are strictly prohibited for all of the software installed in this product or otherwise provided by Anritsu: 1. Copying, except for archival purposes, 2. Transferring to a third party apart from this product, 3.
  • Page 5 CE Conformity Marking Anritsu affixes the CE Conformity marking on the following product(s) in accordance with the Council Directive 93/68/EEC to indicate that they conform to the EMC and LVD directive of the European Union (EU). CE marking 1. Product Model...
  • Page 6 Main frame: MD1230A/B Data Quality Analyzer, MD1231A/A1 IP Network Analyzer, MT7407A Multislot Chassis MP1591A Network Performance Tester PS: About main frame Please contact Anritsu for the latest information on the main frame types that the above modules can be used with.

  • Page 7: About This Manual

    Family Operation Manual MU120106A 10G (1.55) Module Operation Manual indicates this document. Describes basic operations of SDH/SONET modules. MU120119A OC-3/12 STM-1/4 Module (1310 nm) MU120120A OC-3 STM-1 Module (1310 nm) Operation Manual Describes basic operations of SDH/SONET modules. MD1230B Remote Control...
  • Page 8 Decode Module Operation Manual Describes basic operations of Decode modules. Tcl Interface Operation Manual Describes basic operations of Tcl Interface. Expert Analysis Module Operation Manual Describes basic operations of Expert Analysis modules. Application Traffic Monitor Operation Manual Describes how to operate the software for monitoring Ethernet traffic.
  • Page 9 The MP1590 family operation manuals consist of separate documents for the mainframe, module(s), control software, remote control operation, and options, as shown below. MP1590B Network Performance Tester Operation Manual Describes basic operations of the MP1590B. MP1591A Network Performance Tester Operation Manual Describes basic operations of the MP1591A.
  • Page 10 MU120104A/B 2.5G (1.55) Module MU120105A 10G (1.31) Module MU120106A 10G (1.55) Module Operation Manual Describes basic operations of SDH/SONET modules. MU120119A OC-3/12 STM-1/4 Module (1310 nm) MU120120A OC-3 STM-1 Module (1310 nm) Operation Manual MP1590B/MP1591A Network Performance Tester Remote Control Operation Manual Describes remote control via RS-232C, GPIB, and Ethernet Interfaces.
  • Page 11 Full Name Abbreviated Name MD1230B Data Quality Analyzer MD1230B MP1591A Network Performance Tester MP1591A MU120119A OC-3/12 STM-1/4 Module (1310 nm) 156/622M Module MU120120A OC-3 STM-1 Module (1310 nm) 156M Module Note: Note that the MD1230A, MD1231A/A1 and MT7407A are not sup- ported in Ver.

  • Page 12: Table Of Contents

    Table of Contents About This Manual........Section 1 Overview........Product Outline ............. Section 2 Precautions Before Use ... Installation Site Environmental Conditions ....Connection with Device Under Test ......Section 3 Description of Panel ....Description of Panel............Appendix A Specifications ......Index ............
  • Page 14 VIII.

  • Page 15: Overview

    Section 1 Overview This section describes an overview of the 156/622M POS module func- tions. For specifications, refer to the Appendix “Specifications.” Product Outline ............1-2...

  • Page 16: Product Outline

    Each port operates at 156M or 622M individually. (1) Available interfaces The modules and their available interfaces are given below. Modules Available interfaces (wave-length band) MU120119A OC-3/12, 1310 nm, single mode MU120120A OC-3, 1310 nm, single mode (2) Number of ports Each POS module has the number of ports listed below.

  • Page 17: Precautions Before Use

    Section 2 Precautions Before Use This section provides information to be understood before using the 156/622M POS modules. It also covers safety precautions and steps to avoid malfunctioning of the device in use. Read through this section be- fore using the POS modules. Installation Site Environmental Conditions ....

  • Page 18: Installation Site Environmental Conditions

    Section 2 Precautions Before Use 2.1 Installation Site Environmental Conditions The 156/622M POS modules operate normally within a temperature range of 0 to 40°C. Avoid using them under the following conditions to prevent malfunctioning: • Excessive vibration • Excessive moisture or dust •...

  • Page 19: Description Of Panel

    Section 3 Description of Panel This section describes the 156/622M POS module panel controls. Description of Panel........... 3-2...

