Summary of Contents for TEMPUR ACTIVEbreeze
- Page 1 ACTIVEbreeze‡ OWNER’S MANUAL TEMPUR Customer Service AU.: 1300 306 062 | NZ: 0800 483 6789 Patent Pending...
-
Page 2: Table Of Contents
table of contents Safety Precautions and Usage Statements ............1-3 Parts List . -
Page 3: Safety Precautions And Usage Statements
Attention: Important Safety Disclaimers Read all instructions before using your TEMPUR-PEDIC ACTIVEbreeze° ERGO EXTEND adjustable base. SAVE THESE INSTRUCTIONS. In-Home Use and Hospital Disclaimer: To reduce the risk of shock, burns, fire or injury: The TEMPUR-PEDIC ACTIVEbreeze° ERGO EXTEND... - Page 4 This is normal. Weight Limits: The recommended weight limits on the TEMPUR-PEDIC In normal operation of the Activebreeze system, fan noise from the ACTIVEbreeze° ERGO EXTEND are: system can be expected especially at higher speeds. When entering, Queen/Long Single/Single: 850 pounds.
- Page 5 Step 5: Return the base to flat position. ACTIVEbreeze Care: ° TEMPUR-PEDIC ACTIVEbreeze° ERGO EXTEND are equipped with removeable, washable fan filters. Recommended cleaning interval for the filters is every 6 months or more frequent if necessary. Water and mild detergent can be used to clean the filters. Please dry the filter prior to re-installing.
-
Page 6: Parts List
parts list Before discarding the packing materials, ensure all the parts are accounted for. All electronics and components that need to be installed are located in boxes under the base or attached to the frame. Wireless Remote Control (1) AAA Batteries (3) Mattress Retainer Bar (1)* Legs (4) Power Cord (1) -
Page 7: Base Overview
base overview Underbed Light Fan Motor Battery Backup Box Fan Control Box USB Ports Massage Motor Massage Motor Head Motor Foot Motor Massage Motor Massage Motor Control Box Underbed Light USB Port Fan Motor... -
Page 8: Quick Reference Guide
quick reference guide Not to scale. For illustration purposes only. Read all instructions before beginning installation. Control Box Power Supply Power Cord connection ports to head and foot motors (massage and lift). Installed Input Fan Motor under the base. Power Cord Fan Control USB Charging Ports Splitter... -
Page 9: Installation Guide
Place power supply on the ground and extend from the base. Ensure that the power supply and all attached cords are directed toward the desired surge protector. For TEMPUR customer service call AU: 1300 306 062 | NZ: 0800 483 6789... - Page 10 STEP 10 Slide the left side of the mattress retainer bar into the bracket. Pull the retainer bar to the opposite bracket and secure the right side. For TEMPUR customer service call AU: 1300 306 062 | NZ: 0800 483 6789...
-
Page 11: Mattress Setup
Setup is now complete. Refer to remote control guide and user manual pages 10-13 and 16 for complete information regarding tandem setups and operation of the adjustable bed base and ACTIVEbreeze° systems. Setup is now complete! Test all functions on remote. -
Page 12: Remote Control
remote control Remote Control arrives paired to the adjustable base. Three (3) AAA batteries are required to operate the remote. MASSAGE Head Zone Massage Control Activates simple steady-state massage and toggles through 2 intensity levels. Low, high and off. Foot Zone Massage Control Activates simple steady-state massage and toggles through 2 intensity levels. - Page 13 remote control Remote Control arrives paired to the adjustable base. Three (3) AAA batteries are required to operate the remote. ADJUST PRESET Zero G ‡ Head Position Adjustments Adjusts your legs to relieve pressure off the Use to raise and lower the head section of lower back.
- Page 14 remote control FAN MODES Tandem Mode Standard Fan Operation This mode applies to a sync setup of TXL and Fan buttons will operate the fan(s) at the selected CKS sizes only. When activated, the fan on the speed for up to 10 hours. Simply tap the LEFT or base assigned “left side”...
-
Page 15: Remote Control Pairing
When the backlight light goes away, the remote is no longer in Child Lock. The remote or call Tempur-Pedic customer service: and adjustable base will work normally. AU: 1300 306 062 | NZ: 0800 483 6789... -
Page 16: Emergency Battery Backup Box
Press and hold the button on the battery backup Install the 9 Volt batteries into the provided battery backup box. box to lower the base to flat position. Do not mix brand name batteries. For Tempur-Pedic customer service call AU: 1300 306 062 | NZ: 0800 483 6789... -
Page 17: Connecting Strap
connecting strap (optional) Connecting straps are secured to the base frame upon delivery. OVERVIEW If a split setup is being installed, plastic connecting straps are provided (one per base) to secure the bases together. Use both straps to secure the head and foot portions together. -
Page 18: Syncing Two Bases
syncing two bases (optional) A Sync Cord is included with Single and Single Long size bases. The Sync Cord connects the two control boxes to a single remote for the synchronization of two bases. LEFT Fan and SYNC button at the same time. Backlight LED STEP 1 flash (2x) after 6 seconds indicates that Tandem Setup is on. -
Page 19: Headboard Brackets (Not Included)
headboard bracket installation guide (optional) Headboard Brackets are an optional accessory and are not included. A hex key is included with the accessory kit to complete installation. To install the headboard bracket, place the base on it’s side. c) Secure T-Bracket in place by inserting two short screws STEP 1 through top of bracket. -
Page 20: Troubleshooting
If your issue is not resolved by following the instructions above, please locate the serial number on the warranty card or back of the remote control and call the customer service team for your region. For TEMPUR customer service call AU: 1300 306 062 | NZ: 0800 483 6789... - Page 21 notes...
- Page 22 Tempur Customer Service Australia: 1300 306 062 New Zealand: 0800 483 6789 Email: info@tempur.com.au Web: www.tempur.com.au V002_10/2019...
