Summary of Contents for Russell Hobbs RHPAC3001B
- Page 1 Portable 3in1 Air Conditioner, Dehumidifier & Air Cooler Model Number: RHPAC3001 / RHPAC3001B 220-240V AC 50Hz For Customer Services & Spare Parts please call 0345 209 7461 Or visit us at mda.russellhobbs.com PLEASE RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
CONTENTS Page(s) Safety Instructions and Electrical Safety 3 - 5 Electrical Safety Feature Diagram Control Panel Diagram Installing your Air Conditioner 9 - 11 Using your Air Conditioner 12 - 21 Draining your Air Conditioner 22 – 24 Cleaning your Air Conditioner Start/End of Season Operations Troubleshooting Guarantee and Customer Services... -
Page 3: Safety Instructions And Electrical Safety
Safety Instructions Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. • This model uses natural refrigerant gas as part of its cooling system. - Page 4 Safety Instructions • This appliance is designed to be used by adults, do not allow children to play with the appliance. • The appliance is intended for residential use only. • When defrosting and cleaning the appliance, do not use any tools other than those recommended by the manufacturing company.
- Page 5 Safety Instructions • WARNING: System contains refrigerant under very high pressure. The system must be serviced and repaired as recommended by the equipment manufacturer and by qualified persons only. • Do not use in the following locations: - Next to a source of fire. An area where oil is likely to splash.
-
Page 6: Electrical Safety
Electrical Safety THIS APPLIANCE MUST BE PLUGGED INTO AN EARTHED SOCKET • Before switching on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 220 –... -
Page 7: Feature Diagram
FEATURE DIAGRAM Front Rear 1. Control panel 5. Intake grill 2. Handle (both sides) 6. Air outlet grill 3. Castors 7. Intake grill 4. Deflector 8. Power cable 13. Remote control slot 9. Plug fixer 10. Condensation drain (Dehumidification) 11. Condensation drain For Customer Services &... -
Page 8: Control Panel Diagram
CONTROL PANEL DIAGRAM Front Rear 1. Timer button A. Cool mode 2. Fan button B. Dehumidify mode 3. Increase button C. Fan mode 4. Display screen D. High fan speed 5. Decrease button E. Low fan speed 6. Mode button F. -
Page 9: Installing Your Air Conditioner
INSTALLING YOUR AIR CONDITIONER Exhausting Hot Air In the COOL mode the appliance must be placed close to a window or opening so that the warm exhaust air can be ducted outside. First position the unit on a flat floor and make sure there is a minimum of a 45cm (18inch) clearance around the unit and ensure this is within the vicinity of a plug socket. - Page 10 INSTALLING YOUR AIR CONDITIONER Location • The unit should be placed on firm ground to help minimise noise and vibration. For safe and secure positioning, place the unit on a smooth, level floor which is strong enough to support the unit. •...
- Page 11 INSTALLING YOUR WINDOW KIT Your Russell Hobbs Air Conditioner has been supplied with a Window Sealing Kit. The kit is suitable for use on UPVC windows that open internally or externally either 3 sides, or 4 sides. It is not suitable for middle opening windows such as skylights, or wooden frames.
-
Page 12: Using Your Air Conditioner
USING YOUR AIR CONDITIONER Operating from the control panel The control panel is on top of the appliance and it enables you to manage functions without using the remote control. However, to use the appliance to its full potential you are advised to use the remote control. To turn the appliance on plug it into a mains socket and the appliance will enter standby mode. - Page 13 USING YOUR AIR CONDITIONER FAN Mode When using the appliance in this mode, the air hose does not need to be attached. To set this mode correctly: ‐ Press the MODE button several times until the FAN mode indicator light appears. ‐...
- Page 14 USING YOUR AIR CONDITIONER Switching the unit of temperature Hold both the INCREASE and DECREASE buttons at the same time until the appliance beeps (approx. 5 seconds). Once the appliance has beeped you will be able to change the unit of temperature. For example: Before change and when in cool mode the screen will display like this.
- Page 15 USING YOUR AIR CONDITIONER ‐ Continue to press the TIMER button until the desired time is displayed. Wait for approximately 5 seconds and then the timer will then be active. Only the TIMER mode indicator light should be on. ‐ Press either the TIMER or the ON/OFF button and the timer will be cancelled.
- Page 16 USING YOUR AIR CONDITIONER Operating from the remote control On/Off button Mode button Night Mode button Increase button Decrease button Function not present on this appliance Fan button Timer button Unit Switch button • Point the remote control at the receiver on the appliance. •...
- Page 17 USING YOUR AIR CONDITIONER Inserting or Replacing the Batteries To insert or replace the batteries follow the steps below: 1. Remove the cover on the rear of the remote control. 2. Insert two “AAA” 1.5V batteries into the correct positions (see instructions inside the battery compartment).
