9000BTU Portable Air

Conditioner

Model Number: RHPAC4002

220-240V AC 50Hz

For Customer Services & Spare Parts please call 0345 209 7461

Or visit us at

https://mda.russellhobbs.com

PLEASE RETAIN

FOR FUTURE REFERENCE

Table of Contents

Need help?

Do you have a question about the RHPAC4002 and is the answer not in the manual?

Questions and answers

Summary of Contents for Russell Hobbs RHPAC4002

Page 1 9000BTU Portable Air Conditioner Model Number: RHPAC4002 220-240V AC 50Hz For Customer Services & Spare Parts please call 0345 209 7461 Or visit us at https://mda.russellhobbs.com PLEASE RETAIN FOR FUTURE REFERENCE...
Page 2: Table Of Contents
Control Panel Diagram Installing your Air Conditioner 9 – 11 Display Screen Diagram Using your Air Conditioner 13 – 21 Draining your Air Conditioner 22 – 24 Cleaning your Air Conditioner Start/End of Season Operations Troubleshooting Spare Parts Specification Notes RHPAC4002 v2.4...
Page 3: Safety Instructions And Electrical Safety
Children should not play with the appliance. RHPAC4002 v2.4...
Page 4 Be aware that the refrigerants may not contain an odour. • Compliance with national gas regulations shall be observed. • The appliance shall be stored so as to prevent mechanical • damage from occurring. RHPAC4002 v2.4...
Page 5 An area where oil is likely to splash. An area exposed to direct sunlight. An area where water is likely to splash. Near a bath, shower or a swimming pool. In a greenhouse. An area where flammable gasses or liquids are present. RHPAC4002 v2.4...
Page 6: Electrical Safety
This should be carried out by a qualified electrician. The plug removed must be disposed of safely, as insertion into a 13 Amp socket is likely to cause an electrical hazard. RHPAC4002 v2.4...
Page 7: Feature Diagram
7. Condensation Drain 3. Display Screen (Dehumidification) 4. Handle (both sides) 8. Air Exhaust Hose 5. Castors 9. Condensation Drain (Heating) 10. Power Cable For Customer Services & Spare Parts please call 0345 209 7461 Or visit us at https://mda.russellhobbs.com RHPAC4002 v2.4...
Page 8: Control Panel Diagram
CONTROL PANEL DIAGRAM 1. ON/OFF button 2. Mode button 3. Fan button 4. Increase button 5. Decrease button RHPAC4002 v2.4...
Page 9: Installing Your Air Conditioner
2. Extend the other side of the hose and screw it into the hose outlet (Fig. 3) 3. Install the hose inlet into the unit (Fig. 4) 4. Affix the hose outlet into the window seal kit and seal RHPAC4002 v2.4...
Page 10 The hose can be extended but it is best to keep it to the • minimum length required. Also ensure that the hose does not have any sharp bends or sags. RHPAC4002 v2.4...
Page 11 INSTALLING YOUR WINDOW KIT Your Russell Hobbs Air Conditioner has been supplied with a Window Sealing Kit. The kit is suitable for use on UPVC windows that open internally or externally either 3 sides, or 4 sides. It is not suitable for middle opening windows such as skylights, or wooden frames.
Page 12: Display Screen Diagram
DISPLAY SCREEN DIAGRAM 1. Cool symbol 2. Heat symbol* 3. Fan speed indicator 4. Timer symbol 5. Temperature symbol 6. Temperature indicator ‘*’ means that only heat pump models have this function. RHPAC4002 v2.4...
Page 13: Using Your Air Conditioner
Medium Speed: Reduces noise levels but still maintains a good level of comfort Low Speed: For silent operation Auto Speed: The appliance will automatically select the most suitable fan speed in relation to the temperature which it is set at RHPAC4002 v2.4...
Page 14 Select the required fan speed by pressing the FAN button. There are 3 fan speeds to choose from: High/Medium/Low High Speed: For maximum fan power Medium Speed: Reduces noise levels but still maintains a good level of comfort Low Speed: For silent operation RHPAC4002 v2.4 Page 13...
Page 15 (approx. 20 seconds). Once the appliance has beeped you will be able to change the unit of temperature. For example: Before change and when in cool mode the screen will display like this. After the change the screen will then display like this. RHPAC4002 v2.4...
