- Page 1 ASSEMBLY INSTRUCTION ITEM# : GBO21-305-2 SKU# : 810493159 EASTLAKE AW WICKER THREE SEAT SOFA Need help? We are here for you! 1-888-733-8169 Toll Free Or email us at customerservice_01@yeah.net, customerservice_02@yeah.net customerservice_03@yeah.net...
- Page 2 GENERAL BEST PRACTISE FOR ASSEMBLY: Read all instructions before starting Clear a flat covered space to being Always best to do it with a friend Note that hardware required is provided for every step Pay attention to orientation Letter of the part corresponds to a sticker on the products Number of the hardware corresponds to its letter in the package Helpful hints provided along the way WARNINGS:...
- Page 3 PARTS LIST: PARTS LIST Part No. Part Image Part No. Part Image Screw(φ6x35mm) Right Arm Left Arm Washer Sofa Back Seat Cushion Seat Panel Back Cushion Tools PRODUCT FRAME MAP...
- Page 4 STEP 1 STEP 1 PART REQUIRED: 2,3 Keep the screw loose. STEP 2 STEP 2 PART REQUIRED: 1, 2 & 3 Keep the screw loose.
- Page 5 STEP 3 STEP 3 PART REQUIRED: 1,2,3 & 4 Keep the screw loose. STEP 4 STEP 4 PART REQUIRED: 7,8 Tighten all the screws. Finished! Warranty One-year limited warrantly. Proof of purchase (dated register receipt) is required for warranty claims. It remains the customer's responsibility for freight and packing charges to and from the service center.