- Page 18 USING YOUR AIR CONDITIONER COOL Mode, FAN Mode, DRY Mode, Setting the Timer To correctly set these four modes/functions using the remote control, follow the same steps that are stated in the ‘Operating from the control panel’ section of this manual but instead of pressing the buttons mentioned on the control panel press the corresponding buttons on the remote control.
- Page 19 USING YOUR AIR CONDITIONER Night Mode function This function is useful for the night as it gradually reduces the operation of the appliance. To set this function correctly: - Select the COOL or DEHUMIDIFY mode. - Press the NIGHT MODE button. The appliance will then operate in the previously selected mode.
- Page 20 USING YOUR AIR CONDITIONER Tips for correct use To get the best out of your appliance, follow these recommendations: • If possible, close the windows and doors in the room you want to be air conditioned (Fig 21). When installing the appliance semi- permanently you should leave a door slightly open (as little as 1cm) to guarantee correct ventilation.
- Page 21 USING YOUR AIR CONDITIONER Self-Diagnosis This appliance has a self-diagnosis system to help identify a number of malfunctions. The following error messages will be displayed is the appliance has identified a malfunction. DISPLAY WHAT SHOULD YOU DO? PROBE FAILURE If this is displayed please contact our Customer Service team by calling 0345 209 7461.
-
Page 22: Draining Your Air Conditioner
DRAINING YOUR AIR CONDITIONER Water drainage method When there is excess water condensation inside the unit, the appliance will stop running and ‘Ft’ will display (FULL TANK as mentioned in the self diagnosis). This indicates that water needs to be drained out using one of the following procedures. Manual Draining (Fig. - Page 23 DRAINING YOUR AIR CONDITIONER 2. Remove the drain plug. When removing the plug some residual water may spill out, so ensure you have a pan to collect the water. 3. Connect the supplied drain hose to the drain outlet. 4. The water can be continuously drained through the hose into a floor drain or bucket.
- Page 24 DRAINING YOUR AIR CONDITIONER Middle drainage When the unit is running in DEHUMIDIFY mode, you can chose to drain the appliance through the middle drainage hole. This is done as follows: 1. Unplug the unit from the power source 2. Remove the drain plug (Fig A). While doing this some residual water may spill out, so ensure you have a pan to collect the water.
-
Page 25: Cleaning Your Air Conditioner
CLEANING YOUR AIR CONDITIONER Before any cleaning or maintenance, turn the appliance off by pressing the ON/OFF button on either the control panel or remote control, wait for a few minutes and then unplug the appliance from the mains socket. Cleaning the cabinet You should clean the appliance with a slightly damp cloth and then pat dry with a dry cloth. -
Page 26: Start/End Of Season Operations
START/END OF SEASON OPERATIONS Start of season checks Make sure the power cable and plug are undamaged and the earth system is efficient. Follow the installation instructions within this manual precisely. End of season operations To empty the internal circuit completely of water, remove the cap and run all the water off into a pan. -
Page 27: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE SOLUTION The appliance does not come -There is no current -Wait -It is not plugged into the -Plug it into the mains mains -Wait 30 minutes and if the -The internal safety device has problem persists please tripped contact our Customer Service team on 0345 209 7461. -
Page 28: Guarantee And Customer Services
GUARANTEE AND CUSTOMER SERVICES At Russell Hobbs, we take all our customer feedback seriously. Feel free to contact our Customer Service Team, on 0345 209 7461 who will be more than happy to assist you. This product is guaranteed for 12 months from the date of the original purchase. -
Page 29: Spare Parts
SPARE PARTS To check the availability of the following spare parts, simply contact our friendly Customer Services team using the details provided at the bottom of this page. Remote Control Exhaust Hose Drain hose For Customer Services & Spare Parts please call 0345 209 7461 Or visit us at mda.russellhobbs.com RHPAC3001 r4.1... -
Page 30: Specification
SPECIFICATION Model RHPAC3001 / RHPAC3001B Voltage 220 – 240V 50Hz Power Input 780W Maximum Cooling Capacity 7000 BTU Suitable Room Size 8-14 (m2) Refrigerant R290/0.17kg Overall Size (W x H x D) 32 x 67 x 32 (cm) Weight 24.5 KG Moisture Removal 0.6 L/hr... -
Page 31: Notes
NOTES RHPAC3001 r4.1... - Page 32 Russell Hobbs is a registered trademark used under license from Spectrum Brands (UK) Ltd. Made under license by Product Care Trading Limited, Wigan, WN2 4AY/ PCT (NI) Ltd, Belfast, BT5 5AD Russell Hobbs Support: call 0345 209 7461 or visit mda.russellhobbs.com The ‘wheelie bin’...