Page 16 (without obstacles between the remote control and the receiver). The remote control must be handled with extreme care to ensure • continuous usage. Do not drop or expose the remote to direct sunlight or sources of heat. RHPAC4002 v2.4...
Page 17 The cells should be disposed of correctly, including keeping them away from children, even used cells may cause injury. RHPAC4002 v2.4...
Page 18 When in COOL mode, the selected temperature will increase by 1°C (1°F) per hour over a 2-hour period. This new temperature will then be maintained for the next 6 hours. After 6 hours the appliance will turn itself off. RHPAC4002 v2.4...
Page 19 5 seconds and then the timer will then be active. Only the TIMER symbol should be displayed on the screen (Fig. - Press either the TIMER or the ON/OFF button and the timer will be cancelled. The TIMER symbol will then disappear from the screen. RHPAC4002 v2.4...
Page 20 • Never rest objects of any kind on the appliance. • Do not obstruct the air intake and outlet (Fig 23). Ensure the grills are left free. • Make sure there are no heat sources within the room. RHPAC4002 v2.4...
Page 21 PROBE FAILURE If this is displayed please contact our Customer Service team by calling 0345 209 7461. FULL TANK Empty the internal safety tank, following the instructions in the “End of Season Operations” section of this Instruction Manual RHPAC4002 v2.4...
Page 22: Draining Your Air Conditioner
6. Plug the unit back into the power source and turn it back on. Continuous Draining (Fig. 25) While using the unit in the dehumidifier mode, it is recommended to use this method of draining. 1. Unplug the unit from the power source. RHPAC4002 v2.4...
Page 23 5. Plug the unit back into the power source and turn it back on. NOTE – Please ensure that the height of and the section of the drain hose should not be higher than the drain outlet , or the water tank may not be drained (Fig. 26 and 27). RHPAC4002 v2.4...
Page 24 5. Plug the unit back into the power source and turn it back on. NOTE – Please ensure that the height of and the section of the drain hose should not be higher than the drain outlet , or the water tank may not be drained. RHPAC4002 v2.4...
Page 25: Cleaning Your Air Conditioner
If it is very dirty, immerse the filter in warm water and rinse it several times, the water should never be hotter than 40°C (104°F). After washing, leave the filter out to dry and then re- attach the intake grill to the appliance. RHPAC4002 v2.4...
Page 26: Start/End Of Season Operations
Clean the filter and dry thoroughly before putting it back into the appliance. Limit conditions Cooling Mode Temperature of room: 18-35°C (64-95°F) Humidity of room: 30%-90%RH. Heating Mode Temperature of room: 10-25°C (50-77°F). Humidity of room: 30%-90%RH. RHPAC4002 v2.4...
Page 27: Troubleshooting
The following message -The appliance has a self- -See the SELF-DIAGNOSIS appears on the display: diagnosis system to identify section of this booklet LT/PF/FT a number of malfunctions RHPAC4002 v2.4...
Page 28: Spare Parts
To check the availability of the following spare parts, simply contact our friendly Customer Services team using the details provided at the bottom of this page. Remote Control Exhaust Hose For Customer Services & Spare Parts please call 0345 209 7461 Or visit us at https://mda.russellhobbs.com RHPAC4002 v2.4...
Page 29: Specification
SPECIFICATION Model RHPAC4002 Voltage 220 – 240V 50Hz Power Input 1000W Maximum Cooling 9000 BTU Capacity Suitable Room Size 10-16 (m2) Refrigerant R290/0.205kg Overall Size (W x H x D) 42 x 70 x 31 (cm) Weight 29 KG Moisture Removal 1.1 L/hr...
Page 30: Notes
NOTES RHPAC4002 v2.4...
Page 31 NOTES RHPAC4002 v2.4...
Page 32 Russell Hobbs is a registered trademark used under license from Spectrum Brands (UK) Ltd. Made under license by G2S Limited, Wigan, WN2 4AY/G2S (NI) Ltd, Belfast, BT5 5AD Russell Hobbs Support: call 0345 209 7461 or visit https://mda.russellhobbs.com The ‘wheelie bin’ symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
