Service and Repair Manual
S
-80
®
S
-85
®
S
-80X
®
Serial Number Range
from S8015-12264
to S8016H-13642
from S8515-12264
to S8516H-13642
from S80X15-12264
to S80X16H-13642
includes S8516H-13685
and S8516H-13711
from S8015D-101
to S8016D-339
from S80X15D-101
to S80X16D-339
from S80D-340
from S85D-340
from S80XD-340
This manual includes:
Repair procedures
Fault Codes
Electrical and
Hydraulic Schematics
For detailed maintenance
procedures, refer to the
appropriate Maintenance
Manual for your machine.
Part No. 1269074GT
Rev A4
March 2018