  • Page 20: Description Of Panel

    Section 3 Description of Panel 3.1 Description of Panel (1) MU120119A 156/622M Module (1310 nm) The figure below shows the front panel of the 156/622M POS Module. Power Meter Port 1 Output Input Port 2 Output Input MU120119A Link Error...
  • Page 21 Description of Panel The error items are listed in the table below. PPP/Cisco Bulk HDLC/MAPOS PPP/ Error items SDH/ Cisco High SDH/SONET SONET HDLC/ Layer MAPOS Bit all MS-REI HP-REI HP IEC Bit info. Error Oversize/Undersize Error FCS Error Oversize & FCS Error Fragments IP Header checksum Error TCP/UDP checksum Error...
  • Page 22 Section 3 Description of Panel 3-4.
  • Page 23 Appendix Appendix A Specifications..........A-1 App.-I...
  • Page 24 Appendix App.-II.

  • Page 25: Appendix A Specifications

    Item Specifications Model name MU120119A Apparatus name OC-3/12 STM-1/4 Module (1310 nm) Composition Module×1 Options MU120119A-01: Optical Power Meter Interface Corresponding Specification OC-3/STM-1 OC-12/STM-4 Connector Number of Ports Bit Rate 155.52 Mbit/s (NRZ) / 622.08 Mbit/s (NRZ) Clock Internal (±50 ppm Variable), Receive, Lock (64 kHz +8 kHz, 1.5 MHz, 2MHz, 1.5 Mbit/s, 2 Mbit/s)
  • Page 26 Appendix A Specifications MU120119A(Cont’d) Item Specifications SONET/SDH Setting Frame SONET/SDH Mapping OC-12c/STM-4c - VC4*4c - PPP OC-12c/STM-4c - VC4*4c - CiscoHDLC OC-12c/STM-4c - VC4*4c - MAPOS Version1 OC-12c/STM-4c - VC4*4c - MAPOS 16 OC-12c/STM-4c - VC4*4c - Bulk OC-3c/STM-1 - VC4 - PPP...
  • Page 27 Specifications MU120119A(Cont’d) Item Specifications Port Setting IPv4 This port IPv4 Address, Netmask, Gateway ICMP Echo(PING) Reply Not send, Reply to this port ping request Scramble: On/Off Descramble: On/Off Minimum Flag Length: 1 byte/2 byte FCS: 32bit Negotiation: On/Off, Restart, Retry, Abort,...
  • Page 28 Appendix A Specifications MU120119A(Cont’d) Item Specifications Frame Setting FCS: CRC32 MPLS label: Up to 10 MPLS labels can be appended. Fixed setting. Protocol Editing: None, IPv4, TCP/IPv4, UDP/IPv4, IGMP/IPv4, ICMP/IPv4, RIP/UDP/IPv4, DHCP/UDP/IPv4, IPv6, IS-IS IPv4/IPv6: IP Destination/Source Address can be set...
  • Page 29 Specifications MU120119A(Cont’d) Item Specifications OH Setting PPP/Cisco HDLC Address: FFh (User defined) Cisco HDLC: 0Fh MAPOS /MAPOS Version 1 Version 1: 03h /MAPOS 16 Control: 03h (User defined) Cisco HDLC: 00h MAPOS Version 1: 03h Address MAPOS16: 00003h When MAPOS16 then Address field is 16 bit and Control...
  • Page 30 Appendix A Specifications MU120119A(Cont’d) Item Specifications IPv6 (RFC2460) Version (4 bit): 6 Traffic class (8 bit): 0-uncharacterized traffic 1-"filler" traffic 2-unattended data transfer 3-reserved 4-attended bulk transfer 5-reserved 6-interactive traffic 7-internet control traffic Flow Label (20 bit): 20 bit user defined (initial all 0)
  • Page 31 Specifications MU120119A(Cont’d) Item Specifications ICMP Type (8 bit): 0 = Reply 3 = Destination Unreachable (RFC792, 950, 1256) 4 = Source Quench 5 = Redirect 8 = Echo 9 = Router Advertisement 10 = Router Selection 11 = Time Exceeded...
  • Page 32 Appendix A Specifications MU120119A(Cont’d) Item Specifications DHCP (RFC2131) Op Code (8 bit): User defined 1 = Boot request 2 = Boot reply Hardware type (8 bit): User defined 1 = 10 MB Ethernet Hardware address length (8 bit): User defined...
  • Page 33 Specifications MU120119A(Cont’d) Item Specifications Measurement Function SONET/SDH Test Performance G. 826 K1, K2 Monitor Conform to G.783 or G.841 Pointer Monitor AU Pointer Graph: Pointer value, Pointer Inc/Dec Resolution: 1 s, 1 min, 15 min, 60 min OH Monitor SOH, POH, J0, J1...
