- Page 1 ASSEMBLY INSTRUCTIONS ITEM# : GBO22-602-2 SKU# : 810544470 ASHEVILLE ALL WEATHER WICKER ARMLESS SOFA Need help? We are here for you! 1-888-733-8169 Toll Free Or email us at customerservice_01@yeah.net, customerservice_02@yeah.net customerservice_03@yeah.net...
- Page 2 GENERAL BEST PRACTICE FOR ASSEMBLY: Read all instructions before starting Clear a flat covered space to begin assembly Always best to do it with a friend Note that hardware required is provided for every step Pay attention to orientation Letter of the part corresponds to a sticker on the product Number of the hardware corresponds to its letter in the package Helpful hints provided along the way Retain these assembly instructions for future reference.
- Page 3 PARTS LIST FOR CORNER SOFA: PARTS LIST Part No. Part Image Part No. Part Image Long Bolt Sofa Back with Solt (M6x44mm) Sofa Back with Washer Screw hole Bolt (M6x38mm) Sofa Seat Panel Back Foot L eft Back Cushion Front Foot Ri ght Back Cushion Short Bolt Seat Cushion...
- Page 4 PRODUCT FRAME MAP STEP 1 STEP 1 PART REQUIRED: 3, 6 & 7 Keep the bolts loose.
- Page 5 STEP 2 STEP 2 PART REQUIRED: 1, 3 Keep the bolts loose. STEP 3 STEP 3 PART REQUIRED: 2...
- Page 6 STEP 4 STEP 2 STEP 2 PART REQUIRED: 1, 2, 3 Keep the bolts loose. STEP 5 STEP 3 PART REQUIRED: 13, 14 & 15 Finished!
- Page 7 REMINDER REQUIRED: Sectional Set CTN#1 - Right Arm Sofa and Left Arm Sofa and CTN# 2 - Corner Sofa Two other connection locks is included in the hardware pack for sectional sofa set CTN#1 - Right and Left Arm Sofa. PLEASE FIX SOFA SEAT TOGETHER WITH PROVIDED Warranty One-year limited warrantly.
