HORTON OTTOMAN BED ASSEMBLY INSTRUCTIONS

COMPONENT LIST

1 x Headboard
1 x Footboard
COMPONENT LIST
2 x Mattress Bars
24 x M8 x 20mm
bolts with Washer
(12 pcs attached to
head/foot board )
2 x Side Rail
( R & L )
1 x M8 x 80mm
8 x M8 x 60mm
bolts with washer
bolts with washer
and nut
and nut
2 x Slatted bed frame
2 x Bottom Board 2 x Joining Brackets 4 x Support Brackets
( R & L )
6 x M6 x 60mm
1 x 4 mm
Allen Key
bolts with washer
and nut
1 x 5 mm
1 x 11 mm
Allen Key
Spanner
1 x 13 mm
Spanner
