- Page 1 ASSEMBLY INSTRUCTIONS ITEM# : GB21-805 SKU# : 810500148 THORNWOOD AW WICKER LOUNGE WITH CUSHION Need help? We are here for you! 1-888-733-8169 Toll Free Or email us at customerservice _01@yeah.net,customerservice _02@yeah.net customerservice _03@yeah.net...
- Page 2 GENERAL BEST PRACTICE FOR ASSEMBLY: Read all instructions before starting Clear a flat covered space to begin assembly Always best to do it with a friend Note that hardware required is provided for every step Pay attention to orientation Helpful hints provided along the way Retain these assembly instructions for future reference.
- Page 3 PARTS LIST: PARTS LIST Part Image Part Image Part No. Part No. Bolt(M6x18mm) Lounge Seat Panel Lounge Back Bolt(M6x45mm) Position Bracket Bolt(M8x28mm) Left Arm Bolt(M6x14mm) Right Arm Bolt(M8x19mm) Lounge Leg Washer Cushion Tools...
- Page 4 STEP 1 PART REQUIRED: 1 & 6 Keep the bolts loose. STEP 2 PART REQUIRED: 1, 4 & 5 Keep the bolts loose.
- Page 5 STEP 3 PART REQUIRED: 2 & 3 Keep the bolts loose. STEP 4 PART REQUIRED: 1, 2, 4 & 5 Keep the bolts loose.
- Page 6 STEP 5 PART REQUIRED: 7 Tighten all bolts. Finished! Warranty One-year limited warrantly. Proof of purchase (dated register receipt) is required for warranty claims. It remains the customer's responsibility for freight and packing charges to and from the service center.
