MR46E Installation Guide
The Cisco Meraki MR46E are dual-band enterprise class 802.11ax cloud-managed access points. Designed for highest
capacity and highest density, the MR46E meets the needs of the most demanding environments. The access point also
includes a third radio dedicated to optimizing the RF environment and securing the airwaves.
About this Guide
This guide provides instruction on how to install and configure your MR46E access points. This guide also provides
mounting instructions and limited troubleshooting procedures. For more wireless installation guides, refer to the
installation guides section
Product Overview
Physical Specifications
Interfaces
• 1x 100/1000/2.5G BASE-T Ethernet (RJ45)
• 1x DC power connector (5.5 mm x 2.5 mm, center positive)
Power
• Power over Ethernet: 42.5 - 57 V (802.3at compatible)
• Alternative: 12 V DC input
• Power consumption: 30W max (802.3at)
• Power over Ethernet injector and DC adapter sold separately
Note: Actual power consumption may vary depending on the AP
usage.
on our documentation website.
MR46E
wireless
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cisco MERAKI MR46E
Summary of Contents for Cisco MERAKI MR46E
- Page 1 The Cisco Meraki MR46E are dual-band enterprise class 802.11ax cloud-managed access points. Designed for highest capacity and highest density, the MR46E meets the needs of the most demanding environments. The access point also includes a third radio dedicated to optimizing the RF environment and securing the airwaves.
- Page 2 • Two security screw options (included) (13.5 mm long and 2.5 mm diameter and 5 mm head) • Kensington lock hard point • Concealed mount plate with anti-tamper cable bay Product View and Physical Features Your MR46E has the following features: A - LED indicator...
- Page 3 B - Security screw hole C - Kensington lock hard point D - Desk mount feet...
- Page 4 2. Kensington lock – The access point contains a hard point that allows it to be secured to any nearby permanent structure using a standard Kensington lock. External Antenna Ports The MR46E has 6 external antenna ports Ethernet Ports The MR46E features a Gigabit Ethernet RJ45 port that accepts 802.3at power (labeled “Eth0, PoE”). This port should be...
- Page 5 MR Access Points for more details. The MR46E access point may be operated in “Run Dark” mode for additional security and to reduce the visibility of the access point. In this mode, the LED will not be illuminated. This mode may be enabled through Meraki Dashboard.
- Page 6 MR46E Cloud-Managed Access Point Mount cradle including built-in level tool Drop ceiling mount kit...
- Page 7 Wall screws, wall screw anchors, and security screws Safety and Warnings These operations are to be taken with respect to all local laws. Please take the following into consideration for safe operation: • Power off the unit before you begin. Read the installation instructions before connecting the system to the power source.
-
Page 8: Pre-Install Preparation
Pre-install Preparation You should complete the following steps before going on-site to perform an installation. Configure your Dashboard Network The following is a brief overview only of the steps required to add an access point to your network. For detailed instructions about creating, configuring and managing Meraki wireless networks, refer to the online documentation (documentation.meraki.com). - Page 9 Dynamic Assignment • When using DHCP, the DHCP server should be configured to assign a static IP address for each MAC address belonging to a Meraki AP. Other features of the wireless network, such as 802.1X authentication, may rely on the property that the APs have static IP addresses.
-
Page 10: Installation Instructions
Collect Additional Hardware for Installation You will need the following hardware to perform an installation: 802.3at PoE Power Source (either PoE switch or Meraki 802.3at PoE Injector) or an AC adaptor and network cables with RJ45 connectors long enough for your particular mounting location Installation Instructions Warning: Due to the heat dissipation in the back of APs during normal operation, please do not stack powered on APs on top of each other during pre-installation to avoid heat damage. - Page 11 below a drop ceiling, on various electrical junction boxes. The mount cradle contains a variety of hole patterns that are customized for each installation scenario. The mounting template (included inbox with mount cradle) should be used to drill holes for wall mounts and also to identify the correct hole patterns in the mount cradle that should be used for each type of mount.
- Page 12 2 rubber spacers 1. Attach the T-rail clips to the T-rail by rotating them and snapping them into place as shown. The black foam pads should be compressed slightly after installation. 2. Using the dashed lines on the mount cradle template as a guide, set the proper spacing of the T-rail clips on the T- rail.
- Page 13 Mount the AP Attach the MR46E AP to the Mount Cradle (This section applies to wall and/or solid ceiling, drop ceiling or electrical junction box mount where you have already...
- Page 14 To attach the MR46E AP to the mount cradle properly, line up the top edge of the AP with the top tab of the mount cradle. Since the cradle is already mounted to the wall, guide the MR46E AP towards the top tab and insert the top tab into the MR46E AP’s slot.
-
Page 15: Verify Device Functionality And Test Network Coverage
To release the AP from the mount cradle, first remove the security screw that secures the MR46E AP to the cradle’s bottom tab. While holding the MR46E AP with one hand, press the cradle’s bottom tab upwards, releasing the MR46E AP from the bottom of the cradle. -
Page 16: Basic Troubleshooting
2. Verify access point connectivity a. Use any 802.11 client device to connect to the AP and verify proper connectivity using the client’s web browser. 3. Check network coverage 4. Confirm that you have good signal strength throughout your coverage area. You can use the signal strength meter on a laptop, smart phone, or other wireless device. -
Page 17: Warranty
If you are still experiencing hardware issues, please contact Cisco Meraki support by logging in to dashboard and using the Help option near the top of the page, then opening and email case or calling using the contact information on that page. - Page 18 Meraki MR46E devices have been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