  • Page 34 Appendix A Specifications MU120119A(Cont’d) Item Specifications TCP/UDP Received TCP Packet Count, Received TCP Packet Rate, Received UDP Packet Count, Received UDP Packet Rate, TCP Checksum Error , UDP Checksum Error Data Capture Trigger, Capture Filter, User Defined Count/Rate, User Defined 2 Count/Rate, QoS 0 to 7 Frame Count/Rate.
  • Page 35 Specifications MU120119A(Cont’d) Item Specifications Capture Capture Buffer 256 Mbytes/Port Filter condition settings; Capture Filter/Trigger Destination IP Address: don't care, Match, Not match Source IP Address: don't care, Match, Not match Pattern1: don't care, Match, Not match Pattern2: don't care, Match, Not match Error: don't care, Match, Not match Trigger condition settings;...
  • Page 36 Appendix A Specifications MU120119A(Cont’d) Item Specifications Decode Protocol Ethernet (Type II, IEEE802.3, Mac Control), VLAN, MPLS, LLC, LACP, BPDU (STP, RST, MST), ARP, Ethernet OAM, IP, IPv6 (include Extended, Header), IPX, OSINL, IS-IS, IGMP (include IGAP), ICMP, ICMPv6 (include NDP, MLD, MLDA), TCP, UDP, OSPF, OSPFv3,...
  • Page 37 Traffic Map can measure up to 64 streams in real-time. Target: IPv4 Address Service Disruption Time Time of Frame Disruption. Power Meter Supported by MU120119A-01 Optical Power Meter Maximum Input Range: +10 dBm Range: −40 to +5 dBm Accuracy: ±0.5 dB Automatic Test RFC2544 Automatic Test Following 6 types of tests can be supported.
  • Page 38 Appendix A Specifications MU120119A(Cont’d) Item Specifications Latency Duration: 2 to 999 s Number of Trials: 1 to 50 Rate (%): Initial Rate, Step Rate, Step Count, 0.01% step, Result of Throughput Rate Burst Size: 1 to 1000 Result: Latency (0.01 us resolution) Graph: Latency vs.
  • Page 39 Specifications MU120120A Item Specifications Model name MU120120A Apparatus name OC-3/STM-1 Module (1310 nm) Composition Module×1 Options MU120120A-01: Optical Power Meter Interface Corresponding Specification OC-3/STM-1 Connector Number of Ports Bit Rate 155.52 Mbit/s (NRZ) Clock Internal (±50 ppm Variable), Receive, Lock (64 kHz+8 kHz, 1.5 MHz, 2MHz, 1.5 Mbit/s, 2 Mbit/s) Wavelength 1,274 to 1,356 nm...
  • Page 40 Appendix A Specifications MU120120A (Cont’d) Item Specifications SONET/SDH Setting Frame SONET/SDH Mapping OC-12c/STM-4c - VC4*4c - PPP OC-12c/STM-4c - VC4*4c - CiscoHDLC OC-12c/STM-4c - VC4*4c - MAPOS Version1 OC-12c/STM-4c - VC4*4c - MAPOS 16 OC-12c/STM-4c - VC4*4c - Bulk Unframed OH Preset SOH: All byte except B1, B2, H1, H2, H3, K1, K2 POH: All byte except B3...
  • Page 41 Specifications MU120120A (Cont’d) Item Specifications Port Setting IPv4 This port IPv4 Address, Netmask, Gateway ICMP Echo(PING) Reply Not send, Reply to this port ping request Scramble: On/Off Descramble: On/Off Minimum Flag Length: 1 byte/2 byte FCS: 32 bit Negotiation: On/Off, Restart, Retry, Abort, Max-Receive-Unit(default1500), Magic-number (random) , IPCP(Send this port IP address), Default,...
  • Page 42 Appendix A Specifications MU120120A (Cont’d) Item Specifications Frame Setting FCS: CRC32 MPLS label: Up to 10 MPLS labels can be appended. Fixed setting. Protocol Editing: None, IPv4, TCP/IPv4, UDP/IPv4, IGMP/IPv4, ICMP/IPv4, RIP/UDP/IPv4, DHCP/UDP/IPv4, IPv6, IS-IS IPv4/IPv6: IP Destination/Source Address can be set Fixed, Increment, Decrement,...
  • Page 43 Specifications MU120120A (Cont’d) Item Specifications OH Setting PPP/Cisco HDLC Address: FFh (User defined) Cisco HDLC: 0Fh MAPOS /MAPOS Version 1 Version 1: 03h /MAPOS 16 Control: 03h (User defined) Cisco HDLC: 00h MAPOS Version 1: 03h Address MAPOS16: 00003h When MAPOS16 then Address field is 16 bit and Control field is 0 bit Protocol: 16 bit User defined (default 0021) FCS: Auto...
