Summary of Contents for CAVIDYNE Caviblaster 1222-E
- Page 1 Model 1222-E Operation & Maintenance Manual www.cavidyne.com...
- Page 2 6. Connect the 1″ (25 mm) red rubber bypass hose to the cam-lock plug on the pressure- regulating unloader (Figure 5). The bypass hose has a cam-lock socket on one end. Direct the bypass hose away from the working area and secure the hose. Page - 2 For more information please email sales@cavidyne.com or call 1-(352)275-5319...
- Page 3 5. Connect the Zero Thrust Gun to the high pressure hose (Figure 7) and submerge the Zero Thrust Gun in water. Figure 7 6. Restart the water supply. Page - 3 For more information please email sales@cavidyne.com or call 1-(352)275-5319...
- Page 4 (up to 2,200-psi) water stream, which can cause injury when the Zero Thrust Gun is out of the water. ALWAYS keep the Zero Thrust Gun submerged when the pressure pump is engaged. Page - 4 For more information please email sales@cavidyne.com or call 1-(352)275-5319...
- Page 5 If the diver is not wearing a helmet, hearing protection is recommended. Cavidyne recommends “Doc’s Proplugs” vented earplugs for diver hearing protection. 2. Activate the cleaning cavitation stream by squeezing the trigger to the open or “ON” position (Figure 9).
- Page 6 5. Change the oil in the pressure pump after the first 50 hours and every 500 hours thereafter. 6. Change the spring for the Zero Thrust Gun trigger every 12 months or less if required. Page - 6 For more information please email sales@cavidyne.com or call 1-(352)275-5319...
- Page 7 13. Remove the Zero Thrust Gun from the water. 14. Disconnect the power cable from the power source. 15. Flush the system and rinse the outside of the power unit with fresh water. Page - 7 For more information please email sales@cavidyne.com or call 1-(352)275-5319...
- Page 8 Instructions and to the motor and pressure pump manufacturers’ operation manuals for instructions or call CaviDyne, LLC at (352) 275-5319 with any questions. CAUTION: DO NOT USE THIS EQUIPMENT TO CLEAN SENSITIVE SURFACES LED-Lights, Underwater Lights, Elecronic Equipment, Etc. Page - 8 For more information please email sales@cavidyne.com or call 1-(352)275-5319...
- Page 9 Page - 9 For more information please email sales@cavidyne.com or call 1-(352)275-5319...
