5.7 Air Exchange Setting*

Turn n air exchange function: -o
Under on-state of the unit, press
blinks). AIR 1 displayed at the ambient temperature-displayed location (888) is defaulted
(the last type of AIR will be displayed after adjustment). Press
e xchange type. Press
turning on
a e
There are 10 types of ir xchange, but only 1-2 types are for wireless remote control. Refer to the following
details:
1 —— The unit continuously runs for 60min, and fresh air valve opens for 6 min.
2 —— The unit continuously runs for 60min, and fresh air valve opens for 12 min.
3 —— The unit continuously runs for 60min, and fresh air valve opens for 18 min.
4 —— The unit continuously runs for 60min, and fresh air valve opens for 24 min.
5 —— The unit continuously runs for 60min, and fresh air valve opens for 30 min.
6 —— The unit continuously runs for 60min, and fresh air valve opens for 36 min.
7 —— The unit continuously runs for 60min, and fresh air valve opens for 42 min.
8 —— The unit continuously runs for 60min, and fresh air valve opens for 48 min.
9 —— The unit continuously runs for 60min, and fresh air valve opens for 54 min.
10 —— The unit continuously runs for 60min, and fresh air valve always opens.
Turn off air exchange function: -
During air exchange function, press
In this case, air mark is blinking, and then press
this function. Air mark will subsequently disappear.
Air exchange setting is shown as Fig.5.7:
Turn on the unit, without
tur ning on air exchange
function
Press "Enter/Cancel" button
to turn off air exchange function
Note:In air exchange mode, press
operation, the system will quit from air exchange setting ,and current setting data won't be memoried.
14
Function button into this function setting (Air mark
Enter/Cancel button to turn on/off air exchange function. After
this function, the air mark shows.
Press "Function" button
into air exchange function
Press "Function" button
into air exchange function
Fig.5.7 Air exchange device
button or there is no any operation within 5s after the last button
"Function"
Function button into air exchange function.
Enter/Cancel button to turn off
Press " " or "
button to adjust the type of air
exchange
Press "Enter/Cancel" button
to turn on air exchange
function
or button to adjust air
"