  • Page 44 Appendix A Specifications MU120120A (Cont’d) Item Specifications IPv6 (RFC2460) Version (4 bit): 6 Traffic class (8 bit): 0-uncharacterized traffic 1-"filler" traffic 2-unattended data transfer 3-reserved 4-attended bulk transfer 5-reserved 6-interactive traffic 7-internet control traffic Flow Label (20 bit): 20 bit user defined (initial all 0) Payload Length (16 bit): Auto Next Header (8 bit): 0 to 255 (DEC) user defined (initial Hop Limit (8 bit): 0 to 255 user defined (initial 0)
  • Page 45 Specifications MU120120A (Cont’d) Item Specifications ICMP Type (8 bit): 0 = Reply 3 = Destination Unreachable (RFC792, 950, 1256) 4 = Source Quench 5 = Redirect 8 = Echo 9 = Router Advertisement 10 = Router Selection 11 = Time Exceeded 12 = Parameter Program 3 = Time Stamp 14 = Time Stamp Reply...
  • Page 46 Appendix A Specifications MU120120A (Cont’d) Item Specifications DHCP (RFC2131) Op Code (8 bit): User defined 1 = Boot request 2 = Boot reply Hardware Type (8 bit): User defined 1 = 10 MB Ethernet Hardware Address Length (8 bit): User defined 6 = for MAC address Hops (8 bit): User defined (0 to 255) Transaction...
  • Page 47 Specifications MU120120A (Cont’d) Item Specifications Measurement Function SONET/SDH Test Performance G. 826 K1, K2 Monitor Conform to G.783 or G.841 Pointer Monitor AU Pointer Graph: Pointer value, Pointer Inc/Dec Resolution: 1 s, 1 min, 15 min, 60 min OH Monitor SOH, POH, J0, J1 Display: CRC, TIM S1, C2: Received octet value are decoded for display...
  • Page 48 Appendix A Specifications MU120120A (Cont’d) Item Specifications TCP/UDP Received TCP Packet Count, Received TCP Packet Rate, Received UDP Packet Count, Received UDP Packet Rate, TCP Checksum Error , UDP Checksum Error Data Capture Trigger, Capture Filter, User Defined Count/Rate, User Defined 2 Count/Rate, QoS 0 to 7 Frame Count/Rate.
  • Page 49 Specifications MU120120A (Cont’d) Item Specifications Capture Capture Buffer 256 Mbytes/Port Capture Filter/Trigger Filter condition settings; Destination IP Address: don't care, Match, Not match Source IP Address: don't care, Match, Not match Pattern1: don't care, Match, Not match Pattern2: don't care, Match, Not match Error: don't care, Match, Not match Trigger condition settings;...
  • Page 50 Appendix A Specifications MU120120A (Cont’d) Item Specifications Decode Protocol Ethernet (Type II, IEEE802.3, Mac Control), VLAN, MPLS, LLC, LACP, BPDU (STP, RST, MST), ARP, Ethernet OAM , IP, IPv6 (include Extended, Header), IPX, OSINL, IS-IS, IGMP (include IGAP), ICMP, ICMPv6 (include NDP, MLD, MLDA), TCP, UDP, OSPF, OSPFv3, DVMRP, LDP (CR-LDP), BGP4, RIP, DHCP, RSVP (RSVP-TE), BGP4+, PIM-SMv2, PPP (include LCP, IPCP,...
  • Page 51 Specifications MU120120A (Cont’d) Item Specifications Frame Arrival Time Variation(Packet Jitter) Resolution 32 counters indicate the results. Resolution: 1 us, 10 us, 100 us, 1 ms, 10 ms, 100 ms, 1 s. Offset Depend on resolution, Max. 3 min. Graph Frame Count vs. Time Interval Auto scale: On/Off Traffic Monitor Traffic Monitor can measure up to 64 streams in real-time.
  • Page 52 Appendix A Specifications MU120120A (Cont’d) Item Specifications Latency Duration: 2 to 999 s Number of Trials: 1 to 50 Rate (%): Initial Rate, Step Rate, Step Count, 0.01% step, Result of Throughput Rate Burst Size: 1 to 1000 Result: Latency (0.01 us resolution) Graph: Latency vs.
  • Page 53 Index Cisco HDLC MAPOS 3-2, 3-3 1-1, 1-2, 2-1, 2-2, 3-1, 3-2, 3-3 Index-1...

  • Page 54: Index

    Index Index-2.
